TRIMCO 1746 1-1/4" DIAMETER PUSH/PULL BAR SET 18" CTC STRAIGHT PULL OVERVIEW
1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull. 1-1/4" dia. Push/Pull Bar Set 18" CTC Straight Pull.
Trimco’s 1700 Series Push/Pull Bars & Sets are manufactured in the United States from solid stainless steel, bronze or brass. These heavy duty bars are available with a multitude of mounting options for most applications including steel, wood and glass doors. Available in most architectural finishes, the Trimco 1700 Series Bars are also offered with a fOCAL designer series option.
Buy the TRIMCO 1746 Series today to add a stylish hardware for your home!
TRIMCO 1746 1-1/4" DIAMETER PUSH/PULL BAR PULL PRODUCT FEATURES
- Manufactured in the United States from solid stainless steel, bronze and brass.
- Options include 3/4″, 1″ and 1-1/4″ diameter material and 10″, 12″ or 18″ pulls.
- fOCAL designer option available.
- Multiple mounting options for metal, wood and glass doors.
- Must specify CTC on bars. Custom sizes and finishes also available.
APPLICATIONS
- Commercial & Industrial Buildings
- Government & Military Facilities
- Multifamily & Mixed-Use
- Public Buildings & Facilities
- Retail & Strip Malls
TRIMCO 1746 SERIES COLOR VARIATIONS
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Bright Brass (605)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Satin Brass (606)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Oil Rubbed Bronze (613)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Dark Oxidized Satin Bronze (613E)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Matte Black (622)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Bright Chrome (625)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Satin Chrome (626)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Satin Aluminum (628)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Bright Stainless Steel (629)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Satin Stainless Steel (630)
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull Healthy Hardware Steralloy Silver (710CU)
TRIMCO 1700 SERIES COLLECTION
Trimco 1729 3/4" Diameter Push/Pull Bar Set 10" CTC Straight Pull
Trimco 1731 1" Diameter Push/Pull Bar Set 10" CTC Straight Pull
Trimco 1732 1" Diameter Push/Pull Bar Set 12" CTC Straight Pull
Trimco 1737 1" Diameter 90º Offset Push/Pull Bar Set 10" CTC Offset Pull
Trimco 1738 1" Diameter 90º Offset Push/Pull Bar Set 12" CTC Offset Pull
Trimco 1740 3/4" Diameter Push Bar E Mounting Standard
Trimco 1741 1" Diameter Push Bar E Mounting Standard
Trimco 1745 1-1/4" Diameter Push Bar E Mounting Standard
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull
Trimco 1746-1 1-1/4" Diameter Push/Pull Bar Set 12" CTC Straight Pull
Trimco 1747 1-1/4" Diameter 90º Offset Push/Pull Bar Set 18" CTC Offset Pull
Trimco 1747-1 1-1/4" Diameter 90º Offset Push/Pull Bar Set
RESOURCES & DOWNLOADS
Manufacturer Resources
Product Specs
- Commercial/Residential:
- Commercial
- Product Group:
- Door Trim and Accessories
- Product Subgroup:
- Door Pulls, Push and Pull Plates
- Product Type:
- Door Pulls
- Subcategory:
- Door Pulls, Push and Pull Plates
- Healthy Hardware:
- Yes
- (CTC) Center-to-Center:
- 18"
- Product Diameter:
- 1-1/4"
- Product Dimension:
- 1-1/4" Diameter
- Product Category:
- Door Trim and Accessories
- Department:
- Door Hardware
Trimco TRI-1746E-12.605 – Frequently Asked Questions
1) What exactly comes in the Trimco 1746 push/pull bar set - is it a pull on one side and a push bar on the other?
That's right. The 1746 is a two-piece set: a straight pull on the pull side and a push bar on the opposite face, both 1-1/4 inch diameter solid bar. It's ordered as a set, so you're outfitting both faces of one door leaf with one order rather than buying a pull and a push plate separately.
2) Will the Trimco 1746 mount on a glass storefront door, or is it only for wood and hollow metal?
Both. Trimco's 1700 Series bars are offered with mounting options for steel, wood and glass doors, and the 1746 is ordered with either E-Mount or G-Mount. G-Mount is the glass-door option, E-Mount is the standard mounting used on metal and wood doors. Pick the mounting axis to match the door substrate before you order, because the two are not interchangeable after the fact.
3) The Trimco 1746 is listed as 18 inch CTC - can I get the same bar set in other lengths?
The 1746 designation is the 18 inch center-to-center straight pull, and 18 inches is the base spec on the model. Sizes of 12, 18, 24, 30 and 36 inches are offered on the bar. Center-to-center must be specified when you order, so state the CTC you want on the purchase order rather than assuming the default.
4) The 1746 is a straight pull. What should I use if the opening calls for an offset pull instead?
The Trimco 1746 is a straight push/pull bar set. When the opening needs the handle standing off the door face, offset options include the ABH AB3310 offset flat end pull, the ABH AB3330 offset round end pull with custom length options, the Ives 8169 C style offset solid pull at 1 inch diameter, and the Ives 8145EZHD 45 degree offset pull. Trimco also builds the 1747 as the 90 degree offset version of the 1-1/4 inch bar set at 18 inch CTC.
5) What is a back-to-back door pull alternative to the Trimco 1746 if I want the same handle on both faces?
The Trimco 1746 pairs a 1-1/4 inch pull with a push bar on the reverse face. If both faces should carry a matching pull instead, back-to-back sets include the Sure-Loc PL-2KN knurled long door pull double-sided, the Deltana SSPOBB24 24 inch back-to-back modern offset pulls, the Deltana SSPORBB24 24 inch back-to-back round offset pulls, and the Deltana OHP620 off-set handle pull back-to-back set for doors 1-1/8 inch to 1-3/8 inch thick. Note the Deltana pairs listed are offset rather than straight.
6) I am putting a pull on a glass door. Is the Trimco 1746 the right choice or should I look at another pull?
The Trimco 1746 is a good fit for that opening. The 1700 Series bars are built with multiple mounting options covering metal, wood and glass doors, and the 1746 is ordered in E-Mount or G-Mount. Most of the comparable single pulls, such as the Sure-Loc PL-1KN and the ABH AB7200, are specified with through-bolt or thru-bolt mounting, which is aimed at wood and metal doors rather than glass.
7) What is the 710CU Steralloy Silver finish on the Trimco 1746 for?
710CU is Trimco's Healthy Hardware Steralloy Silver, a copper-based antimicrobial finish option, and the 1746 is flagged as a Healthy Hardware item. It's the finish specified on high-touch openings in healthcare, senior living and food service where the facility wants a copper alloy touch surface. The other ten options are standard architectural finishes: 605 bright brass, 606 satin brass, 613 oil rubbed bronze, 613E dark oxidized satin bronze, 622 matte black, 625 bright chrome, 626 satin chrome, 628 satin aluminum, 629 bright stainless, 630 satin stainless.
8) Is the Trimco 1746 heavy enough for a high-traffic commercial entrance?
Yes. It's a commercial-grade item, made in the United States from solid stainless steel, bronze or brass rather than tube, and Trimco describes the 1700 Series bars as heavy duty. The 1-1/4 inch solid section is the largest diameter in the series, which is what you want on entrances, corridors and public building doors that see constant pull cycles.
9) I need to match existing door pulls in my building - what are the alternatives to the Trimco 1746 bar set?
For a comparable commercial straight round bar, the Ives 8103HD is a heavy duty 1 inch round straight pull with through-bolt mounting and the Ives 8102HD is the heavy duty 3/4 inch round straight with 1-1/2 inch clearance. ABH's AB3300 is a 1 inch diameter straight flat end pull. Those are single pulls, though. If you specifically need a push bar on the back face like the 1746 gives you, a back-to-back set such as the Deltana SSPOBB24 or SSPORBB24 (24 inch offset) is the closer concept, though those are offset rather than straight.
10) I only need a push bar on the door, not a pull - does Trimco make that?
Yes, and buying the 1746 set would leave you with a pull you don't need. The 1745 is the 1-1/4 inch diameter push bar on its own with E mounting standard. The 1741 is the same idea in 1 inch diameter and the 1740 in 3/4 inch. Those are the ones to order for a push-side-only opening.
11) Is the Cal-Royal PUL-175 a substitute for a Trimco 1746 push/pull bar set?
No. The Cal-Royal PUL-175 is a night latch cylinder pull 3-1/2 inches in height in stainless steel, a short pull with a cylinder cutout used with a night latch. The Trimco 1746 is a 1-1/4 inch diameter push/pull bar set with an 18 inch center-to-center pull and no cylinder provision. They serve different openings and are not interchangeable.
12) I need a smaller diameter bar than the Trimco 1746 for a lighter door. What are the options?
The Trimco 1746 uses 1-1/4 inch diameter stock. Smaller diameters in the same 1700 family include the 1729 at 3/4 inch with a 10 inch CTC straight pull and the 1731 and 1732 at 1 inch with 10 inch and 12 inch CTC. Across other brands, the Ives 8102HD is a heavy duty straight pull with a 3/4 inch round bar and 1-1/2 inch clearance, and the ABH AB7200 is a solid stainless steel flat end pull at 7/8 inch diameter with through-bolt mounting.
13) If I need a custom pull length rather than a stock size, what are my choices against the Trimco 1746?
The Trimco 1746 comes in 12, 18, 24, 30 and 36 inch lengths, and Trimco notes custom sizes and finishes are also available with CTC specified on the bars. If a non-stock length is required from another source, the ABH AB3330 offset round end pull is offered with custom length options.
14) Which pull should I specify if ADA compliance is the deciding factor over the Trimco 1746?
Among the offset pulls, the Ives 8145EZHD is stated as an ADA compliant 45 degree offset door pull with heavy duty mounting hardware. The Trimco 1746 is a 1-1/4 inch diameter straight push/pull bar set for commercial openings; where the specification calls out an ADA compliant pull by name, the 8145EZHD carries that claim directly.
15) For a healthcare facility, does the Trimco 1746 offer anything the other commercial pulls do not?
The Trimco 1746 is offered in a 710CU Healthy Hardware Steralloy Silver finish in addition to standard architectural finishes such as 626 satin chrome and 630 satin stainless steel. Comparable commercial pulls such as the Ives 8103HD straight heavy duty pull and the ABH AB7200 solid stainless steel pull are specified on construction and mounting rather than an antimicrobial-copper style finish option, so where a facility is standardizing on that finish the 1746 is the part that carries it.
16) Can I get the Trimco 1746 in a length or finish that isn't on the standard list?
Custom sizes and finishes are available on the 1700 Series bars, and there's also the fOCAL designer series option if you want something outside the eleven standard architectural finishes. For anything custom you'll need to state the exact center-to-center dimension with the order, since CTC is a required specification on these bars.
