95415 Viega MegaPress union Smart Connect technology 304 stainless steel, 1/2'' x 1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 1/2'' x 1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 4.524"
- Product Height:
- 1.417"
- Product Weight:
- 0.608 lbs
- Product Width:
- 1.555"
- Product Material:
- 304 stainless steel
Viega 95415 – Frequently Asked Questions
1) What size pipe does the Viega 95415 MegaPress union connect?
The Viega MegaPress union, model 95415, is a 1/2 inch by 1/2 inch fitting, so it joins two 1/2 inch runs. Both ends are press connections (P1 x P2), meaning no threading and no welding at either end.
2) Is the Viega 95415 MegaPress union carbon steel or stainless?
It is 304 stainless steel. That matters when you are matching the fitting to the line: a 304 stainless press union is the one to specify where you do not want a carbon steel body in the system.
3) Can the Viega 95415 MegaPress union be taken apart later for service?
A union is the serviceable joint in a pressed line. Both sides of the 95415 are press ends (P1 x P2) that you crimp onto the pipe, and the union nut in the middle lets you break the connection to pull a valve, pump or section of pipe without cutting the piping apart.
4) What is Smart Connect on the Viega 95415 and why does it matter on an install?
Smart Connect is Viega's unpressed-connection feature, and it is there so the installer can find a joint that was missed. On a pressure test, an unpressed Smart Connect fitting leaks noticeably rather than holding, which flags the joint before the wall closes up. The 95415 is a 1/2 inch stainless MegaPress union with the feature on both press ends.
5) How much space do I need to fit the Viega 95415 MegaPress union?
The fitting itself measures 4.524 inches long, 1.555 inches wide and 1.417 inches high, and weighs 0.608 lbs. Allow clearance beyond that for the press tool jaw to seat squarely around each end, which is the real constraint in a tight joist bay or against a wall.
6) Where is the Viega 95415 MegaPress union manufactured?
Made in Germany. That is often the detail a public-sector or institutional buyer needs for a country-of-origin line on a submittal package.
