Ty-Rap TC1112-TC1117 Multi-Bundle Mounting Strips (7.6mm Tie Width)

Ty-Rap Multi-Bundle Mounting Strip System 7.6mm Tie Width Nylon Construction

(No reviews yet) Write a Review

Model: TC1115

In Stock (leaves warehouse same day if ordered before 3pm ET)

$29.67
Adding to cart… The item has been added
Free Shipping on orders over $199.99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Ty-Rap Multi-Bundle Mounting Strip System 7.6mm Tie Width Nylon Construction

Professional cable management solution for parallel wire bundle installation

The Ty-Rap Multi-Bundle Mounting Strip System delivers reliable cable organization with 7.6mm tie width compatibility and durable nylon/polyamide 6.6 construction. This professional mounting solution accommodates multiple wire bundles in parallel installations with screw mounting capability and operates reliably across temperature ranges from -40 to +185°F.

Professional Features & Benefits

  • 7.6mm Tie Width Compatibility: Ensures secure cable bundle retention with standardized tie dimensions for consistent installation results.
  • Nylon/Polyamide 6.6 Construction: Provides exceptional durability and chemical resistance for long-term performance in demanding environments.
  • Temperature Rating -40 to +185°F: Maintains reliable operation across extreme temperature conditions for versatile application flexibility.
  • Screw Mounting Design: Enables secure permanent installation with standard fastening hardware for professional applications.
  • Natural Color Finish: Offers clean, professional appearance that blends with most installation environments.
  • UL E49405 Listed: Meets rigorous safety and performance standards for professional electrical installations.
  • Multiple Bundle Capacity: Accommodates up to six parallel wire bundles for efficient cable management organization.

Technical Specifications

  • Brand Label: Ty-Rap
  • Cable Size: 0.301 in7.64 mm
  • Effective Date: 19731120
  • Idea Granular Category Code Igcc: 5065 >> Cable tie mounts
  • Mounting Type: Screw
  • Process Temperature Rating: -40 to +185 °F
  • Product Color: Natural
  • Product Material: Nylon/Polyamide 6.6
  • Product Type: Multiple Bundle Mounting Strip
  • Rohs Date: 9AKK107992A8808
  • Special Functions: These nylon mounting strips for parallel installation of wire bundles can accommodate up to six clo
  • Standards: UL E49405
  • Department: Elecrtical

Professional Applications

  • Commercial Electrical Installations
  • Industrial Control Panels
  • Data Center Cable Management
  • Telecommunications Equipment Rooms
  • Manufacturing Facility Wiring
  • Professional Office Buildings
  • Utility and Infrastructure Projects

Why Choose Ty-Rap Quality?

Ty-Rap delivers proven reliability with UL E49405 listing and robust nylon/polyamide 6.6 construction that withstands extreme temperatures from -40 to +185°F. The professional-grade mounting strip system ensures long-term performance and maintains secure cable organization in demanding electrical environments.

Manufacturer Resources

Product Specs

Brand Label:
Ty-Rap
Cable Size:
0.301 in7.64 mm
Effective Date:
19731120
Idea Granular Category Code Igcc:
5065 >> Cable tie mounts
Installation Category:
Screw
Process Temperature Rating:
-40 to +185 °F
Product Color:
Natural
Product Material:
Nylon/Polyamide 6.6
Product Type:
Multiple Bundle Mounting Strip
Rohs Date:
9AKK107992A8808
Special Functions:
These nylon mounting strips for parallel installation of wire bundles can accommodate up to six clo
Standards:
UL E49405
Department:
Electrical

Ty-Rap TC1115 – Frequently Asked Questions

1) What cable tie width do the Ty-Rap TC1112 series mounting strips accept?
The TC1112 series strips are built around a 7.6mm tie width, listed as 0.301 in / 7.64 mm. Standard-width ties in that range feed through the strip slots; wider heavy-duty ties will not seat properly, so match your ties to 7.6mm before you order the strips.
2) How many wire bundles can I run on one Ty-Rap multi-bundle mounting strip?
It depends on the length you pick. The strips run from one bundle up to six: TC1113 at 53.3mm holds one bundle, TC1115 at 130.0mm holds three, TC1116 at 168.0mm holds four, TC1117 at 206.0mm holds five, and TC1112 at 244.0mm holds six parallel bundles. Pick the length by how many separate runs you need held side by side off the same mounting point.
3) How do these Ty-Rap strips attach, and do they come with screws?
Mounting is by screw, so the strip is fastened mechanically to panel steel, backboard, or framing rather than stuck on with adhesive. Fasteners are not part of the strip itself, so order the screws to suit your substrate (sheet metal screws for panel work, wood screws for plywood backboard). That also means they hold in heat and oil where an adhesive base would eventually let go.
4) Can these cable tie mounting strips be used outdoors or in unheated or hot areas?
They carry a temperature rating of -40 to +185 degrees F, which covers unheated warehouses, rooftop mechanical areas, and hot control cabinets. The material is nylon/polyamide 6.6 in natural color. Natural nylon is not UV stabilized, so for long-term exposure to direct sunlight a black UV-rated mount is the better choice.
5) Why use a multi-bundle mounting strip instead of individual cable tie mounts?
A single strip gives you one screw installation that carries several parallel bundles at fixed, even spacing, instead of laying out and drilling a separate mount for each run. That keeps circuits separated and dressed in line in a control panel or equipment room. If you only have one run to secure, the shortest version, TC1113 at 53.3mm, is the single-bundle size and behaves like a conventional tie mount.
6) Are Ty-Rap TC1112 series mounting strips UL listed for commercial electrical work?
Yes. The strips are covered under UL E49405, which is the listing referenced for the product. That is the file number inspectors and spec writers look for on cable tie mounts going into commercial panels and equipment rooms.
7) Will nylon 6.6 mounting strips hold up in an industrial panel with oils and cleaners around?
Nylon/polyamide 6.6 is the standard material for cable tie mounts in industrial panels and resists the oils and common chemicals found there. Where it is weaker is prolonged outdoor UV and continuous wet, high-humidity service, since nylon absorbs moisture. For indoor control cabinets, manufacturing wiring, and telecom rooms it is the normal choice.
