Straps 1-Hole X 1-1/4 EMT Conduit Stp (Box 50)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Country Of Origin:
- United States
- Division:
- Electrical H1
- Language Code:
- EN
- Number Of Holes:
- 1
- Order Minimum Imperial:
- 50
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Box
- Product Group:
- Hardware
- Product Height:
- 3.25 in
- Product Length:
- 7.25 in
- Product Weight:
- 5 lbs
- Product Width:
- 6.75 in
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Straps and Clips
- Product Type:
- One Hole EMT Pipe Strap
- Type2:
- One Hole EMT Pipe Strap
- Product Finish:
- Zinc
- Product Details:
- One Hole EMT Pipe Strap
- Product Material:
- Steel
Metallics 125EOS – Frequently Asked Questions
1) Does this Metallics EMT strap meet Buy American / ARRA requirements for a federal job?
Yes. The 125EOS is flagged both ARRA compliant and Buy American compliant, with United States country of origin - which is what a government, school or healthcare procurement file usually needs on record for conduit hardware.
2) Can the 125EOS EMT strap be used on rigid or IMC conduit instead of EMT?
It's built as an EMT strap. EMT has a smaller outside diameter than rigid or IMC of the same trade size, so a 1-1/4 EMT strap won't close correctly over 1-1/4 rigid. Use a strap sold for rigid/IMC on those runs.
3) Is the 125EOS conduit strap galvanized or painted steel?
Steel with a zinc finish. That's the standard plated strap for dry interior runs and normally protected locations; for exposed coastal or wet corrosive environments, spec a stainless strap instead.
4) How many 1-1/4 EMT straps come in a box of Metallics 125EOS?
They ship 50 to a box, and 50 is the order minimum, so you buy full boxes rather than loose pieces. Metallics notes other sizes and quantities are available by request.
5) Do 1-hole EMT straps come with screws or anchors?
Hardware is separate. A one-hole strap gives you a single fastener hole, so you supply the screw or anchor suited to the substrate - wood screw into studs, self-drilling screw into metal stud or deck, masonry anchor into block or concrete. Order those alongside the box of 50.
6) Should I use a one-hole strap or a two-hole strap for 1-1/4 EMT?
A one-hole strap like the 125EOS installs fast with a single fastener and is the usual pick for vertical or general surface runs. A two-hole strap resists twisting better and is preferred where the conduit is heavily loaded, run overhead, or where a spec calls out two-point fastening. For long horizontal runs of 1-1/4 EMT, many inspectors and specs favor the two-hole.
7) How much does a box of 50 Metallics 125EOS straps weigh for shipping?
A box of 50 comes in at 5 lbs, and the carton runs 7.25 x 6.75 x 3.25 inches - small enough to keep several sizes on the truck without eating van space.
