Von Duprin 22F-4FT Fire Rated Wide Stile Rim Exit Device, 48" Pushpad, Less Dogging

Von Duprin 22F-4FT Fire Rated Wide Stile Rim Exit Device, 48" Pushpad, Less Dogging

(No reviews yet) Write a Review

Model: 22EO-F 4 689
$881.00
$461.85
Selected Finish is
Selected Trim Function is
Selected Lever (For "L" Lever Option Only) is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$881.00
$461.85
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Von Duprin 22F-4FT Fire Rated Wide Stile Rim Exit Device, 48" Pushpad, Less Dogging

Commercial-Grade Fire Rated Rim Exit Device for Wide Stile Single and Double Door Applications

The Von Duprin 22F-4FT is a fire rated, wide stile rim exit device engineered for demanding commercial applications on single and double doors with mullion. Sized at 48" (4 ft) for wide door coverage, this pushpad rim exit device features a non-handed design and fits door stiles as narrow as 3-13/16" (97mm), accommodating a broad range of door configurations. Certified to ANSI/BHMA A156.3-2008 Grade 1 and UL listed for both Panic Exit Hardware and Fire Hardware (ANSI/UL 10C), it delivers the highest level of code-compliant performance. The device is designed and manufactured in accordance with the ISO 9001 Quality Management System, ensuring consistent, professional-grade quality.

Professional Features & Benefits

  • 48" Wide Door Coverage: Sized at 48" (4 ft) to accommodate wide stile single and double door applications, with compatibility for doors fitted with mullions.
  • Narrow Stile Compatibility: Fits door stiles as narrow as 3-13/16" (97mm), providing installation flexibility across a wide range of door types.
  • Fire Rated Construction: UL listed under ANSI/UL 10C and CAN/ULC-S104 for fire rated applications, ensuring compliance with fire egress code requirements.
  • ANSI/BHMA Grade 1 Certified: Meets ANSI/BHMA A156.3-2008 Grade 1 standards, the highest commercial grade for exit devices, as well as ANSI/UL 305 and CAN/ULC-S132 certifications.
  • Non-Handed Design: The device is non-handed, simplifying specification, ordering, and installation across varied door configurations without handing concerns.
  • Compact Center Case Dimensions: Center case measures 4-1/4" x 1-3/8" x 2-3/8" with a 3/4" latch throw and 3-3/4" product projection for a low-profile, reliable latching solution.
  • Hollow Metal Door Compatibility: Covers stock hollow metal doors with 161 cutouts for straightforward integration with standard commercial door preparations.
  • Versatile Trim and Electronic Options: Compatible with 210 knob trim (Classroom, Storeroom, Dummy functions) and 230 lever/thumbpiece trim (Classroom function), plus electronic options including RX push pad monitor, CON common connectors, and AX accessible device (UL certified for 5 lb. operating force per 2010 ADA Chapters 404.2.7 and 309.4, and 2013 California Building Code Chapter 11B-309.4).
  • ISO 9001 Quality Management: Designed and manufactured in accordance with ISO 9001 Quality Management System standards for consistent, reliable production quality.

Technical Specifications

  • Series: 22 Series
  • Grade: Grade 1
  • Product Group: Exit Devices and Trim
  • Product Subgroup: Exit Devices - Rim
  • Product Type: Exit Devices - Rim
  • Subcategory: Rim Exit Devices
  • Latch Throw: 3/4"
  • Commercial/Residential: Commercial
  • Stile Type: Wide Stile
  • Center Case Dimensions: 4-1/4" x 1-3/8" x 2-3/8"
  • Wood Door Compatible: No
  • Door Hand Direction: Non-Handed
  • Door Thickness Range: 1-3/4"
  • Product Size: 48"
  • Fire Rating: Yes
  • Product Projection: 3-3/4"
  • Product Style: Push Pads
  • Product Category: Exit Devices and Trim
  • Department: Door Hardware

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Von Duprin Quality?

Von Duprin rim exit devices are built to the most rigorous commercial standards, with the 22F Series earning ANSI/BHMA A156.3-2008 Grade 1 certification and UL listings under ANSI/UL 10C, ANSI/UL 305, CAN/ULC-S104, and CAN/ULC-S132 for comprehensive code compliance. Designed and manufactured under ISO 9001 Quality Management System guidelines, every device delivers consistent, dependable performance. Engineered for demanding commercial applications where fire-rated egress reliability and long-term durability are essential, the Von Duprin 22F Series is a trusted choice for architects, contractors, and facility managers alike.

Product Specs

Series:
22 Series
Grade:
Grade 1
Product Group:
Exit Devices and Trim
Product Subgroup:
Exit Devices - Rim
Product Type:
Exit Devices - Rim
Subcategory:
Rim Exit Devices
Latch Throw:
3/4"
Commercial/Residential:
Commercial
Stile Type:
Wide Stile
Center Case Dimensions:
4-1/4" x 1-3/8" x 2-3/8"
Wood Door Compatible:
No
Door Hand Direction:
Non-Handed
Door Thickness Range:
1-3/4"
Product Size:
48"
Fire Rating:
Yes
Product Projection:
3-3/4"
Product Style:
Push Pads
Product Category:
Exit Devices and Trim
Department:
Door Hardware

Von Duprin 22EO-F 4 689 – Frequently Asked Questions

1) Will the Von Duprin 22F rim exit device fit a wood door?
No. The 22F-4FT is built for hollow metal doors and is not wood door compatible, and it covers stock hollow metal doors with 161 cutouts. If the opening is wood, look at a rim device rated for wood: the Adams Rite 3700 Series is a fire rated narrow stile rim device listed as wood door compatible, and the Adams Rite 8700 Series is the non fire rated version of that.
2) Is the 22F rim exit device approved for a fire rated door opening?
Yes. The 22F is fire rated and UL listed under ANSI/UL 10C and CAN/ULC-S104 for fire hardware, plus ANSI/UL 305 and CAN/ULC-S132 for panic hardware, and it is certified to ANSI/BHMA A156.3-2008 Grade 1. That combination is what a fire rated egress opening needs. Note the F designation matters: a non fire rated 22 device will not pass on a labeled door.
3) Why does the 22F fire rated exit device have no dogging?
Fire rated exit devices cannot be dogged. Dogging holds the latch retracted so the door pushes free, and on a labeled opening the latch has to stay projected to keep the door positively latched in a fire. That is why the 22F-4FT ships less dogging. If you want a door that stays push-open during business hours, that is a non fire rated application, and the electric latch retraction option (QEL) is the fire rated way to hold latches back on a schedule under access control.
4) Can the Von Duprin 22F-4FT be used on a pair of doors?
Yes, on single and double doors, but a double door application needs a mullion. This is a rim device, so it latches into a strike on the frame or on the mullion rather than into the head and threshold. If you cannot use a removable mullion because the opening has to stay clear, a rim device is the wrong type and you need a vertical rod device instead, such as the Hager 4501 concealed vertical rod for wide stile doors.
5) Will the 22F rim device latch into my existing strike?
The latchbolt throws 3/4 inch, and the device projects 3-3/4 inch off the door face with a center case measuring 4-1/4 x 1-3/8 x 2-3/8 inches. A rim device latches into a surface strike on the frame stop, not a mortised ANSI strike, so plan on the strike that goes with the device rather than reusing what is in the frame. Von Duprin publishes trim and strike template indexes for both hollow metal and wood door frames, and those templates are what your installer should work from.
6) What outside trim options work with the Von Duprin 22 Series exit device?
Trim is a separate choice on the order. You can run it exit only with no outside trim, or specify knob (K), lever (L), thumbpiece (TP), night latch (NL), night latch with optional pull (NL-OP), dummy trim (DT), or the blank escutcheon versions of knob, lever and thumbpiece (K-BE, L-BE, TP-BE). On the hardware side that maps to 210 knob trim in Classroom, Storeroom and Dummy functions, and 230 lever or thumbpiece trim in Classroom function. If you pick the L lever option you also choose the lever style: 06, 03 or 17.
7) What do I order to get door position and request to exit signals back to my access control panel?
Signalling is an option you add on the order. The choices are RX request to exit, RX2 double request to exit, LX latch bolt monitor switch, LX-LC latch bolt monitoring low current, LX-RX combined latch monitoring and request to exit, LX-RX-LC the low current version of that, and ALK alarm exit kit. RX tells the panel someone pushed the pad; LX tells it the latch actually moved. For remote unlocking, QEL quiet electric latch retraction pulls the latch back electrically, with QELX as the version for AX devices. CON common connectors are also available for wiring.
8) Is there an ADA compliant version of the Von Duprin 22 exit device?
Yes, the AX accessible device option. AX devices are UL certified for a 5 lb operating force per 2010 ADA Chapters 404.2.7 and 309.4 and 2013 California Building Code Chapter 11B-309.4. If you are specifying for a facility that has to hit that operating force, order the AX version, and if you are also adding electric latch retraction, the matching option is QELX rather than plain QEL.
9) What rim exit device fits a narrow stile aluminum door if the Von Duprin 22F-4FT will not?
The 22F-4FT is a wide stile device and fits stiles as narrow as 3-13/16 inches, which is wider than many aluminum storefront stiles. For narrow stile openings, the Corbin Russwin ED4200 is a Grade 1 36 inch narrow stile rim device for 1-3/4 inch doors that accepts trim, the Falcon 19-R is a Grade 1 36 inch narrow stile exit only device, and the Detex 40 Advantex is a Grade 1 extra heavy duty narrow stile rim device. Confirm the actual stile face on the door before ordering either family.
10) What fire rated rim exit device should I use on a 36 inch door instead of the Von Duprin 22F-4FT?
The 22F-4FT is sized at 48 inches. For a narrower opening, the Marks USA M9900F-36 is a 36 inch fire rated rim exit device, exit only, and the Orca Hardware OED85 is a 36 inch fire rated rim exit device, also exit only. The Arrow FS1250 is a 32 inch fire rated rim device for 1-3/4 inch doors. All three hold the fire rating; they differ from the 22F-4FT in that they are exit only, so an opening needing outside trim needs a device that accepts it.
11) Can I use a Cal-Royal 5500 48 inch rim exit device in place of the Von Duprin 22F-4FT?
Only on a non fire rated opening. The Cal-Royal 5500 is a 48 inch heavy duty rim exit device with a push bar, and it is Grade 2 and not fire rated. The Von Duprin 22F-4FT is Grade 1 and fire rated. On a labeled fire door assembly the 22F-4FT or another fire rated device is what carries the label; the Cal-Royal 5500 covers the same 48 inch width on a standard egress door.
12) Will a Von Duprin 22F-4FT fit a door thicker than 1-3/4 inches, and what handles that instead?
The Von Duprin 22F-4FT is specified for 1-3/4 inch doors. For thicker leaves, the Dormakaba 9300 Series 48 inch wide stile rim device covers 1-3/4 to 2-1/4 inches and the Adams Rite 8800 Series covers 1-3/4 to 2-1/4 inches. Both are Grade 1, and neither is fire rated, so on a labeled thick door confirm the fire listing separately before specifying.
13) What size door does a 48 inch exit device go on, and do I need to cut it down?
The 22F-4FT is the 4 foot pushpad, sized for wide leaves. Von Duprin rim devices are sized to the door width, so the 48 inch bar goes on the wider openings and a narrower leaf takes a shorter device. Measure the actual leaf width before you order the length. If you need a 3 foot bar in the same fire rated rim class, the Marks USA M9900F comes in a 36 inch version as well as a 48 inch.
14) Do I have to specify a hand when ordering the Von Duprin 22F?
The device itself is non handed, so the same chassis works on either swing. You do still pick a handing on the order (RHR or LHR) because the trim and prep follow the door, but you are not stocking two different devices. For a property manager standardizing across a building, non handed means one part number covers openings that swing both ways.
15) What is a good fire rated alternative to the Von Duprin 22F rim exit device?
Among fire rated rim devices, the Marks USA M9900F comes in a 48 inch exit only version, the Dexter ED1000 Series has a Grade 1 fire rated rim device, the Orca OED85 is a 36 inch fire rated rim exit only, and the Sargent 12-8810 is a fire rated Grade 1 wide stile rim device. The Arrow FS1250 is a fire rated 32 inch rim device for 1-3/4 inch doors. What separates the 22F from most of them is the trim and electrification range: knob, lever, thumbpiece and night latch trims plus RX, LX, ALK and QEL options on one platform.
16) I only need a push bar on an exit door with no outside access. Is the 22F overkill?
If the opening is not fire rated, yes, it likely is. Order EO exit only if you still want the 22F for the Grade 1 rating and the trim options later. For a plain non rated exit only bar, the Corbin Russwin ED2200 is a Grade 1 wide stile exit only rim device, the Sargent 3828 is a Grade 1 reversible push bar rim device for 48 inch doors, and Cal-Royal 5500 is a 48 inch Grade 2 push bar rim device. On a labeled fire door none of those substitute for the 22F.
17) Push pad or crossbar exit device, which should I put on a 48 inch door?
The 22F-4FT is a push pad device, which is the current standard on commercial openings: the pad runs the width of the bar and there is no bar to catch a cart or a jacket. Crossbar devices are still made and still sold, for example the CRL Jackson 1095 Series 48 inch crossbar rim device and the Corbin Russwin ED3000 Series 48 inch crossbar, and they are usually chosen to match crossbar devices already on adjacent openings in an older building. Neither of those crossbar devices is fire rated, so on a labeled door the push pad 22F is the one that qualifies.
18) What is the difference between the Von Duprin 22F-4FT and the Dexter ED1000-R-F-EO fire rated rim device?
Both are Grade 1 fire rated rim exit devices for non-wood doors. The Dexter ED1000-R-F-EO is an exit only device with no outside trim function. The Von Duprin 22F-4FT is a 48 inch wide stile device that is non-handed and can be ordered exit only or with knob, lever, thumbpiece, night latch or dummy trim, plus an AX accessible option. For a straight push-to-exit fire door with no outside control, the Dexter covers it; for an opening where the outside side needs a key or lever, the 22F-4FT carries that in the same device.
19) Is a crossbar rim device like the CRL Jackson 1095 or Corbin Russwin ED3200 interchangeable with the Von Duprin 22F-4FT?
Not directly. The Von Duprin 22F-4FT uses a push pad actuator with a 3-3/4 inch projection. The CRL Jackson 1095 is a 48 inch crossbar rim panic device, exit only and wide stile, and the Corbin Russwin ED3200 is a Grade 1 48 inch crossbar rim device for 1-3/4 inch doors. Crossbar devices project differently and mount to a different door prep than a push pad chassis, and neither of those two is fire rated, so they are not a swap onto a labeled door.
20) Is an SDC pressure sense bar or switch bar an alternative to the Von Duprin 22F-4FT?
They solve a different problem. The SDC SureExit PSB560 is a 36 inch pressure sense bar with tri-failsafe technology and the SDC MSB550 is a 36 inch mechanical switch bar that releases an electromagnetic lock; both fit narrow or wide stile and neither is fire rated. Those bars signal a lock to release and carry no latch of their own. The Von Duprin 22F-4FT is a mechanical latching rim device with a 3/4 inch throw and its own latch, fire rated for labeled openings. A magnetic lock release bar is not a drop-in for a latching fire exit device.
21) If I need a night latch function rim device, is the Sargent 8504 the same as ordering the Von Duprin 22F-4FT NL?
Both give a keyed night latch, but the chassis differ. The Sargent 8504 is a Grade 1 narrow stile rim device built specifically in night latch function. The Von Duprin 22F-4FT is a wide stile Grade 1 fire rated device and night latch is one of its ordered trim functions, alongside a night latch cylinder assembly with optional pull. For a narrow stile aluminum door the Sargent 8504 fits the stile; for a labeled wide stile door needing the fire rating, the 22F-4FT night latch build is the one to specify.
22) What finishes does the Von Duprin 22F-4FT exit device come in?
Four: 526 chrome, 622 matte black, 689 aluminum and 695 dark bronze. 689 aluminum is the usual match for existing commercial openings and 695 dark bronze pairs with bronze storefront, so if you are adding a device to a building that already has Von Duprin hardware, match the finish number on the device already installed rather than eyeballing the color.
23) Can I get the prep templates before I order the Von Duprin 22 Series device?
Yes. Von Duprin publishes template indexes for the 22 Series covering hollow metal door prep, hollow metal trims and strikes, wood door prep, and wood door trims and strikes. Pull the hollow metal set for this device, since the 22F-4FT is not wood door compatible. If your shop is prepping doors in advance, those templates give the fabricator the cutouts and strike locations before the hardware arrives.
24) Von Duprin 22F-4FT compared to the BEST Precision 2101 wide stile rim device?
The BEST Precision 2101 is a 36 inch wide stile rim exit device for non-wood doors and is not fire rated. The Von Duprin 22F-4FT is 48 inches, wide stile, Grade 1, fire rated, and non-handed with a 4-1/4 by 1-3/8 by 2-3/8 inch center case. If a facility is standardizing wide stile push pad hardware across both labeled and unlabeled openings, the 22F-4FT covers the labeled doors and matches the wide stile prep.
