Topaz Lighting 472 45° Liquidtight Connector, Malleable Iron

Topaz Lighting 472 45° Liquidtight Connector, Malleable Iron

(No reviews yet) Write a Review

Model: 477

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1.97
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Topaz Lighting 472 45° Liquidtight Connector, Malleable Iron

The Topaz Lighting 472 45° Liquidtight Connector joins liquidtight flexible conduit (LFMC) to enclosures at a 45° angle, giving installers a clean routing option where a straight connector won't fit the run. This connector is part of Topaz Lighting's Liquidtight Fittings lineup and is available across a range of trade sizes from 1/2" through 4" to fit a variety of conduit runs. Built from malleable iron with a zinc-plated finish, it is engineered for durability in demanding conduit and raceway installations, and it includes an insulated throat to help protect conductor insulation as wires pass through the fitting. It's a practical choice for electricians who need a dependable transition between LFMC and junction boxes, panels, or equipment housings.

Key Features

  • 45° Angle Design: Provides an angled transition for liquidtight flexible conduit runs where space or routing constraints make a straight connector impractical.
  • Wide Size Range: Offered in trade sizes from 1/2" through 4" to match a variety of LFMC conduit runs across commercial and industrial projects.
  • Durable Construction: Malleable iron body offers strength and long-term reliability in demanding conduit and raceway installations.
  • Zinc-Plated Finish: Helps resist corrosion and extends service life across a range of conduit and raceway environments.
  • Insulated Throat: Protects conductor insulation from abrasion as wires are pulled through the connector during installation.
  • Liquidtight Compatibility: Purpose-built for use with liquidtight flexible conduit, supporting secure, code-conscious conduit-to-enclosure connections.
  • Connector-Style Fitting: Simplifies conduit terminations at boxes, panels, and equipment enclosures within Conduit & Raceway systems.

Technical Specifications

  • Angle: 45°
  • Pack Size: 100

Typical Applications

  • Liquidtight Flexible Conduit (LFMC) Terminations
  • Commercial and Industrial Electrical Installations
  • Conduit and Raceway Systems
  • Junction Box, Panel, and Equipment Enclosure Connections
  • Angled Conduit Routing in Tight Spaces
  • Renovation and New Construction Wiring Projects

Why Topaz Lighting?

Topaz Lighting builds its liquidtight fittings from malleable iron with protective zinc-plated finishes, giving electrical professionals a connector that stands up to the demands of everyday conduit and raceway work. The added insulated throat reflects attention to installation detail, helping safeguard conductors during pulls. Available across a full range of trade sizes, the Topaz Lighting 472 45° Liquidtight Connector gives contractors a dependable angled option for Conduit & Raceway applications, built for reliable, code-conscious electrical work on new construction and renovation projects alike.

Product Specs

Department:
Electrical
Product Group:
Conduit & Raceway
Product Subgroup:
Conduit Bodies & Fittings
Product Type:
Connector
Conduit Type:
Liquidtight
Angle:
45°
Product Material:
Malleable Iron
Product Color:
Zinc-Plated
Pack size (unit):
100
Product Finish:
Zinc-Plated
Product Size:
1/2" - 4"

Topaz Lighting 477 – Frequently Asked Questions

1) Will the Topaz 472 45 degree liquidtight connector work with regular flexible metal conduit, or only liquidtight?
Liquidtight only. The Topaz 472 is built for liquidtight flexible metal conduit (LFMC), and the sealing gland and ferrule that make the connection are sized to the jacket on liquidtight, not to bare FMC (Greenfield). Running standard FMC into it won't clamp or seal correctly. For a dry indoor FMC run into a box you want a squeeze or screw-in FMC connector instead.
2) Do I still need a bushing with the Topaz 472 liquidtight connector?
No separate bushing needed. The 472 has an insulated throat built in, so the conductors are already protected from the metal edge as they come through. That is the whole point of the insulated throat, it saves you buying and installing a plastic bushing on the inside of the box.
3) What trade sizes does the Topaz 472 45 degree liquidtight connector come in?
Trade sizes run 1/2 inch through 4 inches, and each size is its own part number: 491 for 1/2 inch, 472 for 3/4 inch, 473 for 1 inch, 474 for 1-1/4 inch, 475 for 1-1/2 inch, 496 for 2 inch, 477 for 2-1/2 inch, 498 for 3 inch, 479 for 3-1/2 inch, and 480 for 4 inch. Order by the size of the liquidtight, not the size of the knockout, they match on standard trade sizing.
4) When should I use a 45 degree liquidtight connector instead of a straight or 90 degree one?
The 45 splits the difference. Use it where a straight connector would force the liquidtight into a tight bend coming off the box, and a 90 would kick the conduit flat against the wall or the equipment. Typical case: a motor or rooftop unit sitting off to one side of the enclosure, or a panel mounted close to a corner. It also keeps the pulling radius easier on conductors than a hard 90. If you have full clearance in line with the knockout, a straight connector is fewer dollars and one less leak path.
5) Is the Topaz 472 liquidtight connector OK for outdoor or wet locations?
The body is malleable iron with a zinc-plated finish, which is the standard corrosion-resistant combination for liquidtight work and holds up outdoors and in washdown or damp industrial areas. Where you have salt spray or aggressive chemicals, a non-metallic or stainless liquidtight fitting is the better call. Note that a liquidtight connection is only as good as the seal at both ends, so the enclosure knockout needs a sealing locknut or gasket to keep the whole run rated.
6) Which Topaz part number do I order for a 3/4 inch liquidtight run at 45 degrees?
Part number 472, the 3/4 inch size. The numbering is not sequential across the whole range, so watch the jumps: 491 is the 1/2 inch, then 472, 473, 474 and 475 climb through 1-1/2 inch, but 2 inch is 496 and 3 inch is 498. Order by trade size and confirm the number against it rather than assuming the next digit up is the next size up.
7) Is the Topaz 472 sold individually or do I have to buy a box of 100?
Pack size on the 472 is 100 pieces. That is the standard carton for the smaller trade sizes and it is how contractors stocking a truck or a job trailer normally buy them. If you need a handful for a single termination, order the count you need and we will tell you how it breaks.
