Spec Sheet
Product Specs
- Actuator:
- Pushbutton, mushroom head
- Actuator Color:
- Black
- Contact Configuration:
- 1NC
- Enclosure Material:
- Die cast
- Legend:
- STOP
- Notes:
- Nema 4 - 13, if properly mounted on a flat surface
- Number Of Elements:
- 1
- Operating Mode:
- Momentary
- Series:
- 10250T
- Department:
- Electrical
- Product Type:
- 30.5 mm, Heavy-Duty
- Product Details:
- 30.5 mm, Heavy-Duty
- Mounting Method:
- Flush
- Performance Rating:
- NEMA 4, 4X, 12, 13
B-LINE 10250T3576 – Frequently Asked Questions
1) Is the B-Line 10250T3576 control station a maintained (latching) stop button or momentary?
It's momentary. The black mushroom head pushbutton springs back when released, so the 1NC contact opens only while the button is pressed. If your machine needs a stop that stays latched in until it's twisted or pulled out to reset, this one won't do it, and it should not be used as an emergency stop that has to hold the circuit open.
2) Can I mount this B-Line STOP pushbutton station outdoors or in a washdown area?
Rated NEMA 4, 4X, 12 and 13, so it handles hosedown, corrosive atmospheres, dust, oil and coolant. The rating only holds if the station is properly mounted on a flat surface, and the enclosure is die cast. A poor gasket seat on an uneven surface is what usually costs you the rating in a washdown bay.
3) Is the mushroom button on the 10250T3576 red like a typical emergency stop?
No, the actuator is black with a STOP legend. It's a black mushroom head stop button, not the red emergency stop colour crews expect. If your site standard or safety spec calls for a red E-stop mushroom, specify a red actuator version instead.
4) How many contact blocks does the 10250T3576 come with, and can I wire a second circuit off it?
One element only, configured 1NC. That gives you a single normally closed circuit to break, which is what a stop function needs. If you need an extra contact for a PLC input or an indicator circuit, you'd have to add a separate block or choose a station built with more elements, because this one is assembled with a single contact.
5) Does this B-Line station come already assembled, or do I build it from an operator and enclosure?
It ships as an assembled control station: die cast enclosure, black mushroom head pushbutton, STOP legend and one 1NC contact element already fitted. You wire it and mount it, no operator or block to order separately.
6) What is the correct part number to reorder this black mushroom STOP station?
Order it as B-Line 10250T3576, part of the 10250T 30.5 mm heavy-duty series. That number covers the complete assembled station with the black mushroom actuator and 1NC element.
