Ideal Industries 12-Pole Terminal Strip 22-6 AWG with Heavy-Duty Corrosion-Resistant Construction
Professional-grade wiring connection solution with UL recognition and CSA certification
The Ideal Industries 12-Pole Terminal Strip delivers reliable electrical connections for professional applications, featuring heavy-duty construction with corrosion-resistant components and a rugged polyester thermoplastic base rated UL 94V-0. This terminal strip accommodates wire sizes from 6 through 22 AWG Cu with .625 (15.88mm) center spacing and #10-32 Philslot nickel-plated brass terminal screws for secure, long-lasting connections.
Professional Features & Benefits
- 12-Pole Configuration: Provides multiple connection points for efficient wire management and distribution in electrical panels and control systems.
- 22-6 AWG Wire Range: Accommodates a wide range of copper wire sizes for versatile application compatibility and installation flexibility.
- UL Recognized & CSA Certified: Meets rigorous safety standards (E82048, LR15364) ensuring code compliance and reliable performance in professional installations.
- Heavy-Duty Corrosion-Resistant Construction: Features corrosion-resistant screws and surface plates for extended service life in demanding environments.
- Rugged Polyester Thermoplastic Base: UL Rated 94V-0 material provides excellent durability and flame resistance for safe operation.
- #10-32 Nickel-Plated Brass Screws: Philslot terminal screws deliver secure connections with excellent conductivity and corrosion resistance.
- .625 (15.88mm) Center Spacing: Standard spacing ensures compatibility with industry-standard mounting and wiring practices.
Technical Specifications
- Deparetment: Electrical
- Product Group: Outlets
- Product Subgroup: Wiring Accessories
- Recommended Torque: 20 in.-lb.
- parent sku: IDL-89-512
Professional Applications
- Electrical Panel Wiring and Distribution
- Control System Connections
- Industrial Equipment Terminations
- Commercial Building Electrical Systems
- Motor Control Centers
- Instrumentation and Control Wiring
- Maintenance and Repair Applications
Why Choose Ideal Industries Quality?
Ideal Industries terminal strips combine UL recognition and CSA certification with heavy-duty construction featuring corrosion-resistant components and rugged polyester thermoplastic materials. The recommended 20 in.-lb. torque specification ensures proper installation while the nickel-plated brass terminal screws provide reliable, long-lasting electrical connections for professional applications.
Manufacturer Resources
Spec Sheet
Product Specs
- Product Group:
- Wire Connectors & Terminals
- Department:
- Electrical
- Product Subgroup:
- Terminal Blocks & Strips
- Recommended Torque:
- 20 in.-lb.
- parent sku:
- IDL-89-512
- Product Type:
- Terminal Block
Ideal Industries 89-512 – Frequently Asked Questions
1) What wire sizes will the Ideal 89-512 terminal strip accept?
The Ideal 89-512 terminal strip takes copper conductors from 22 AWG up to 6 AWG. That range covers control and instrumentation wiring at the small end and feeder-class branch conductors at the large end on the same block, so one strip can handle mixed terminations in a panel. Conductors are copper only.
2) How tight should I torque the screws on an Ideal 12-pole terminal strip?
20 in.-lb. is the recommended torque for the #10-32 Philslot nickel-plated brass terminal screws on the Ideal 89-512. Hitting that value matters on a 12-pole strip carrying mixed wire sizes: undertorqued terminations on fine 22 AWG strand back out under vibration, and overtorquing can strip the brass.
3) What is the terminal spacing on the Ideal 89-512 barrier strip?
Centers are .625 inch (15.88 mm) pole to pole, across all 12 poles. That is the dimension to check against your existing strip or panel layout before you order, since a replacement on a different center spacing will not line up with pre-drilled mounting or existing jumper bars.
4) Is this terminal strip UL recognized or CSA certified for a commercial panel build?
Both. The Ideal 12-pole strip is UL recognized under file E82048 and CSA certified under LR15364, and the polyester thermoplastic base carries a UL 94V-0 flame rating. That is the paperwork an inspector or a panel shop QA reviewer will ask for on control and motor control center work.
5) Will this terminal strip hold up in a damp or industrial environment?
It is built for it. The screws and surface plates are corrosion resistant, the terminal screws are nickel-plated brass, and the base is a rugged polyester thermoplastic rather than a general-purpose plastic. That combination is aimed at motor control centers, industrial equipment terminations, and plant maintenance work rather than dry residential use.
6) Do I need ring or spade terminals for the Ideal 89-512, or can I land bare wire?
The terminals are #10-32 screws, so any ring or fork terminal sized for a #10 stud lands directly on it. Bare stranded conductors can be captured under the screw head as well. For 22 AWG and other fine strand, a crimped #10 ring is the more secure termination, especially where the assembly sees vibration.
7) Is a barrier terminal strip like this the right choice, or should I use DIN rail terminal blocks?
A barrier strip like the Ideal 89-512 is a fixed 12-pole block you screw to a panel surface or subpanel, with all twelve circuits in one piece at .625 inch centers. It suits equipment terminations, motor control centers, and instrumentation runs where the pole count is known and fixed. DIN rail blocks are the better pick when you need to add or remove poles later or mix block types on one rail. If the count is set and you want one mounted part instead of a rail assembly, the barrier strip is simpler.
8) Can I use the Ideal 89-512 with aluminum conductors?
No. The wire range on this strip is specified as 22 through 6 AWG copper. Use a block rated for aluminum or a CU/AL-listed connector if your feeders are aluminum.
