Metallics JHFW117 Washers 3/8 X 1-1/2 Octagnl St-zn (Jar 100)

The JHFW117 is a 3/8 inch octagonal washer, so it seats on 3/8-16 threaded rod or 3/8 inch bolts, the size most commonly used for hanging strut, trapeze, and conduit supports. Overall it measures 1-1/2 inches across the flats, giving a much larger bearing face than a standard 3/8 flat washer.

The wide 1-1/2 inch octagon spreads load over a bigger area than a standard round flat washer, which is what you want when the rod bears on strut, wood, sheet metal, or a slotted channel where a small washer would pull through or dimple the material. The flats also give a wrench or pliers something to hold while you run the nut up. For straight bolt-to-steel connections where load spreading is not the issue, a plain round flat washer is the cheaper choice.

They are zinc plated steel, which handles indoor and normally dry or damp interior locations fine. Zinc plating is a sacrificial coating, not stainless, so for direct exposure to weather, wet process areas, or corrosive atmospheres you should step up to hot dip galvanized or stainless hardware instead.

They are not electrical-only. Metallics lists the JHFW117 for the electrical, plumbing, heating and air conditioning trades, so the same jar covers conduit and strut work, pipe hanger rod, and duct or equipment supports wherever a 3/8 rod needs a wide bearing washer. That makes it a reasonable standardization item for an MRO crib serving all three trades.

Each jar holds 100 of the 3/8 x 1-1/2 octagonal zinc plated steel washers, packed in a jar rather than a bag, which keeps them from scattering in a van drawer or on a cart. Jar weight is 2.37 lbs.

Origin is listed as multiple, meaning Metallics sources the JHFW117 from more than one country, so the marking on a given jar can vary. If a job requires documented single-source or domestic origin, this part will not satisfy that requirement.
