ABH 0117.25 Pivot Set, 3/4" Offset, Up to 250 lbs

ABH 0117.25 Heavy-Duty Offset Pivot Set with 3/4" Offset for Doors Up to 250 lbs

(No reviews yet) Write a Review

Model: 0117.25-RH-US26
$441.00
$433.36
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$441.00
$433.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABH Heavy-Duty Offset Pivot Set with 3/4" Offset for Doors Up to 250 lbs

Professional Heavy-Duty Pivot Solution for Commercial Applications

The ABH Heavy-Duty Offset Pivot Set delivers professional-grade door support with 3/4" offset design for doors up to 250 pounds and 42" maximum width. Constructed from stainless steel base material with heavy-duty bearings, this pivot set is UL listed for use on 3-hour fire rated doors. The handed design requires specification of LH or RH configuration and accommodates doors ranging from 60" to 90" tall with one intermediate pivot (019 model recommended, ordered separately).

Professional Features & Benefits

  • Heavy-Duty Load Capacity: Supports doors up to 250 pounds with maximum door width of 42" for demanding commercial applications.
  • Precision Offset Design: 3/4" offset configuration provides proper door clearance and smooth operation in offset hung applications.
  • Stainless Steel Construction: Stainless steel base material with heavy-duty bearings ensures long-term durability and corrosion resistance.
  • Fire Rating Compliance: UL listed for use on 3-hour fire rated doors meeting critical safety requirements for commercial buildings.
  • Flexible Door Height Compatibility: Accommodates doors from 60" to 90" tall with one intermediate pivot, with additional pivots for each 30" of additional height.
  • Handed Configuration: Available in left-hand (LH) or right-hand (RH) configurations for proper door swing operation.
  • BAA Qualified: Meets Buy American Act requirements for government and institutional projects.
  • Compatible Accessories: Works with 019 intermediate pivot (ordered separately) for extended door height applications.

Technical Specifications

  • Application: Standard Door
  • BAA Qualified: Yes
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Weight: Up to 250 lbs
  • Duty Level: Heavy Duty
  • Electronic: No
  • Fire Rated Time: 3 hours
  • Fire Rating: Yes
  • Hang Type: Offset Hung
  • Keyed: N/A
  • Keyed Function: N/A
  • Mounting Method: Offset
  • Pivot Type: Top & Bottom
  • Product Attribute: Pivots
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: 180
  • Product Subgroup: Pivots and Pivot Sets
  • Product Substrate: Stainless Steel
  • Product Type: Pivot Sets - Offset
  • Subcategory: Door Pivots

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Fire-Rated Door Applications

Why Choose ABH Quality?

ABH pivot sets deliver professional-grade reliability with stainless steel construction and heavy-duty bearings rated for doors up to 250 pounds. UL listed for 3-hour fire rated applications and BAA qualified for government projects. Engineered for demanding commercial applications where dependable door operation and fire safety compliance are essential.

Product Specs

Product Group:
Door Hinges and Pivots
Product Subgroup:
Pivots and Pivot Sets
Product Type:
Pivot Sets - Offset
Subcategory:
Door Pivots
Commercial/Residential:
Commercial
Hang Type:
Offset Hung
Keyed:
N/A
Keyed Function:
N/A
BAA Qualified:
Yes
Duty Level:
Heavy Duty
Fire Rated Time:
3 hours
Electronic:
No
Door Weight:
Up to 250 lbs
Pivot Type:
Top & Bottom
Mounting Method:
Offset
Application:
Standard Door
Product Attribute:
Pivots
Product Model:
180
Fire Rating:
Yes
Product Category:
Door Hinges and Pivots
Product Substrate:
Stainless Steel
Department:
Door Hardware

ABH 0117.25-RH-US26 – Frequently Asked Questions

1) Will the ABH 0117.25 offset pivot set carry a 250 lb door?
Up to 250 lbs is the rated door weight for the ABH 0117.25, with a maximum door width of 42 inches. Both limits have to be met, so a 250 lb door wider than 42 inches is outside the rating. It is a heavy duty, commercial-rated set on stainless steel base material with heavy-duty bearings.
2) Can I use these pivots on a 3-hour fire rated door?
Yes. The 0117.25 pivot set is UL listed for use on doors with a 3-hour fire rating, which covers stair and shaft openings as well as the lighter ratings below it.
3) Do I have to specify left hand or right hand on the ABH 0117.25?
Yes, it is a handed set. Order either Left Hand or Right Hand to match the door swing. A pivot set installed in the wrong hand will not work, so determine handing at the opening before the order goes in.
4) Can I buy just the bottom pivot to replace a worn one?
Yes. Three ways to order: the full 0117.25 set (0180 top plus 0117.25B bottom), the 0117.25B bottom pivot alone, or the 0180 top pivot alone. If a bottom pivot has worn out under a heavy door, the 0117.25B on its own is the replacement, matched to the same hand as the door.
5) For a fire rated opening, what offset pivot set can I use besides the ABH 0117.25?
The BEST A3 System offset hung pivot set is also fire rated and is hung offset, so it addresses the same class of opening. The ABH 0117.25 carries a 3-hour fire rating, is offset hung, and takes doors up to 250 lbs with a stainless steel base. Where the two differ is offset dimension: the ABH set is built to a 3/4 inch offset, so match the door and frame prep before choosing between them.
6) What is a 3/4 inch offset pivot and how is it different from center hung?
Offset hung means the pivot point sits 3/4 inch in from the face of the door rather than on the door centerline. The door swings one direction and the pivot clears the frame, which is what you want for single acting doors with a closer and for standard commercial openings. Center hung doors rotate about their own centerline and swing both ways, and they need a different pivot entirely. The 0117.25 is offset hung and single acting.
7) Will this pivot set pass a Buy American requirement on a federal job?
The 0117.25 is BAA qualified, so it meets Buy American Act requirements for government and institutional work. That plus the 3-hour UL fire listing is usually what an agency or school district spec is looking for on an offset hung opening.
8) What else could I use instead of the ABH 0117.25 for a 3/4 inch offset opening?
Calibre Door Closers makes the PV1000, a 3/4 inch offset flush pivot set in their CA/Hardware Series, which is the closest direct alternative on offset geometry. BEST also offers the A3 System offset hung pivot set, which carries a fire rating. Where the spec calls for a 250 lb capacity and a 3-hour UL fire listing specifically, the ABH 0117.25 is the one that states both.
9) I only need to replace the worn bottom pivot, not the whole set. What are my options?
You do not need a full set. The ABH 0117.25B bottom pivot and the 0180 top pivot are each orderable on their own, in addition to the complete 0117.25 set that pairs them. That is a component-level replacement path the comparable offset sets, the BEST A3 System and the Calibre PV1000, are cataloged as complete pivot sets rather than split pieces. Specify left hand or right hand to match the existing door.
10) My project has a Buy American requirement. Does that narrow the pivot choice?
Yes. The ABH 0117.25 offset pivot set is BAA qualified, which is what government and institutional specs usually call for, and it is a commercial heavy duty set rated to 250 lbs with a 3-hour fire listing. The comparable offset sets, the BEST A3 System and the Calibre PV1000, are specified by their pivot configuration rather than by a Buy American qualification, so if the drawing carries a BAA line, verify that separately before substituting either one.
11) Will a center hung pivot work in place of the ABH 0117.25?
No. The ABH 0117.25 is offset hung with an offset mounting method and a 3/4 inch offset, meaning the pivot point sits inboard of the door edge and the frame and door are prepped for that geometry. A center hung pivot puts the pivot point on the door centerline and uses different prep entirely. If you are cross shopping, stay within offset hung products such as the BEST A3 System offset hung pivot set or the Calibre PV1000 3/4 inch offset flush pivot set.
12) Is the ABH 0117.25 an electrified pivot for power transfer?
No. The 0117.25 is a mechanical pivot set with no electrical provision. If the door needs power to an electric lock or exit device, transfer it through a separate electric power transfer or a door loop.
13) Will the 0117.25 hold up in a high-traffic or corrosive environment?
Base material is stainless steel with heavy-duty bearings, which is what gives it corrosion resistance and bearing life under a 250 lb leaf. It is specified for commercial duty, standard doors, in offices, schools, healthcare, government, industrial and multi-tenant residential buildings.
14) Do I need an electrified pivot instead of the ABH 0117.25 if the door has a card reader?
The ABH 0117.25 is a non-electronic mechanical pivot set, so it carries no power transfer through the pivot. The comparable offset sets, the BEST A3 System and the Calibre PV1000, are likewise cataloged as mechanical pivot sets. For a door with electrified hardware, run power through a separate electric power transfer device and keep the 0117.25 for load and fire duty, where its 3-hour fire listing and 250 lb capacity apply.
