Keystone 60W Dusk to Dawn LED Area Light with Power Select & Color Select 0-10V Dimming

Keystone 60W Dusk to Dawn LED Area Light with Power Select & Color Select 0-10V Dimming

(No reviews yet) Write a Review

Model: KT-ALED60PS-D2D-WM-8CSB-VDIM
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$335.89
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Keystone 60W Dusk to Dawn LED Area Light with Power Select & Color Select 0-10V Dimming

Professional outdoor lighting with selectable power and color temperature control

The Keystone 60W Dusk to Dawn LED Area Light delivers versatile outdoor illumination with advanced Power Select and Color Select technology. This professional-grade fixture features automatic photocell operation, 0-10V dimming capability, and Type 5 distribution for comprehensive area coverage. Built with gray housing and rated for 50,000 hours of reliable operation, this fixture provides flexible lighting solutions for various outdoor applications.

Professional Features & Benefits

  • Selectable Power Options (60/40/30W): Optimize energy consumption and light output for specific application requirements while maintaining installation flexibility.
  • Selectable Color Temperature (3000/4000/5000K): Choose the ideal color temperature for your environment, from warm residential lighting to crisp commercial illumination.
  • Automatic Dusk to Dawn Operation: Built-in photocell sensor provides hands-free operation, turning on at dusk and off at dawn for energy efficiency and convenience.
  • 0-10V Dimming Compatibility: Professional dimming control allows precise light level adjustment for enhanced energy savings and lighting management.
  • Type 5 Light Distribution: Provides uniform circular light distribution pattern ideal for area lighting applications requiring comprehensive coverage.
  • DLC Listed Quality: Meets DesignLights Consortium standards for energy efficiency and performance, ensuring utility rebate eligibility.
  • 50,000 Hour Rated Life: Extended operational life reduces maintenance costs and provides long-term reliability for continuous outdoor use.

Technical Specifications

  • Accessory Device: No
  • Cec T20: No
  • Cri: >80
  • Dimming: 0-10V
  • Distribution Type: Type 5
  • Dlc: Yes
  • Dlc Premium: No
  • Energy Star: No
  • Housing Color: Gray
  • Input Voltage: 120-277
  • Led Module Included: No
  • Not Suitable For Sale In California: No
  • Product Weight: 3.6 lbs
  • Rated Life Hours: 50000
  • Selectable Color Temperature: 3000/4000/5000
  • Selectable Lumens Output: 9120/6720/5100
  • Selectable Power: 60/40/30
  • Sensor Type: Photocell
  • T24 Ja8: No
  • Ul: No
  • Warranty Years: 10 Year Limited
  • Wireless Control: No

Professional Applications

  • Commercial parking lots and walkways
  • Residential driveways and outdoor areas
  • Multi-unit property common areas
  • Professional office exterior lighting
  • Retail establishment perimeter lighting
  • Light industrial facility outdoor areas
  • Municipal and public space illumination

Why Choose Keystone Quality?

Keystone delivers professional-grade LED lighting solutions backed by a comprehensive 10 Year Limited warranty and DLC listing for proven performance. The durable gray housing construction and 50,000-hour rated life ensure long-term reliability in demanding outdoor environments, while the selectable power and color temperature options provide installation flexibility for diverse lighting requirements.

Manufacturer Resources

Product Specs

Accessory Device:
No
Cec T20:
No
Cri:
>80
Dimming:
0-10V
Distribution Type:
Type 5
Dlc:
Yes
Dlc Premium:
No
Energy Star:
No
Housing Color:
Gray
Input Voltage:
120-277
Led Module Included:
No
Not Suitable For Sale In California:
No
Product Weight:
3.6 lbs
Rated Life Hours:
50000
Selectable Color Temperature:
3000/4000/5000
Selectable Lumens Output:
9120/6720/5100
Selectable Power:
60/40/30
Sensor Type:
Photocell
T24 Ja8:
No
Ul:
No
Warranty Years:
10 Year Limited
Wireless Control:
No

Keystone KT-ALED60PS-D2D-WM-8CSB-VDIM – Frequently Asked Questions

1) Will the Keystone KT-ALED60PS-D2D area light run on a 277V circuit?
Yes. The KT-ALED60PS-D2D-WM-8CSB-VDIM accepts 120-277V input, so it wires to 120, 208, 240 or 277V without changing fixtures. That makes it workable on both residential 120V exterior circuits and commercial 277V lighting panels.
2) How do I set the wattage and color temperature on this Keystone Power Select area light?
Both are selectable on the fixture itself, not ordered as separate part numbers. Power Select gives 60W, 40W or 30W, and Color Select gives 3000K, 4000K or 5000K. Lumen output tracks the wattage you pick: 9120 lumens at 60W, 6720 at 40W, 5100 at 30W. One stocked fixture covers nine combinations, which is why it suits a property manager standardizing across mixed sites.
3) Does this dusk to dawn LED area light need a separate photocell?
No separate photocell is needed. A photocell sensor is built in, so the fixture switches on at dusk and off at dawn on its own. Wire it to an unswitched hot and it runs itself. There is no wireless or networked control in it, so if you want scheduling or grouping you would need upstream controls.
4) Can I dim this Keystone area light from a building control system?
It takes 0-10V dimming, so it lands on a standard low-voltage analog dimming control run alongside the line voltage feed. That is the usual interface for commercial lighting panels and occupancy or daylight controllers. Note the photocell already handles on/off, so the 0-10V pair is for trimming light level, for example dropping a parking lot to partial output after hours.
5) Is Type 5 distribution right for a parking lot, or do I need a different pattern?
Type 5 throws a symmetric circular pattern, so it is right for a pole or wall position in the middle of an area you want lit evenly in all directions: open lots, courtyards, driveways, common areas. If you are lighting along a property line or a roadway edge and need the light cut off on the back side, a Type 3 or forward-throw distribution is the better choice, since Type 5 will spill light behind the fixture.
6) Do I have to order an LED module or lamp separately for this Keystone area light?
No lamp or module purchase is involved. The LEDs are integral to the fixture, not a replaceable module you order as a separate line item. Rated life is 50,000 hours, so maintenance planning is fixture replacement at end of life rather than relamping.
7) What is the exact part number to order this Keystone dusk to dawn Power Select area light?
The manufacturer part number is KT-ALED60PS-D2D-WM-8CSB-VDIM. That single number covers the wall mount housing, the dusk to dawn photocell, all three wattage settings and all three color temperatures, plus the 0-10V dimming leads, so distributors do not need to break it out by wattage or Kelvin.
8) How much does this Keystone wall mount area light weigh, and will a standard junction box carry it?
The fixture weighs 3.6 lbs. That is light enough for a normal wall mount over an exterior box, which matters on stucco, EIFS or siding where you do not want a heavy head cantilevered off the wall. No structural pole bracket work is involved at that weight.
9) Will the light quality be good enough for color recognition on security camera footage?
CRI is greater than 80, which is the normal threshold for commercial outdoor work and enough for reasonable color rendering on camera. Pairing that with 5000K on the Color Select switch gives the crispest, most neutral rendering for security areas, while 3000K reads warmer and suits residential frontages and multi-family entries.
10) What color is the housing on this Keystone 60W area light?
Gray housing. If you are adding fixtures to a site that already runs bronze or black exterior lighting, the gray will read differently, so it is worth confirming the aesthetic before mixing it into an existing run on a storefront or multi-family facade.
