American Standard Ultima Selec...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$487.53
$437.53
American Standard Ultima Selectronic Touchless Urinal Flush Valve, Piston-Type, Base Model, 1.0 gpf/3.8 Lpf - AMS-606B101

American Standard Ultima Selectronic Touchless Urinal Flush Valve, Piston-Type, Base Model, 1.0 gpf/3.8 Lpf - AMS-606B101

(No reviews yet) Write a Review

Model: 606B101.002
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$487.53
$437.53
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Ultima Selectronic Touchless Urinal Flush Valve, Piston-Type, Base Model, 1.0 gpf/3.8 Lpf
  • POWER KIT MUST BE PURCHASED SEPARATELY
  • For urinals with 3/4-inch (19 mm) exposed top spud
  • Touchless operation limits the spread of germs
  • Exclusive DynaClean self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Fully mechanical manual override can operate without power
  • Fail-Safe operation: Valve automatically closes upon loss of power or water pressure
  • Pressure Compensation feature ensures accurate flush volume regardless of inlet water pressure
  • Proprietary brass alloy resists dezincification
  • 11-1/2" (292 mm) rough-in

Manufacturer Resources

Product Specs

Product Type:
Flush Valve
Product Group:
Commercial
Product Subgroup:
Parts and Accessories
Family:
SELECTRONIC
Luxury/Non Luxury:
Non Luxury
Residential Commercial:
Commercial
Product Length:
27
Product Height:
4.25
Product Weight:
10.67
Product Width:
10.38
Department:
Plumbing
Parts and Accessories Type:
Flush Valve
Application:
Toilet

American Standard 606B101.002 – Frequently Asked Questions

1) Does the American Standard 606B101 urinal flush valve come with a power supply?
No. The power kit for the Ultima Selectronic 606B101 has to be ordered separately, so budget for it as a second line item. Without it the sensor won't operate, though the valve does have a fully mechanical manual override that flushes with no power at all.
2) Will this touchless flush valve fit my urinal's spud?
It's built for urinals with a 3/4 inch (19 mm) exposed top spud. If your fixture has a 1 inch spud or a back/concealed spud connection, this isn't the valve for that opening.
3) What is the rough-in dimension for the Ultima Selectronic urinal flush valve?
11-1/2 inches (292 mm) from the fixture to the centerline of the supply. That's the number to work to when you're setting the carrier and stubbing out the wall supply.
4) What happens to this sensor flush valve if the power or water goes out?
Fail-Safe operation closes the valve automatically on loss of power or loss of water pressure, so you don't get a stuck-open valve flooding the floor. You can still flush the fixture by hand using the mechanical override.
5) Is the 606B101 a low-flow valve I can use to cut water use in a commercial restroom?
It flushes 1.0 gpf (3.8 Lpf), which is below the 1.0-gallon-plus range of older urinal valves. Pressure Compensation holds that volume steady regardless of inlet water pressure, so the flush doesn't over-deliver on a high-pressure riser.
6) We keep getting run-on with our old urinal valves. Does this one address that?
Yes. The DynaClean self-cleaning wiper spring wipes the refill orifice on every flush, which is the debris path that causes valve run-on. For a building on hard or dirty water that's the main reason to pick this piston-type valve over a plain diaphragm unit.
7) Is the 606B101 rated for a commercial restroom, and what is it made of?
It's an American Standard Commercial-group flush valve for institutional and public restrooms, built from a proprietary brass alloy that resists dezincification. Dezincification is what eats standard brass in aggressive water, so that matters on a building you're standardizing across.
8) What finish and part number do I order for the Ultima Selectronic urinal valve?
Chrome is the finish offered, ordered as American Standard MPN 606B101.002. It's the base model of the Selectronic family piston-type urinal valve.
9) How heavy is the American Standard 606B101 flush valve and what are the shipped dimensions?
The valve is listed at 10.67 lb, with dimensions of 27 x 10.38 x 4.25. Worth knowing if you're spec'ing a run of them for a multi-fixture restroom retrofit.
