Wiremold Steel Fixture Box for 500 & 700 Series Raceway - White, 1.0 in Deep, 23.75 cu in

Wiremold Steel Fixture Box for 500 & 700 Series Raceway - White, 1.0 in Deep, 23.75 cu in

(No reviews yet) Write a Review

Model: 5738AWH
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$23.61
$21.28
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Wiremold 500 & 700 Series Steel Fixture Box

Professional electrical fixture mounting solution for raceway systems

The Wiremold 500 & 700 Series Steel Fixture Box provides reliable mounting and electrical connection capabilities for fixture installations in raceway applications. Constructed from durable steel with a clean white finish, this fixture box offers 23.75 cubic inches of volume in a compact 1.0-inch deep profile, making it ideal for professional electrical installations where space efficiency and reliable performance are essential.

Professional Features & Benefits

  • Steel Construction: Provides exceptional durability and long-term reliability for demanding electrical applications
  • White Finish: Delivers a clean, professional appearance that integrates seamlessly with most interior environments
  • 1.0-inch Depth: Compact profile maximizes installation flexibility while maintaining adequate wiring space
  • 23.75 Cubic Inch Volume: Offers ample space for fixture connections and wire management in a space-efficient design
  • 5.5-inch Height: Provides optimal mounting dimensions for standard fixture applications
  • 500 & 700 Series Compatibility: Designed specifically for seamless integration with Wiremold raceway systems

Technical Specifications

  • Product Color: White
  • Product Depth: 1.0 in
  • Product Height: 5.5 in
  • Product Material: Steel
  • Product Volume: 23.75
  • Department: Electrical

Professional Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Educational Facilities
  • Healthcare Environments
  • Industrial Facilities
  • Residential Multi-Unit Properties
  • Professional Service Centers

Why Choose Professional Quality?

This steel fixture box delivers the reliability and durability required for professional electrical installations. The robust steel construction and precise manufacturing ensure long-term performance, while the compact design and generous volume provide the flexibility needed for efficient fixture mounting in raceway applications.

Manufacturer Resources

Product Specs

Product Color:
White
Product Depth:
1.0 in
Product Height:
5.5 in
Product Material:
Steel
Product Volume:
23.75
Department:
Electrical
Product Group:
Wiring Devices
Product Type:
Boxes & Enclouseres

Wiremold 5738AWH – Frequently Asked Questions

1) What size fixture boxes does the Wiremold 500/700 Series steel fixture box come in?
Three diameters: 4-3/4 inch (5738WH), 5-1/2 inch (5738AWH), and 6-3/8 inch (5739WH). All three are white steel. Pick the diameter off the fixture canopy you are hanging, since the canopy has to cover the box rim cleanly on a surface-mounted raceway run.
2) Will a Wiremold 5738 fixture box work with 500 series raceway, or only 700?
Both. The 5738 family of steel fixture boxes is made for Wiremold 500 and 700 series surface raceway, so a single box covers either run. That matters on a retrofit where an older 500 run is being extended with 700 - you do not need a different box for each.
3) How much wire volume does the Wiremold 5738 fixture box give me for box fill?
23.75 cubic inches. That is the number you run your box fill calculation against when you count conductors, the fixture leads, and any grounding or device allowances on the outlet.
4) How far does the Wiremold surface fixture box stick out from the ceiling or wall?
One inch deep. On an exposed surface raceway run in an office, classroom, or corridor, that keeps the box close to the finished surface instead of hanging down like a standard 4-inch square box on a bracket. The listed 5.5 inch height is the box body dimension.
5) Is the Wiremold 500/700 fixture box steel or plastic?
Steel, finished in white. Steel is what you want where the raceway is metal and the box is part of the equipment grounding path, and it holds a fixture load better than a nonmetallic surface box in a healthcare corridor, school, or industrial bay.
6) Does the white finish on the Wiremold fixture box match white 500 and 700 raceway?
All three sizes are supplied in white, the same finish family as white Wiremold 500 and 700 series raceway, so the box, the run, and the fittings read as one line across a ceiling. There is no other color on the 5738/5739 boxes, so a run in ivory or metallic will not match here.
