Metallics JPMP89 8-32 x 2 in. ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.39
$0.39
Metallics JPMP89 8-32 x 2 in. Pan Head Phillips Machine Screws - Steel Zinc - 100qty

Metallics JPMP89 8-32 x 2 in. Pan Head Phillips Machine Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JPMP89
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.39
$0.39
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
8-32 x 2 in. Pan Head Phillips Machine Screws - Steel Zinc - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.

  • Features

    • Steel Zinc Material
    • 8-32 Diameter, 2" Length
    • Pan head with Phillips Drive

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.105 - 0.115 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.306 - 0.322 in.
Fastener Length:
2
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell B70-B100
Language Code:
EN
Material Standard:
AISI 1006 - 1022
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Head_Screw_St_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Diameter:
0.175
Product Group:
Fasteners
Product Height:
5.75 in
Product Length:
3.5 in
Product Weight:
1.08 lbs
Product Width:
3.5 in
Recess Penetration Gaging Depth:
0.071 - 0.097
Sub Division:
Electrical-E H2
Tensile Strength:
60000 psi minimum
Thread Per Inch:
32
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
PMP
Product Finish:
Zinc
Product Details:
Machine Screw
Product Material:
Steel Zinc

Metallics JPMP89 – Frequently Asked Questions

1) Are these zinc plated steel screws OK for outdoor or wet locations?
Zinc plated carbon steel is a dry, indoor-location fastener. The JPMP89 is made from AISI 1006 to 1022 steel with a zinc finish, which handles general interior MRO work but will corrode in exterior, damp, or washdown areas. For those openings use a stainless 8-32 pan head Phillips instead.
2) Do these machine screws come with nuts, or do I need a tapped hole?
The JPMP89 is the screw only. A machine screw has a straight, uniform 8-32 thread with a blunt end, so it needs either a tapped hole (a device yoke, a box ear, a threaded bracket) or a separate 8-32 nut. It will not form its own thread in sheet metal the way a self-tapping screw does.
3) Are Metallics JPMP89 screws Buy American or ARRA compliant for a government job?
No. These are not Buy American compliant and not ARRA compliant, and country of origin is listed as multiple. If your project carries domestic-sourcing requirements, this part will not satisfy them.
4) What size Phillips driver do I need for these 8-32 pan head screws?
A #2 Phillips. The recess on the JPMP89 measures 0.175 inch in diameter with a gaging depth of 0.071 to 0.097 inch, so a #2 bit seats fully. Using a #1 will cam out and chew the recess on a 2 inch screw that needs several turns to draw down.
5) How much room does the pan head take up above the surface?
The head sits low: height is 0.105 to 0.115 inch with a head width of 0.306 to 0.322 inch. That shallow profile is why a pan head works under a cover plate or flush trim where a round or truss head would stand proud. Dimensions follow ASME B18.6.3-2010.
6) How are Metallics JPMP89 machine screws packaged and what is the minimum order?
They ship in a jar of 100, and 100 is the order minimum. The packed jar weighs 1.08 lbs. Buying by the jar is how most electrical and maintenance shops stock 8-32 x 2 so the bin does not run dry mid-job.
7) How strong is an 8-32 x 2 in. zinc machine screw, and can I torque it down hard?
Tensile strength is 60,000 psi minimum with a hardness of Rockwell B70 to B100. That is a standard low-carbon machine screw, not a Grade 5 or 8 bolt, so it is sized for holding devices, plates, covers, and light brackets. Do not treat it as a structural fastener or impact it down.
