95430 Viega MegaPress union Smart Connect technology 304 stainless steel, 1-1/2'' x 1-1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 1-1/2'' x 1-1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 6.709"
- Product Height:
- 2.756"
- Product Weight:
- 2.494 lbs
- Product Width:
- 2.992"
- Product Material:
- 304 stainless steel
Viega 95430 – Frequently Asked Questions
1) What size pipe does the Viega 95430 MegaPress union fit?
The Viega 95430 MegaPress union is a 1-1/2 inch x 1-1/2 inch fitting, so it presses onto 1-1/2 inch pipe on both ends. Both sides are press connections (P1 x P2), meaning there is no threading or welding on either end.
2) Is the Viega 95430 MegaPress union made of stainless steel or carbon steel?
It's 304 stainless steel. That matters when you're choosing between MegaPress carbon steel fittings for black iron pipe and the stainless version, which is what you want where corrosion resistance or a cleaner service medium is the concern.
3) What does Smart Connect on the Viega 95430 union actually do for me on the job?
Smart Connect is Viega's feature that makes an unpressed connection detectable during pressure testing, so a joint you missed shows itself before the wall closes up. On a long run with many 1-1/2 inch presses it's the difference between finding the miss at test and finding it after drywall.
4) Why use a press union instead of a threaded or welded union on 1-1/2 inch pipe?
A press union joins two pipe ends with no flame and no thread cutting, which is why it gets specified in occupied buildings, mechanical rooms with hot work restrictions, and retrofit work where you can't rotate pipe to thread it. The 95430 presses on both ends (P1 x P2). If you need a transition to existing threaded pipe, you want a press x thread adapter instead of this union.
5) How much room do I need around the Viega 95430 union to press it?
The fitting itself measures 6.709 inches long, 2.992 inches wide and 2.756 inches high, so plan clearance beyond that for the press jaw and tool head. In tight joist bays or against a wall, measure the jaw swing before committing to the location.
6) What is the Viega part number and manufacturer for this 1-1/2 inch stainless press union?
Manufacturer part number 95430, made by Viega, in the MegaPress stainless line. It's manufactured in Germany. That MPN is what you quote for reorders or for matching an existing submittal.
