WAC Lighting Pop-in 4in 5-CCT LED Recessed Downlight, 12W 1,000LM, Wet Rated
The WAC Lighting Pop-in is a low-profile, shallow-regressed 4in LED recessed downlight with a driver and electrical connection junction box built directly onto the fixture for a fast, single-piece installation. Delivering 1,000+ lumens from a 12W high-powered LED module at CRI 90, this fixture features an on-board 5-CCT selectable switch to toggle between 2700K, 3000K, 3500K, 4000K, and 5000K without swapping bulbs. It is ETL & cETL listed under UL #1598 for Dry, Damp, and Wet Locations, making it suitable for a wide range of residential and light commercial ceiling installations.
Key Features
- Compact Cutout: Installs in a 4.13in cutout and fits ceiling thicknesses between 0.5in and 1.5in, with retention clips holding the light engine securely in place.
- Durable Construction: Die-cast aluminum housing with a frosted TIR lens for a regressed, glare-reducing beam that mimics the look of a traditional recessed downlight.
- Integrated Driver Design: Remote driver and junction box are pre-attached to the fixture, simplifying wiring and reducing installation time in new construction or remodel applications.
- Universal Voltage Input: Universal input driver operates across 120V-220V-277V, giving installers flexibility across circuit types.
- High Light Output: 12W LED module delivers 1,000 delivered lumens at CRI 90 with a 50,000-hour rated lifespan.
- 5-CCT Selectable: Onboard switch toggles between 2700K Warm, 3000K Warm White, 3500K White, 4000K Cool White, and 5000K Natural White, accessible before, during, or after installation by removing the twist-lock diffuser.
- Wet-Location Rated: ETL & cETL listed under UL #1598 for Dry, Damp, and Wet Locations, and Airtight/IC-Rated for direct contact with insulation.
- Smooth Dimming: Compatible with ELV dimmers (down to 10%) and TRIAC dimmers (down to 5%) for continuous, flicker-free dimming.
Certifications & Compliance
- ETL & cETL Listed (UL #1598)
- Suitable for Dry, Damp, and Wet Locations
- Airtight and IC-Rated for Insulation Contact
- CEC and Title 24 JA8-2016 Compliant
Technical Specifications
- Bulb Base: LED Module - Universal Driver
- Bulbs Included: Yes
- Dimmable: ELV;TRIAC
- Energy Star: No
- Hardwired or Portable: Hardwired
- Number of Bulbs: 1
- Product Type: Recessed Lighting Kit
- Safety Rating: ETL, cETL, CSA CAN, Title 24
- Shade/Glass Description: Frosted Acrylic Diffuser
- Warranty: 5 Years Functional, 2 Years Finish
- Subcategory: 4" LED Kit
- Beam Spread: Flood
- Voltage: 120-240-277
- Country of Origin: Thailand
- Location Rating: Wet
- Total Wattage: 12
- Color Temperature: 2700-3000-3500-4500-5000
- Style: Functional
Typical Applications
- Residential and Light Commercial Recessed Lighting
- New Construction and Remodel Ceiling Installations
- Kitchens, Living Rooms, and Hallways
- Bathrooms and Wet-Location Areas
- Insulated (IC-Rated) Ceiling Applications
Why WAC Lighting?
WAC Lighting builds the Pop-in around a die-cast aluminum housing, an integrated driver and junction box, and ETL & cETL listing for Dry, Damp, and Wet Locations, giving installers a code-compliant fixture that is ready for demanding residential and commercial ceilings. Backed by a 5-year functional and 2-year finish warranty, it is engineered for reliable, low-maintenance performance across new construction and remodel projects alike.
Manufacturer Resources
Specification Sheet
Product Specs
- Bulb Base:
- LED Module - Universal Driver
- Bulb Shape:
- LED Module
- Bulbs Included:
- Yes
- Collection:
- Pop-in
- Dimmable:
- ELV;TRIAC
- Energy Star:
- No
- Hardwired or Portable:
- Hardwired
- Number of Bulbs:
- 1
- Product Type:
- Downlight
- Safety Rating:
- ETL, cETL, CSA CAN, Title 24
- Shade/Glass Description:
- Frosted Acrylic Diffuser
- Subcategory:
- 4" LED Kit
- Avg Rated Hours:
- 50000
- Beam Spread Angle:
- Flood
- Product Voltage:
- 120-240-277
- Product Material:
- Aluminum
- Location Rating:
- Wet
- Total Wattage:
- 12
- Light Temperature:
- 2700-3000-3500-4500-5000
- Product Style:
- Functional
- Mounting Method:
- Ceiling
- Department:
- Electrical
- Product Group:
- Lighting
- Product Subgroup:
- Light Fixtures
WAC Lighting R4DSDR2-F9CS-BK – Frequently Asked Questions
1) What size cutout does the WAC Pop-in 4 inch recessed downlight need, and what ceiling thickness will it fit?
The Pop-in drops into a 4.13 inch cutout and fits ceiling thicknesses from 0.5 inch to 1.5 inch, with retention clips gripping the light engine. That covers typical 1/2 inch and 5/8 inch drywall, single or double layer. If your ceiling is thicker than 1.5 inches, the clips will not seat properly and this is the wrong fixture.
2) Can I use the WAC Pop-in downlight in a shower or on a covered exterior porch ceiling?
Yes. The Pop-in is ETL and cETL listed under UL #1598 for Dry, Damp, and Wet Locations, so shower ceilings, covered porches, and soffits are all within its rating. It is also Airtight and IC-Rated, meaning it can sit in direct contact with insulation without a separate housing box.
3) Do I need a separate junction box or remote driver for the WAC Pop-in recessed light?
No. The driver and the electrical connection junction box are built onto the fixture, so you cut the hole, land your line-voltage wiring in the attached box, and push the light engine in. No rough-in can and no remote driver to find a place for, which is why it works for both new construction and remodel ceilings.
4) Will the WAC Pop-in run on a 277V commercial circuit?
Yes. The Pop-in uses a universal input driver rated 120V-240V-277V, so the same fixture can be ordered for a residential 120V branch circuit or a 277V lighting circuit in a light commercial building. No separate 277V version to specify.
5) How do I set the color temperature on the WAC Pop-in, and can I change it after it is installed?
There is an onboard 5-CCT switch covering 2700K warm, 3000K warm white, 3500K white, 4000K cool white, and 5000K natural white. You can reach it before, during, or after installation by twisting off the lock diffuser, so a property manager can match a fixture to the rest of a room after the fact instead of pulling and reordering.
6) Does the WAC Pop-in meet California Title 24 for new residential work?
Yes. The Pop-in is CEC listed and Title 24 JA8-2016 compliant, which is what inspectors look for on California residential recessed lighting. Title 24 also appears on its safety rating listing alongside ETL, cETL, and CSA CAN.
7) What trim finishes and trim sizes does the WAC Pop-in come in?
Two finishes, black and white, in two trim sizes, 4.75 inch and 5 inch. Both finishes are offered in both trim sizes. Pick the 5 inch trim if you are covering a slightly oversized or ragged existing hole, and the 4.75 inch for a tighter reveal on a fresh cut.
8) Should I use a canless downlight like the WAC Pop-in or a traditional recessed can and trim?
A canless fixture like the Pop-in makes sense when ceiling depth is tight or you are retrofitting from below without attic access, since the housing, driver, and junction box arrive as one piece and go in through the 4.13 inch hole. A traditional can plus separate trim is still the better route when you want to swap trim styles later or need a lamp you can change independently. For insulated ceilings, note the Pop-in is already Airtight and IC-Rated, so no separate IC housing is required.
9) Does the WAC Pop-in need a bulb, and what is the lens made of?
No bulb to buy. The LED module is integral and included, one source per fixture. Light passes through a frosted TIR lens with a frosted acrylic diffuser, and the engine is regressed slightly into a die-cast aluminum housing, which is what keeps the glare down and gives it the look of a conventional can light rather than a flat wafer.
