WAC Lighting PD4136-MP Kanister LED Multi-Light Pendant, Aluminum with Smoke Glass
The WAC Lighting PD4136-MP Kanister LED Multi-Light Pendant brings an industrial-modern silhouette to any room with three mouth-blown, smoke-gradient glass cylinders suspended at varying heights on black hardware. Built with an Aluminum frame and a concealed Universal Input Voltage Driver (120V-240V-277V), this fixture pairs a High Powered Replaceable LED at 3000K and CRI 90 with smooth ELV/TRIAC dimming. It is ETL & cETL Listed for Damp locations, ADA Compliant, and CEC/Title 24 Compliant, making it a dependable choice for both residential and light-commercial installations.
Key Features
- Layered Glass Design: Three mouth-blown smoke-gradient glass cylinders hang at varying heights, creating a balanced rhythm of form and light.
- Durable Construction: Aluminum construction with black hardware delivers clean, precise lines and long-term durability.
- Adjustable Electrified Cable: Ultra-sleek electrified cable eliminates clunky power wires; height is simple to adjust through push pin connectors on the canopy, and the fixture is sloped ceiling compatible.
- Universal Input Voltage Driver: Concealed 120V-240V-277V driver in the canopy supports broad electrical compatibility across installations.
- Smooth Dimming: Compatible with Electronic Low Voltage (ELV) or TRIAC dimmers for smooth, continuous dimming control.
- High-Performance LED: High Powered Replaceable LED with CRI 90, 3000K color temperature, 1400 lumens, and a Rated Hours life of 50,000.
- Total Wattage: 27.2W energy-efficient LED light source.
Certifications & Compliance
- ETL & cETL Listed for Damp Locations
- ADA Compliant
- CEC and Title 24 Compliant
Technical Specifications
- ADA Compliant: Yes
- Bulb Base: LED Module - Universal Driver
- Bulb Shape: LED Module
- Bulbs Included: Yes
- Dimmable: ELV;TRIAC
- Energy Star: No
- Hardwired or Portable: Hardwired
- Lumens: 1400
- Product Type: Indoor Hanging Lighting
- Safety Rating: ETL;cETL
- Shade/Glass Description: Mouth-blown smoke gradient glass
- Warranty: 5 Years Functional, 2 Years Finish
- Subcategory: Multi-Light Pendant
- CRI: 90
- Beam Spread: Flood
- Voltage: 120-240-277
- Country of Origin: Philippines
- Total Wattage: 27.2
- Style: Modern;Transitional
Typical Applications
- Dining Room and Kitchen Island Lighting
- Entryway and Foyer Statement Fixtures
- Damp-Location Indoor Hanging Installations
- Modern and Transitional Interior Design
- Residential and Light-Commercial Spaces
Why WAC Lighting?
WAC Lighting builds the Kanister pendant with Aluminum construction, mouth-blown smoke-gradient glass, and a concealed Universal Input Voltage Driver for reliable, code-compliant performance. Backed by ETL & cETL Damp-location listings, ADA and CEC/Title 24 compliance, and a 5-Year Functional/2-Year Finish warranty, it delivers dependable, dimmable LED lighting for modern interiors.
Manufacturer Resources
Installation Guide
Product Specs
- ADA Compliant:
- Yes
- Bulb Base:
- LED Module - Universal Driver
- Bulb Shape:
- LED Module
- Bulbs Included:
- Yes
- Collection:
- Kanister
- Dimmable:
- ELV;TRIAC
- Energy Star:
- No
- Hardwired or Portable:
- Hardwired
- Lumens:
- 1400
- Product Type:
- Indoor Hanging Lighting
- Safety Rating:
- ETL;cETL
- Shade/Glass Description:
- Mouth-blown smoke gradient glass
- Subcategory:
- Multi-Light Pendant
- Avg Rated Hours:
- 50000
- CRI:
- 90
- Beam Spread Angle:
- Flood
- Product Voltage:
- 120-240-277
- Product Material:
- Aluminum
- Location Rating:
- Damp
- Total Wattage:
- 27.2
- Light Temperature:
- 3000
- Product Style:
- Modern;Transitional
- Department:
- Electrical
WAC Lighting PD413603R-TWA-BKSM – Frequently Asked Questions
1) Can the WAC Kanister PD4136 pendant run on 277V commercial power, or is it 120V only?
The Kanister multi-light pendant uses a concealed universal input voltage driver rated 120V-240V-277V, so the same fixture works on residential 120V and on 277V commercial lighting circuits with no separate transformer or alternate part number. It is a hardwired fixture, not a plug-in, so it needs a junction box and a licensed connection.
2) Will the Kanister LED pendant work with the dimmers already in my building?
Dimming on the Kanister pendant is ELV or TRIAC. A standard forward-phase TRIAC wall dimmer or an electronic low voltage dimmer will give smooth control; 0-10V and DALI controls will not drive it. If your panel or room controls are 0-10V, you need a different fixture family.
3) Is the Kanister pendant OK over a kitchen sink or in a covered porch or bathroom?
Location rating is Damp, with ETL and cETL listings. That covers bathrooms, over a kitchen sink, and covered exterior areas that never see direct water. It is not wet-rated, so do not hang it where rain or spray can hit the glass.
4) Can the Kanister multi-light pendant be hung on a sloped ceiling?
Yes. The Kanister hangs on an electrified cable and is sloped ceiling compatible, and hanging height is set through push pin connectors on the canopy, so you adjust each of the three glass cylinders on site rather than ordering a fixed stem length.
5) Will the Kanister pendant pass a California Title 24 inspection and ADA review on a commercial job?
It is listed ADA compliant and CEC/Title 24 compliant, which is what matters on California residential and light-commercial permits, and it carries ETL and cETL listings for the US and Canada. It is not Energy Star rated, so if a utility rebate program requires Energy Star specifically, this will not qualify.
6) What color and quality of light does the WAC Kanister PD4136 put out, and is it bright enough for a kitchen island?
Output is 1400 lumens total at 27.2W, 3000K warm white, CRI 90, with a flood beam spread. That is accent and ambient-level light for a dining table or island, not task-level illumination for a whole kitchen, so plan recessed or undercabinet light alongside it. CRI 90 keeps finishes and food color accurate.
7) Does the Kanister pendant come with the LED, or do I have to buy lamps, and can the LED be replaced later?
The LED comes installed, so nothing else needs to be ordered to light it. It is a high powered replaceable LED module driven by the universal driver, rated 50,000 hours, so at end of life the module can be swapped instead of the whole pendant. There is no screw-base socket, so standard A-lamps will not fit it.
8) What glass options does the Kanister PD4136 pendant come in?
Two glass choices, both on black hardware: Black with Smoke Glass and Black with White Glass. The smoke version is mouth-blown smoke gradient glass, which reads darker and shows the LED more directly; the white glass diffuses more and gives less visible glare over a dining table.
9) Is there an installation guide for the WAC Kanister PD4136 pendant?
Yes, WAC publishes an installation guide for the Kanister pendant and it is available as a PDF with the product data. It covers canopy mounting, the push pin cable adjustment, and the driver connections for the 120V/240V/277V input.
10) What is the Kanister pendant frame made of, and will it hold up in a rental or hospitality space?
The frame is aluminum with black hardware, and the shades are mouth-blown glass. Aluminum does not rust, which is part of why the fixture carries a damp rating for bathrooms and covered areas. The glass cylinders are the vulnerable part in high-traffic or turnover spaces, so keep the mounting height above head level in corridors and entries.
