Metallics JTEK3PV 10 x 3/4 in....
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.26
$0.26
Metallics JTEK3PV 10 x 3/4 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

Metallics JTEK3PV 10 x 3/4 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK3PV
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.26
$0.26
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 3/4 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

  • Features

    • #2 Drill Point
    • Steel Zinc Material
    • Pan Head with Phillips Drive
    • 10 Diameter, 3/4" Length

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

Manufacturer Resources

Product Specs

Minimum Purchase:
500 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Color:
Silver
Fastener Head Height:
0.122 - 0.133 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.357 - 0.373 in.
Fastener Length:
4-Mar
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
500
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Panel Thickness:
0.035 - 0.110 IN
Phillips Recess Diameter:
0.192
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
3.05 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.089 - 0.113
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
16
Thread Standard:
SAE J78 - 2013
Thread Type:
UNC
Torsional Strength:
61 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK3PV – Frequently Asked Questions

1) What metal thickness will a #10 x 3/4 in. self-drilling screw with a #2 drill point actually drill through?
The Metallics JTEK3PV is rated for panel thickness of 0.035 to 0.110 inches. That covers typical sheet metal studs, strut, duct and enclosure flanges. Go thicker than 0.110 and the #2 drill point is out of its range, so you want a larger drill point number for heavier structural steel.
2) Do I need to pre-drill a pilot hole for the Metallics JTEK3PV screws?
No. It's a Type BSD self-drilling and tapping screw, so the drill point cuts its own hole and the threads tap it in one pass within the 0.035 to 0.110 inch panel thickness range. One driver, no pilot bit, no tapping step.
3) Do Metallics JTEK3PV screws meet Buy American requirements for a government or institutional job?
They are flagged both ARRA compliant and Buy American compliant, which is what a public agency, school district, or federally funded project submittal usually asks for. Country of origin is listed as multiple.
4) What driver bit do I need for these Metallics pan head Phillips self-drilling screws?
A #2 Phillips bit. The recess is a Phillips drive with a 0.192 inch recess diameter and 0.089 to 0.113 inch gaging depth, so a #2 seats fully. A #1 will cam out and a #3 won't bottom in the recess.
5) How many screws come in a jar of Metallics JTEK3PV?
They ship in a jar with a 500 count order minimum, roughly 3.05 lbs of hardware. If you need a different size or count, Metallics lists other sizes and quantities as available by request.
6) Is the pan head on these screws low enough to sit under a conduit strap or device plate?
Head height runs 0.122 to 0.133 inches with a head width of 0.357 to 0.373 inches. That's a low, broad pan head, so it clamps strap and bracket slots without much standoff, but it is not a flush head, it sits proud of the surface. For a flush finish you need a flat head screw instead.
7) Will zinc plated steel self-drilling screws hold up outdoors or in a wet area?
The JTEK3PV is steel with a zinc finish, which is built for dry interior and protected work, electrical enclosures, raceway, metal framing. Zinc plating gives limited corrosion protection, so for exterior, coastal, or washdown locations choose a stainless self-drilling screw rather than this one.
8) What standards do these #10 self-drilling tapping screws conform to?
Dimensions follow ASME B18.6.3-2010 and the thread conforms to SAE J78 - 2013, UNC thread at 16 threads per inch. Hardness is Rockwell C32-40 with 61 lb-in minimum torsional strength. Worth noting for spec writers: SAE J78 does not cover #7 diameter drill screws, so a #7 callout can't be held to that standard.
9) Can I run these in with an impact driver without snapping heads?
Torsional strength is 61 lb-in minimum on the #10 x 3/4 in. JTEK3PV, with Rockwell C32-40 hardness. That is enough for normal cordless driving into 0.035 to 0.110 inch steel, but a high torque impact driver run wide open will twist heads off any drill screw this size. Use a clutch or a screw gun with depth control.
