Metallics JFWP23 8 x 2-1/2 in....
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.36
$0.36
Metallics JFWP23 8 x 2-1/2 in. Flat Head Phillips Wood Screws - Steel Zinc - 100qty

Metallics JFWP23 8 x 2-1/2 in. Flat Head Phillips Wood Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JFWP23
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.36
$0.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
8 x 2-1/2 in. Flat Head Phillips Wood Screws - Steel Zinc - 100qty

  • Features

    • 8 Diameter, 2-1/2" Length
    • Steel Zinc Material
    • Screws of nominal lengths too short to accomodate the minimum thread length shall have threads extending as close to the underside of the head as practicable.
    • Flat Head with Phillips Drive

  • Additional Notes

    • Other sizes and quantities available by request | Length of Thread: Length = 1 inch then 2/3 thread

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.1
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.100 - 0.100 in.
Fastener Head Type:
Flat
Fastener Head Width:
0.292 - 0.332 in.
Fastener Length:
2/1/02
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Wood_Screw_Steel_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Depth:
0.113 - 0.136
Phillips Recess Diameter:
0.191 - 0.204
Phillips Recess Width:
0.032
Product Group:
Fasteners
Product Height:
3.6 in
Product Length:
3 in
Product Weight:
1.05 lbs
Product Width:
3 in
Screw Point Type:
Tapered Point
Sub Division:
Electrical-E H2
Thread Per Inch:
15
Thread Standard:
ASME B18.6.1-1997
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Wood Screw
Type2:
Wood Screw
Series:
JFWP
Product Finish:
Zinc
Product Details:
Wood Screw
Product Material:
Steel Zinc

Metallics JFWP23 – Frequently Asked Questions

1) Will a #8 x 2-1/2 in. flat head wood screw sit flush in a countersunk hole?
Yes, if the countersink matches the head. The JFWP23 flat head measures 0.292 to 0.332 in. across with a head height of 0.100 in., so an 82-degree countersink sized for a #8 flat head brings it flush or slightly below the surface. Without a countersink the flat head will stand proud and split thin stock.
2) Do these wood screws need a pilot hole, or will they bite on their own?
The JFWP23 has a tapered point, not a self-drilling tip, so it starts on its own in softwood but wants a pilot hole in hardwood or near an edge. Thread count is 15 per inch over a 2-1/2 in. length, and on nominal lengths over 1 inch the thread runs about two-thirds of the screw, so the shank portion rides in the top member and pulls the joint tight.
3) What driver bit do I need for the Metallics JFWP23 wood screws?
A #2 Phillips bit. The JFWP23 is a Phillips drive screw with a recess diameter of 0.191 to 0.204 in., recess depth 0.113 to 0.136 in., and a 0.032 in. recess width, so a #2 tip seats fully without camming out.
4) Are zinc plated wood screws OK for outdoor or damp locations?
Zinc plated steel is a dry-location finish. The JFWP23 is steel with a zinc plating, which handles interior framing, cabinet backing, strut and box mounting, but it will corrode in exterior exposure, in treated lumber, or in wet areas. For those, use a stainless or coated exterior-rated screw instead.
5) How many Metallics JFWP23 screws come in a pack, and can I buy just a few?
They ship in a jar of 100, which is the order minimum. There is no loose or small-count break on the JFWP23, so plan for the full jar per order.
6) Do these Metallics screws meet a recognized dimensional spec for submittals?
Head, thread and recess dimensions conform to ASME B18.6.1, with the thread specifically to ASME B18.6.1-1997. That is the standard a spec reviewer looks for on a tapping wood screw submittal.
7) What are these flat head wood screws typically used for on a job site?
Metallics lists the JFWP23 for the electrical, plumbing, and HVAC trades, which is where a #8 x 2-1/2 in. flat head gets used to anchor strut, hangers, backer boards, box brackets and device plates into wood framing. The flat head lets it countersink flush under a mounting plate rather than hold it off the surface.
