Metallics JFMP127SS 10-24 x 3 in. Flat Head Phillips Machine Screws - 18-8 Stainless - 100qty

Metallics JFMP127SS 10-24 x 3 in. Flat Head Phillips Machine Screws - 18-8 Stainless - Each

(No reviews yet) Write a Review

Model: JFMP127SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$192.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10-24 x 3 in. Flat Head Phillips Machine Screws - 18-8 Stainless - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | Hardness and tensile strength standards are offered as guides only for stainless machine screws. There is currently no national standard for these performance requirements for stainless machine screws.

  • Features

    • Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
    • Flat head with Phillips Drive
    • Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance, in food processing machinery and refrigeration equipment.
    • 10-24 Diameter, 3" Length
    • 18-8 Stainless Material

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-1998
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.098 - 0.116 in.
Fastener Head Type:
Flat
Fastener Head Width:
0.333 - 0.362 in.
Fastener Length:
3
Gaging Diameter:
0.313
Hardness:
Rockwell B85-B95
Language Code:
EN
Material Standard:
SAE
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Phillips Recess Depth:
0.124
Phillips Recess Diameter:
0.198
Phillips Recess Width:
0.032
Product Group:
Fasteners
Product Height:
5.75 in
Product Length:
3.5 in
Product Weight:
2.01 lbs
Product Width:
3.5 in
Protrusion Gaging Diameter:
0.025 - 0.042 Above
Sub Division:
Electrical-E H2
Tensile Strength:
1050 lb minimum
Thread Per Inch:
24
Thread Standard:
ANSI/ASME B1.1
Thread Type:
UNC
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
FM and FMP
Product Details:
Machine Screw
Product Material:
18-8 Stainless

Metallics JFMP127SS – Frequently Asked Questions

1) Will a 10-24 x 3 inch flat head Phillips machine screw thread into a standard device box or mud ring?
The Metallics JFMP127SS is a 10-24 UNC thread, 24 threads per inch, cut to ANSI/ASME B1.1. That is the same thread used on standard electrical device and fixture mounting holes, so it mates with 10-24 tapped holes in boxes, mud rings and fixture straps. The 3 inch length is the long one, meant for reaching through deep plaster rings, extension rings or thick wall build-up rather than a flush box.
2) Can I use a machine screw like this in drywall or wood, or does it need a tapped hole?
Machine screws need a mating thread. The JFMP127SS has a 10-24 UNC machine thread with a blunt end, so it goes into a tapped hole, a threaded insert, or a nut. It will not cut its own thread in wood, drywall or sheet metal. For those substrates use a wood screw, a self-drilling sheet metal screw, or install a 10-24 anchor or rivet nut first.
3) Will the flat head sit flush in a countersunk hole, and how much room does the head take?
Yes, it is a flat countersunk head, so it seats flush in an 82 degree countersink. Head width runs 0.333 to 0.362 inch and head height 0.098 to 0.116 inch, dimensioned to ASME B18.6.3-1998. If your plate or bracket is not countersunk, the head will stand roughly a tenth of an inch proud; use a round or pan head instead where a raised head is acceptable.
4) Is 18-8 stainless the right choice for damp, outdoor or washdown locations?
18-8 stainless handles general atmospheric corrosion, which covers damp interiors, food processing equipment and refrigeration gear, and it holds strength better than plain steel as operating temperature rises. It is not a marine-grade alloy, so for constant salt spray or submerged service you want 316 rather than 18-8. For a zinc-plated steel screw in a wet mechanical room, this is the upgrade.
5) Do these stainless machine screws meet Buy American or ARRA requirements on a public project?
The JFMP127SS carries a compliance flag for both Buy American and ARRA, with country of origin listed as China. On federally funded work, submit those flags against your project's specific domestic-content clause, because the threshold varies by funding source.
6) What size Phillips driver do I need for these 10-24 stainless machine screws?
A #2 Phillips. The recess on the JFMP127SS measures 0.198 inch diameter and 0.124 inch deep, which is the standard #2 geometry. Run a driver bit in good condition if you are power-driving, since 18-8 stainless is softer than hardened steel and the recess will cam out and round before the screw snaps.
7) How are these Metallics 10-24 x 3 in. screws packaged, and is there a minimum order?
They ship in a jar of 100, which is the order minimum (100 count). Shipping weight on the jar is 2.01 lbs. Handy if you are stocking a van or a maintenance crib rather than buying loose pieces.
