92520 Viega PureFlow Press 90° elbow Zero Lead Bronze, 1/2'' x 1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P x MPT
- Country Of Origin:
- Made In Germany
- Material Type:
- Bronze
- Product Dimension:
- 1/2'' x 1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Elbows
- Product Type:
- Elbow
- Product Length:
- 1.772"
- Product Height:
- 2.484"
- Product Weight:
- 0.202 lbs
- Product Width:
- 3.031"
Viega 92520 – Frequently Asked Questions
1) Will the 1/2 inch MPT end on the Viega 92520 thread into a standard 1/2 inch female iron pipe fitting?
Yes. The threaded leg is 1/2 inch male pipe thread, so it mates with any 1/2 inch FIP or FNPT connection, brass stop valves, threaded nipples, unions, or a threaded port on a fixture. Use thread sealant or tape on the thread; the press side seals on the tube with the fitting's own seal, no sealant.
2) Is the Viega 92520 elbow safe for drinking water lines?
It's a zero lead bronze body, which is what PureFlow fittings use for potable hot and cold water distribution. Bronze also holds up better than a plastic insert fitting where the joint is exposed or takes handling.
3) Do I need a press tool for the Viega 92520, or can it be crimped with a manual ring tool?
The press end is made up with a press tool and the correct 1/2 inch PureFlow jaw. It is not a compression, cinch clamp, or copper crimp ring connection, and nothing on the press side is tightened by hand. The only hand-tightened part of this fitting is the 1/2 inch male thread.
4) I'm ordering fittings for a multi-family rough-in. What part number do I ask for on this 1/2 inch press by thread elbow?
Viega part number 92520, described as the PureFlow Press 90 degree elbow in zero lead bronze, 1/2 inch by 1/2 inch, P x MPT. Give that number and the P x MPT callout together so nobody pulls the press by press elbow off the shelf by mistake.
5) Where is the Viega 92520 PureFlow elbow made, and how heavy is it?
Made in Germany, and it weighs 0.202 lbs. Light enough that a run of them adds nothing meaningful to hanger loading, and the origin matters on public and institutional jobs that call out country of origin on submittals.
