Yale Residential Yale YH Collection Oxford Passage Door Knobset YR10XF

Yale YH Collection Oxford Passage Door Knob Set

(No reviews yet) Write a Review

Model: YR10XF-619
From the Oxford Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$36.60
$21.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

YALE YH COLLECTION YR10XF OXFORD PASSAGE DOOR KNOB SET WITH ROUND ROSE OVERVIEW

Superior light commercial quality with push button locking, removable knobs for simple re-keying, and a lifetime limited finish and mechanical warranty.

The YH Collection continues a legacy of distinctive design, high manufacturing standards and demanding performance started by Linus Yale in the mid -19th century. The YH Collection leverages years of engineering refinement with artful execution to offer a series of ANSI Grade 2 superior light commercial quality locks that will beautifully serve any home for generations. They offer superior functionality such as push-button locking and removable knobs for simple re-keying.

PASSAGE FUNCTIONS

  • Ideal for closets, hallways or rooms where no locking mechanism is needed
  • Box Contents: 2x Knobss, 2x rose, interior chasis, strike plate, 4x screws, latch, exterior chasis

FEATURES & BENEFITS

  • Exceeds criteria for ANSI/BHMA A156.2 Grade 2 certification
  • Constructed from quality materials with a focus on durability
  • Easy Install Mounting System — Square Spindle Simplifies Installation - Knobs, Levers
  • Pre-Installed Mounting Screws
  • Concealed Mounting Screws — Clean Upgraded Look
  • Provide easy re-keying
  • Reduces wear and provides smooth operation
  • Limited Lifetime Mechanical and Finish Warranty

DOWNLOADS

Manufacturer Resources

Product Specs

Series:
YH Collection
Collection:
Oxford
Features:
Concealed Screws
Edge Bore:
1"
Warranty:
Limited Lifetime Mechanical
Keyed Function:
Non-Keyed
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Knobsets
Subcategory:
Residential Door Knobs
Cross Bore:
2-1/8"
Keyed:
No
Commercial/Residential:
Residential
Handle Type:
Knob
Lock Function:
Passage
Grade:
Grade 2
Product Attribute:
Cylindrical Locks
Tags:
door knobs and locks
Product Function:
Passage/Hall/Closet
Door Thickness Range:
1-3/8" to 1-3/4"
Product Design:
Round
Mounting Method:
Surface
Product Category:
Mechanical Locks
Product Substrate:
Metal
Department:
Door Hardware

Yale Residential YR10XF-619 – Frequently Asked Questions

1) Will the Yale YH Collection Oxford passage knob fit a 1-3/8 inch interior door?
Yes. The Oxford passage knobset covers doors from 1-3/8 to 1-3/4 inches, so it works on both older interior doors and standard 1-3/4 inch stock without any spacer or extension kit. Anything thicker than 1-3/4 needs a different lock.
2) What door prep does the Yale Oxford knobset need, and will it drop into an existing knob bore?
It takes the standard bored prep: a 2-1/8 inch cross bore through the face of the door and a 1 inch edge bore for the latch. That is the same prep almost every residential knob or lever sits in, so if you are pulling an old cylindrical knob off, the holes are already there. No new drilling on a like-for-like swap.
3) Does the Yale Oxford passage knob lock or take a key?
No, and that is the point of it. Passage function means both knobs always turn and the latch is the only thing holding the door. There is no cylinder, no key, no thumbturn and no push button on this one. Hall, closet, and pantry doors are what it is for. If you need the door to lock from inside for a bath or bedroom, buy a privacy set instead, and for an exterior or office door you want a keyed entrance lock.
4) What is the closest equivalent to the Yale YH Collection Oxford YR10XF passage knob set from another brand?
The Dexter C2000 Series passage knob (DEX-C2000-PASS-KNB) is the nearest match. Both are Grade 2 non-keyed passage/hall/closet cylindrical knob locks, and both fit doors 1-3/8 inch to 1-3/4 inch thick. The Dexter uses a ball knob and is described as non-clutching; the Oxford YR10XF uses a round-design knob with concealed screws. Corbin Russwin CK4410 is a second option at the same Grade 2 passage function and the same 1-3/8 inch to 1-3/4 inch door thickness range, with a Global knob.
5) I need a fire rated passage knob lock for a corridor door - what should I use?
The Falcon W101 is a Grade 2 medium duty cylindrical knob lock in the passage/closet latch function with a 2-3/4 inch backset, and it carries a fire rating. The Falcon X101 is the Grade 1 heavy duty fire rated passage knobset in the same family. Both are the ones to specify when the opening is a rated assembly.
6) The bedroom and bathroom doors need to lock - what takes the place of a passage knob there?
A passage knob has no locking mechanism, so a privacy set is the correct part for bed and bath. Dexter C2000 (DEX-C2000-PRIV-KNB) is a Grade 2 privacy/bed/bath cylindrical ball knob lock for doors 1-3/8 inch to 1-3/4 inch thick, matching the Yale Oxford YR10XF grade and door range. Cal-Royal BER20 is a Grade 3 privacy knob lock with brass trim for the same door thickness range, and Pamex FTF10 is a Grade 3 Baron privacy knob lockset.
7) Which knob set do I order for an exterior or office door that has to take a key?
Passage knobs are non-keyed, so a keyed function is a different part. Dexter C2000 (DEX-C2000-ENTR-KNB) is a Grade 2 keyed entry/office cylindrical ball knob lock for doors 1-3/8 inch to 1-3/4 inch thick. Corbin Russwin CK4851 is a Grade 1 entrance/office cylindrical lock with a Global knob and conventional cylinder for 1-3/8 inch to 2 inch doors. Callan Edgewood (CLN-G2KE1001) is a Grade 2 entrance knobset.
8) Is a dummy knob the same as a passage knob?
No. A passage knob such as the Yale Oxford YR10XF operates a latch, so the knob turns and retracts a bolt into a strike. A dummy is fixed trim with no latch: the BEST 6K single dummy trim (BEST-6K-1DT) is a Grade 2 medium duty non-keyed dummy, the Schlage A170 is a Grade 2 heavy duty single dummy trim, and Cal-Royal BA40 is a dummy knob for 1-3/8 inch to 1-3/4 inch doors. Order a dummy only for an inactive leaf or a door that is pulled, not latched.
9) Is a Grade 2 knob strong enough for apartment turnover or light commercial use?
Grade 2 under ANSI/BHMA A156.2 is the middle tier, and Yale rates the YH Collection as light commercial. For hallway and closet doors in multi-family or an office suite it holds up fine. On a heavy-traffic institutional corridor, step up to a Grade 1 passage knob such as the Corbin Russwin CK4310 or the Falcon X101.
10) What comes in the box with the Yale Oxford passage knobset, and do I need to buy a latch or strike separately?
Everything for one door is in the carton: two knobs, two roses, interior and exterior chassis, the latch, a strike plate, and four screws. The mounting screws come pre-installed and the spindle is square, so it goes together without fishing parts loose. Nothing else to order unless the frame needs a different strike.
11) What finishes does the Yale Oxford passage knob come in for matching other doors in a building?
Four finishes: 619 satin nickel, 605 polished brass, 609 antique brass, and 10BP oil rubbed bronze permanent. Those are standard BHMA finish codes, so 619 and 605 will line up with the rest of the hardware on the opening if it is specified the same way. The 10BP is a permanent coated bronze rather than a living finish, so it stays put instead of wearing through at the grip.
12) I need a knob on a door that does not move, like a closet false door. Is the Yale Oxford passage set right?
No. The passage set includes a working latch and a strike, so it is for a door that actually latches. On a false or inactive leaf you want a dummy trim, which is knob and rose only with no latch: the Schlage A170 single dummy or the BEST 6K single dummy trim, both Grade 2, or a Bravura Biloxi round-trim dummy if you want a residential look.
13) What is a simpler alternative to the Oxford YR10XF for a hall or closet door?
Pamex FTF (PMX-FTF30) is a Grade 3 Baron knob lockset in the passage function for doors 1-3/8 inch to 1-3/4 inch thick. Kwikset 200P Polo is an interior hall and closet passage knob supplied with a 6AL latch and RCS round corner strike. Both are passage knobs for the same kind of non-locking opening as the Yale Oxford YR10XF, which is Grade 2.
14) What are the other Grade 2 passage knobsets if I want a different look on the same spec?
Bravura Albany (BVR-BV335002) and Bravura Lynchburg (BVR-BV336002) are both Grade 2 passage knobsets with round trim, and Bravura Dallas (BV947-200) is a Grade 2 passage knobset with rectangle trim in a US4 satin brass finish. Arrow MK01 and Arrow RK01 are Grade 2 passage cylindrical knob locks for 1-3/8 inch to 1-3/4 inch doors, the RK01 with a ball knob. The Yale Oxford YR10XF is a round-design Grade 2 passage knob in oil rubbed bronze, polished brass, antique brass and satin nickel.
15) For a storeroom or supply closet that has to stay secured, what replaces a passage knob?
A passage knob latches but does not secure, so a storeroom function is the part for a closet that must stay locked. The Sargent 6G04 is a Grade 2 standard duty storeroom/closet knob lock with a single cylinder. The Sargent 8XG04 is the Grade 1 heavy duty storeroom/closet single cylinder knob lock with a 2-3/4 inch backset for higher-traffic facility use.
16) Do the Baldwin Estate passage knobs cross over with the Yale Oxford YR10XF?
They cover the same passage function but are built to a different pattern. Baldwin Estate 5000 (BAL-5000PASS) is a preconfigured 2 inch Baltimore knob with a 5048 rose, a 2-3/8 inch backset and a full lip strike; Baldwin Estate 5011 is a Colonial passage knob with a 5058 rose. The Yale Oxford YR10XF is a Grade 2 passage knob with a round rose, a 2-1/8 inch cross bore and a 1 inch edge bore.
17) Can I use Emtek or Omnia knobs in place of a cylindrical passage knob set?
Check the function before ordering. Emtek Porcelain knobs (EMTEK-8000-PORCELAIN) ship as two knobs with a threaded rod, and the Emtek Arts and Crafts Hammered Egg, Georgetown and Providence sets are dummy pairs with no latch. Omnia 434/PA is a passage latchset with a 3 inch projection, while Omnia 434/0, 442/00 and 458/0 are single dummy latchsets. Only the Omnia 434/PA matches the passage function of the Yale Oxford YR10XF.
18) Sargent 78-2875 and 28C-KNOB came up in a knob search - are those alternatives to a passage knobset?
No, those are exit device trim, not standalone bored locksets. The Sargent 28C-KNOB is exit device trim with knob and rose in the entrance function for 1-3/4 inch doors, and the Sargent 78-2875 is an outside knob only with B design. The Imperial USA ED-BKL580 is likewise knob trim in the storeroom function. A door that needs a complete passage set takes a bored lockset like the Yale Oxford YR10XF, which fits a 2-1/8 inch cross bore.
19) Do the screws show on the Yale Oxford knob once it is installed?
No. The Oxford round rose uses concealed mounting screws, so the finished face is clean metal with no fasteners visible. That matters when you are standardizing visible hardware across units and do not want the exposed-screw look of budget builder sets.
20) Are the Yale YH Collection knobs removable for re-keying, and does that matter on a passage set?
The knobs come off on the YH Collection chassis, which is how Yale handles re-keying across the family. On the Oxford passage set there is no cylinder to re-key, so what removable knobs buy you here is easier service: you can pull trim without taking the whole lock apart. The re-keying benefit applies to the keyed functions in the same collection.
21) Is the Yale Oxford knob metal or plastic inside?
Metal construction throughout the lockset. That is the difference between this and a big-box builder-grade knob where the chassis and spindle are often zinc-plated pot metal or plastic collars, and it is why it carries a Grade 2 rating rather than Grade 3.
