WAC Lighting R2F-R FQ 2in Remodel Recessed Housing, Galvanized Steel

WAC Lighting R2F-R FQ 2in Remodel Recessed Housing, Galvanized Steel

(No reviews yet) Write a Review

Model: R2FBRT-1
From the FQ Collection
$107.95

In Stock (leaves warehouse same day if ordered before 3pm ET)

$107.95
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

WAC Lighting R2F-R FQ 2in Remodel Recessed Housing, Galvanized Steel

The WAC Lighting R2F-R is a 2" remodel recessed housing from the FQ Recessed series, a complete line of high performance LED luminaires engineered for outstanding functionality and quality. Built from 20 Gauge Galvanized Steel, this hardwired housing is ETL & cETL rated for Dry locations and supports 120-240-277 voltage, making it a dependable foundation for round and square, trimmed and trimless FQ trim options.

Key Features

  • Trade Size: 2" housing sized for remodel installations where retrofit access is limited.
  • Durable Construction: 20 Gauge Galvanized Steel housing body for long-term structural reliability.
  • Hardwired Installation: Designed for permanent hardwired connection for a clean, code-compliant install.
  • Voltage Rating: Compatible with 120-240-277 voltage systems for flexible electrical service applications.
  • Dimmable Control: Compatible with 0-10V, ELV, and TRIAC dimming for smooth light-level adjustment.
  • Glare Control Design: Part of the FQ series featuring 30° shielding, 35° vertical tilting, and 360° horizontal rotation for uniform floor-to-ceiling wall washing.
  • Location Rating: Rated for Dry locations only.

Certifications & Compliance

  • ETL Listed
  • cETL Listed
  • Rated for Dry Locations

Technical Specifications

  • Collection: FQ
  • Dimmable: 0-10V,ELV;TRIAC
  • Energy Star: No
  • Hardwired or Portable: Hardwired
  • Product Type: Recessed Housings
  • Safety Rating: ETL;cETL
  • Warranty: 5 Years Functional
  • Subcategory: 2" Housing
  • Voltage: 120-240-277
  • Material: 20 Gauge Galvanized Steel
  • Country of Origin: Thailand
  • Location Rating: Dry

Typical Applications

  • Remodel and Retrofit Recessed Lighting Projects
  • Residential and Commercial Ceiling Installations
  • Floor-to-Ceiling Wall Washing Applications
  • Dry-Location Interior Lighting Layouts
  • Dimmable Lighting Control Systems

Why WAC Lighting?

WAC Lighting builds the FQ Recessed series on a 20 Gauge Galvanized Steel housing with ETL & cETL Dry-location ratings and a 5-year functional warranty, giving installers a dependable, code-compliant platform for professional recessed lighting work. Multiple power levels and a full range of trim styles make the R2F-R housing a versatile, easy-to-order foundation for remodel projects.

Product Specs

Collection:
FQ
Dimmable:
0-10V,ELV;TRIAC
Energy Star:
No
Hardwired or Portable:
Hardwired
Product Type:
Recessed Housings
Safety Rating:
ETL;cETL
Subcategory:
2" Housing
Product Voltage:
120-240-277
Product Material:
20 Gauge Galvanized Steel
Location Rating:
Dry
Product Style:
Functional
Department:
Electrical

WAC Lighting R2FBRT-1 – Frequently Asked Questions

1) Can the WAC Lighting R2F-R 2 inch housing be installed in an existing finished ceiling?
That is what it is built for. The R2F-R is the remodel version of the FQ 2 inch recessed housing, meant to go into an existing finished ceiling through the cut opening rather than being nailed to joists before drywall. It is a hardwired housing, so you need branch circuit conductors brought to the location and accessible from the ceiling cavity.
2) Can I put this 2 inch recessed housing in a bathroom or outside under a soffit?
No. The R2F-R carries a Dry location rating only, so keep it out of showers, tub areas, covered exterior soffits and any location subject to moisture or condensation. For those spots you need a wet or damp rated housing instead.
3) What dimmers work with the WAC FQ 2 inch remodel housing?
It accepts 0-10V, ELV and TRIAC dimming, so it fits either a line-voltage ELV/TRIAC wall dimmer or a 0-10V control system on a commercial lighting panel. Match the driver control method to the dimmer you already have on the circuit before you commit a whole floor to one approach.
4) What do I have to specify when ordering the R2F-R besides the housing itself?
Two choices drive the order: trim style and output. Trimmed is model R2FBRT; trimless comes as R2FRRL (round) or R2FSRL (square). Each is offered at 15W, 21W and 25W. Trimless versions need to be set in before the ceiling is mudded and finished, so decide that early in a remodel sequence rather than after the drywall work is closed out.
5) Is there a square option, or is the FQ 2 inch only round?
Both shapes are available. R2FSRL is the square trimless unit and R2FRRL is the round trimless; the trimmed R2FBRT covers the trimmed option. All three come at 15W, 21W and 25W, so you can mix square and round apertures on one job at matched output.
6) Is the WAC R2F-R listed for commercial code inspection?
It is ETL and cETL Listed, which covers both US and Canadian installations. Combined with the Dry location rating, that is what an inspector will look for on an interior hardwired recessed install.
7) Is a 2 inch aperture downlight bright enough for wall washing in a lobby or corridor?
The FQ series is built for it. The optics give 30 degrees of shielding with 35 degrees of vertical tilt and 360 degrees of horizontal rotation, which is how you get even floor-to-ceiling coverage off a small aperture. Choose the 25W variant where throw distance or ceiling height is greater, 15W for tighter residential-scale spaces.
8) How durable is the housing for a multi-family or institutional job where it sits in the ceiling for decades?
The body is 20 gauge galvanized steel rather than stamped aluminum or plastic, which holds its shape during install and resists corrosion in a ceiling cavity over the long run. That construction is consistent across all nine trim and wattage combinations.
9) Does this WAC housing qualify for an Energy Star rebate program?
No. The R2F-R is not Energy Star qualified, so if your utility or municipal incentive requires an Energy Star listed luminaire, this housing will not satisfy that line item. It is still ETL and cETL Listed for code purposes.
