Product Specs
- Actuator:
- One indicating light, two pushbuttons, flush
- Actuator Color:
- Red
- Contact Configuration:
- 1NO-2NC
- Enclosure Material:
- Die cast
- Legend:
- MOTOR RUN START/STOP
- Light unit type:
- Transformer
- Light Unit Voltage:
- 110 Vac
- Notes:
- Enclosure has corrosion resistant coating
- Number Of Elements:
- 3
- Operating Mode:
- Momentary
- Series:
- 10250T
- Department:
- Electrical
- Product Type:
- 30.5 mm, Heavy-Duty
- Product Details:
- 30.5 mm, Heavy-Duty
- Mounting Method:
- Surface
- Performance Rating:
- NEMA 4, 4X, 12, 13
- Product Weight:
- .4 LB
- Product Width:
- 3.88 in
- Product Height:
- 7.75 in
- Product Length:
- 0.25 in
B-LINE 10250T4337 – Frequently Asked Questions
1) Is the B-Line 10250T4337 control station rated for washdown or outdoor use?
The 10250T4337 carries NEMA 4, 4X, 12 and 13 ratings, so it handles hosedown, corrosive atmospheres, dust and oil-laden environments. The die cast enclosure also has a corrosion resistant coating, which is what gets it the 4X. That covers food plants, car washes, and wet exterior wall mounting.
2) What is actually in the 10250T4337 station - how many buttons and lights?
Three elements in one enclosure: two flush pushbuttons and one indicating light, legended MOTOR RUN START/STOP. It ships assembled, so you are not building it up from separate operators and a box.
3) Will the 10250T4337 work for a standard three-wire motor start/stop circuit?
That is what it is built for. Contact configuration is 1NO-2NC with momentary operation, giving you a normally open start contact and normally closed stop contacts for a three-wire seal-in circuit, plus the run indicator. Confirm your contactor coil suits the 110 Vac pilot light supply.
4) Do the pushbuttons on this station latch, or do they release when you let go?
Momentary operation - the contacts change state only while the button is held and spring back on release. Holding a motor running depends on a seal-in contact in your starter circuit, not on the button. If you need a button that stays in, specify a maintained or push-pull operator instead.
5) Are the buttons on the 10250T4337 flush or raised, and what color?
Both pushbuttons are flush style, and the actuator color is red. Flush buttons reduce accidental operation where people brush past the station. If you need a mushroom or extended head for a glove-on emergency stop, this is not that station.
