3M Scotchlok Female Disconnect Terminal 12-10 AWG Nylon Insulated Quick Connect System

3M Scotchlok Female Disconnect Terminal 12-10 AWG Nylon Insulated Quick Connect System

Professional Quick-Connect Electrical Terminals for Reliable Wire Connections

The 3M Scotchlok Female Disconnect Terminal delivers professional-grade electrical connections with yellow nylon insulation and interlocking barrel design. Accommodating 12-10 AWG wire sizes with 0.25-inch male tab compatibility, this fully insulated terminal provides reliable performance for electrical installations requiring quick and easy wire disconnect capability.

Professional Features & Benefits

• 12-10 AWG Wire Compatibility: Accommodates standard wire gauges for versatile electrical connection applications across residential and commercial installations.
• 600V Maximum Voltage Rating: Provides reliable electrical performance for standard voltage applications with professional-grade safety margins.
• Nylon Insulation Material: Yellow nylon construction offers durability and electrical isolation while providing visual identification for wire management.
• Interlocking Barrel Design: Butted seam with interlocking barrel ensures secure wire insertion and reliable electrical contact for long-term performance.
• 0.25-inch Tab Compatibility: Mates with standard 0.25-inch wide male tabs for consistent connection interface across electrical systems.
• 221�F Maximum Operating Temperature: Handles elevated temperature conditions for reliable performance in demanding electrical environments.
• ETP Copper Construction: High-conductivity copper material ensures optimal electrical performance and corrosion resistance.

Technical Specifications

• Barrel Inside Diameter: 0.128 Inch
• Barrel Length Imperial: 0.25 Inch
• Barrel Style: Interlocking Barrel
• Color Family Incorporate Product Color: Yellow
• Conductor Size: 12 - 10 AWG
• Connection Type: Wire
• Connection Width Imperial: 0.25 in
• Connection Width Metric: 6.35 mm
• Connector Connector Tool: Connector
• Connector Style: Insulation Displacement
• Diameter D: 0.23 Inch
• Disconnect Type: Female
• Fastener Orientation: Female
• Flame Retardant: No
• Grease Filling Against Corrosion: No
• Insulation Color: Yellow
• Insulation Material: Nylon
• Insulation Outer Diameter Metric: 3.68 mm
• Interrupt Free Shifting: No
• Male Tab Width W: 0.250 Inch
• Manufacturer Catalog Number: 7000133400
• Manufacturing Origin: USA
• Mates With Male Tab Width W: 0.25 Inch
• Maximum Conductor Size: 10 AWG
• Maximum Insulation Outer Diameter Imperial: 0.145 Inch
• Maximum Insulation Outer Diameter Metric: 3.7 mm
• Maximum Insulation Outside Diameter: 0.145 in
• Maximum Operating Temperature Celsius: 105 Degree Celsius
• Maximum Operating Temperature Fahrenheit: 221 Degree Fahrenheit
• Maximum Recommended Voltage Rating: 600 V
• Maximum Wire Gauge: 10 AWG
• Minimum Conductor Size: 12 AWG
• Minimum Wire Gauge: 12 AWG
• Overall Diameter Imperial: 0.23 in
• Overall Length Imperial: 0.99 in
• Overall Length Metric: 25.14 mm
• Overall Width Imperial: 0.37 in
• Package Height: 4.37500 in
• Package Length: 1.62500 in
• Package Weight: 0.2800 LBS
• Pad Width: 0.25 in
• Product Material: ETP Copper
• Tab Width: 0.25
• Terminal Style: Fully Insulated
• Terminal Type: Standard

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Residential Electrical Systems
• Commercial Building Wiring
• Industrial Control Panels
• Automotive Electrical Connections
• HVAC System Wiring
• Appliance Connections
• Electrical Maintenance and Repair

Why Choose 3M Quality?

3M Scotchlok terminals deliver reliable electrical connections with USA manufacturing quality and ETP copper construction. The fully insulated terminal design with 600V voltage rating and 221�F temperature capability ensures dependable performance for professional electrical applications requiring quick disconnect functionality.
