11/2 GALV MI 90 STR ELL
Manufacturer Resources
Product Specs
- Dimensions Specification:
- ASME B16.3
- End Conn Size 1:
- FPT
- End Conn Size 2:
- MPT
- Finish Specification:
- ASTM A-153
- Material Specification:
- ASTM A-197
- Pressure Rating Specification:
- ASME B16.3
- Size 1:
- 1.5
- Size 2:
- 1.5
- Strength:
- STD
- Thread Specification:
- ASME B1.20.1
- Ul Fm:
- Yes
- Department:
- Plumbing
- Product Group:
- Pipe Fittings
- Product Subgroup:
- Elbows
- Product Type:
- 90° Elbow
- Product Finish:
- Galvanized
- Product Material:
- Malleable Iron
- Product Weight:
- 1.55 lbs
ASC Engineered Solutions 311017008 – Frequently Asked Questions
1) Can this 1-1/2 inch galvanized street elbow be used on a fire sprinkler line?
It is UL/FM listed, so it is accepted for fire protection piping. Pressure class and dimensions follow ASME B16.3 at standard (STD) strength, and the galvanized coating is per ASTM A-153, which is the usual requirement for wet and dry sprinkler systems.
2) Is a galvanized malleable iron elbow OK for potable water, or should I use something else?
This is a galvanized malleable iron fitting made to ASTM A-197 with an ASTM A-153 hot dip coating. Galvanized iron is the traditional choice for fire protection and general water service piping. For new potable water work, many jurisdictions now require lead free brass or copper fittings instead, so check what your local code accepts before specifying galvanized.
3) What is the part number and weight on the ASC 1-1/2 inch galvanized 90 street elbow?
Order it as ASC Engineered Solutions MPN 311017008. Each fitting weighs 1.55 lbs, which is worth knowing if you are pricing freight on a full box for a riser job.
4) Is this elbow full standard weight or is it a lighter pattern?
It is standard (STD) weight malleable iron, dimensioned and pressure rated to ASME B16.3. That is the normal Class 150 galvanized pattern used in commercial plumbing and sprinkler work, not a light duty or drainage pattern fitting.
