WAC Lighting LU-24DC Undercabinet LED Remote Power Supply, 12VDC

WAC Lighting LU-24DC Undercabinet LED Remote Power Supply, 12VDC

(No reviews yet) Write a Review

Model: LU-24DC060-UNV-RB2
From the Undercabinet Strip Collection

In Stock (leaves warehouse same day if ordered before 3pm ET)

$141.95
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

WAC Lighting LU-24DC Undercabinet LED Remote Power Supply, 12VDC

The WAC Lighting LU-24DC is a remote plug & play power supply engineered for WAC undercabinet LED linear strip light systems, delivering a clean architectural look for kitchen and cabinet lighting applications. This Low Voltage Class 2 electronic transformer accepts universal 120V-277V input and outputs 12VDC with a max load of 60W or 96W, and it is rated IP44 for Dry or Damp interior locations. Backed by ETL, cETL UL #2108 listing, it's built to power extended undercabinet strip runs reliably and safely.

Key Features

  • Universal Input Voltage: 120V-277V input, 12VDC output with max load of 60W or 96W for flexible power supply sizing.
  • Extended Run Length: Supports up to 18FT max run on the 96W power supply and 12FT max run on the 60W power supply.
  • Plug & Play Connection: Includes a 72" cord with a quick connect for fast, tool-free hookup to the lighting system.
  • Remote-Ready Housing: Features 5 electrical knockouts and a housing designed for electrical connections.
  • Smooth Dimming Compatibility: Works with electronic low voltage (ELV) or TRIAC (standard LED/CFL) dimmers, dimming down to 10%.
  • Built-In Circuit Protection: Inherently protected and power limited with auto reset, soft start, and short and overload circuit protection to guard against normal and abnormal short circuits.
  • Soft Start Feature: Delays abrupt inrush current to the lamp, extending lamp life.
  • Steel Construction: Durable steel housing supports long-term reliability in undercabinet installations.

Certifications & Compliance

  • ETL, cETL UL #2108 Listed
  • IP44 Rated for Dry or Damp Interior Locations

Technical Specifications

  • ADA Compliant: Yes
  • Collection: Undercabinet Strip
  • Energy Star: No
  • Hardwired or Portable: Plugin
  • Safety Rating: ETL, cETL, IP44
  • Warranty: 5 Years Functional
  • Material: Steel
  • Country of Origin: China
  • Style: Functional
  • Mounting: Ceiling/Wall;Any

Typical Applications

  • Kitchen Undercabinet Lighting
  • Cabinet and Shelving Accent Lighting
  • Residential and Commercial Millwork Lighting
  • Dry and Damp Interior Locations
  • WAC Lighting Undercabinet Strip Light Systems

Why WAC Lighting?

WAC Lighting engineers this remote power supply with built-in soft start, auto reset, and short/overload circuit protection to keep undercabinet LED strip systems running safely and reliably. With ETL, cETL UL #2108 listing, an IP44 rating for Dry or Damp locations, and a 5-Year Functional Warranty, it's a code-compliant choice for professional electrical and lighting installations.

Product Specs

ADA Compliant:
Yes
Collection:
Undercabinet Strip
Energy Star:
No
Hardwired or Portable:
Plugin
Product Type:
Undercabinet Lighting
Safety Rating:
ETL, cETL, IP44
Subcategory:
Transformer
Product Material:
Steel
Location Rating:
Damp
Product Style:
Functional
Mounting Method:
Ceiling/Wall;Any

WAC Lighting LU-24DC060-UNV-RB2 – Frequently Asked Questions

1) Should I order the 60W or 96W WAC LU-24DC power supply for my undercabinet strip run?
Pick by run length. The 96W version of the LU-24DC drives up to 18 feet of WAC undercabinet LED strip; the 60W version tops out at 12 feet. Those are the only two wattages offered, so a continuous run longer than 18 feet needs a second supply.
2) Will the WAC LU-24DC run on a 277V commercial circuit?
Yes. The LU-24DC takes universal 120V to 277V input, so it works on standard residential 120V and on 277V commercial lighting circuits, and outputs 12VDC as a Class 2 low voltage supply.
3) Can I put the WAC LU-24DC remote power supply on a dimmer?
It dims with electronic low voltage (ELV) or TRIAC dimmers, the standard LED/CFL type, down to 10 percent. The dimmer goes on the 120V-277V line side, not on the 12VDC output.
4) Is the LU-24DC hardwired or does it plug in?
It is a plug-in unit. The LU-24DC ships with a 72 inch cord and a quick connect for tool-free hookup to the strip system, and the steel housing has 5 electrical knockouts for making the connections.
5) Can the LU-24DC be mounted inside a cabinet near a sink or in a damp area?
The LU-24DC carries an IP44 rating for dry or damp interior locations, so inside cabinetry or a kitchen base near a sink is acceptable. It is not rated for wet locations or exterior use.
6) Is the WAC LU-24DC listed for a commercial inspection?
It is ETL and cETL listed to UL #2108, the low voltage lighting systems standard, which covers both US and Canadian jobs. It is not Energy Star rated.
7) Will the LU-24DC work with any 12V LED tape, or only WAC strip?
It is built for WAC undercabinet LED linear strip light systems and uses WAC's quick connect on the 72 inch cord, so it lands plug and play on that strip. Output is 12VDC Class 2, so matching WAC strip from the Undercabinet Strip collection is the straightforward pairing.
8) What protects the strip lights if the low voltage wiring shorts out?
The LU-24DC is inherently protected and power limited, with short circuit and overload protection plus auto reset, so it recovers once the fault is cleared instead of needing replacement. A soft start feature delays inrush current at switch-on, which helps lamp life.
9) Where can I mount the LU-24DC transformer?
Mounting is unrestricted by orientation, listed as ceiling/wall or any position, which is what lets it sit remote from the fixtures inside a cabinet, above a ceiling, or in millwork. Keep it in a dry or damp interior spot.
