1/2 GALV MI 90 STR ELL
Manufacturer Resources
Product Specs
- Dimensions Specification:
- ASME B16.3
- End Conn Size 1:
- FPT
- End Conn Size 2:
- MPT
- Finish Specification:
- ASTM A-153
- Material Specification:
- ASTM A-197
- Pressure Rating Specification:
- ASME B16.3
- Size 1:
- 0.5
- Size 2:
- 0.5
- Strength:
- STD
- Thread Specification:
- ASME B1.20.1
- Ul Fm:
- Yes
- Department:
- Plumbing
- Product Group:
- Pipe Fittings
- Product Subgroup:
- Elbows
- Product Type:
- 90° Elbow
- Product Finish:
- Galvanized
- Product Material:
- Malleable Iron
- Product Weight:
- 0.27 lbs
ASC Engineered Solutions 311016208 – Frequently Asked Questions
1) Is the ASC 1/2 inch galvanized 90 degree street elbow threaded male on one end and female on the other?
Yes. The ASC Engineered Solutions 311016208 is a street ell: one end is FPT (female pipe thread) and the other is MPT (male pipe thread), both 1/2 inch. That lets it thread straight into a female port or coupling without an added nipple, which is the whole reason to use a street pattern instead of a standard 90 with two female ends.
2) Is this galvanized street elbow UL Listed and FM Approved for fire sprinkler piping?
Yes, the 311016208 carries UL/FM recognition, so it can be used on fire protection piping where a listed fitting is required. It is a standard weight (STD) malleable iron fitting with pressure ratings per ASME B16.3.
3) Can I use a galvanized malleable iron elbow on a wet or outdoor line?
The galvanized coating is applied to ASTM A-153, the hot-dip spec for hardware, which is what makes this fitting suitable for water service and damp or exterior runs where black iron would rust. The body itself is malleable iron to ASTM A-197. For gas piping, black iron is the usual call rather than galvanized.
4) What does the STD marking mean on this malleable iron fitting?
STD is standard weight, Class 150 territory in malleable iron, as opposed to extra heavy. Pressure ratings come from ASME B16.3 and vary by size and service. For higher-pressure work you would step up to an extra heavy fitting instead.
