ABH 0195 Heavy-Duty Offset Piv...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$398.00
$204.15
ABH ABH 0195 Pivot Set, 3/4" Offset, Up to 450 lbs ABH-0195

ABH 0195 Heavy-Duty Offset Pivot Set with 3/4" Offset for Doors Up to 450 lbs

(No reviews yet) Write a Review

Model: 0195-RH-US32D
$398.00
$204.15
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$398.00
$204.15
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABH Heavy-Duty Offset Pivot Set with 3/4" Offset for Doors Up to 450 lbs

Professional Heavy-Duty Pivot Hardware for Commercial Door Applications

The ABH Heavy-Duty Offset Pivot Set delivers professional-grade door support with 3/4" offset design for doors up to 450 pounds and maximum door width of 48". Constructed from stainless steel base material with heavy-duty bearings, this UL listed pivot set is approved for use on 3-hour fire rated doors. The complete set includes 0180 top pivot and 0195 bottom pivot components for comprehensive door mounting solutions.

Professional Features & Benefits

  • Heavy-Duty Load Capacity: Supports doors up to 450 pounds with maximum door width of 48" for demanding commercial applications.
  • 3/4" Offset Design: Precision offset configuration provides proper door clearance and smooth operation for offset hung installations.
  • Stainless Steel Construction: Durable stainless steel base material with heavy-duty bearings ensures long-lasting performance in high-traffic environments.
  • Fire Rating Compliance: UL listed for use on 3-hour fire rated doors meeting critical safety requirements for commercial buildings.
  • Complete Pivot Set: Includes 0180 top pivot with frame and door leaf components plus 0195 bottom pivot for comprehensive installation.
  • Intermediate Pivot Compatibility: Works with 019 intermediate pivot (ordered separately) for doors ranging from 60" to 90" tall with additional pivots for every 30" of additional height.
  • Professional Installation Components: Frame leaf mortises into header, door leaf mortises into top and bottom of door, with bottom leaf mortising into side jamb and resting on floor.
  • BAA Qualified: Meets Buy American Act requirements for government and institutional projects requiring domestic sourcing compliance.

Technical Specifications

  • Application: Standard Door
  • BAA Qualified: Yes
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Weight: Up to 450 lbs
  • Duty Level: Standard Duty
  • Electronic: No
  • Fire Rated Time: 3 hours
  • Fire Rating: Yes
  • Hang Type: Offset Hung
  • Keyed: N/A
  • Keyed Function: N/A
  • Mounting Method: Offset
  • Pivot Type: Intermediate
  • Product Attribute: Pivots
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: 180
  • Product Subgroup: Pivots and Pivot Sets
  • Product Substrate: Stainless Steel
  • Product Type: Pivot Sets - Offset
  • Subcategory: Door Pivots

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Fire-Rated Door Applications

Why Choose ABH Quality?

ABH pivot hardware delivers professional-grade reliability with stainless steel construction and heavy-duty bearings rated for doors up to 450 pounds. UL listed for 3-hour fire rated applications and BAA qualified for government projects. Engineered for demanding commercial applications where dependable door support and fire safety compliance are essential.

Product Specs

Product Group:
Door Hinges and Pivots
Product Subgroup:
Pivots and Pivot Sets
Product Type:
Pivot Sets - Offset
Subcategory:
Door Pivots
Commercial/Residential:
Commercial
Hang Type:
Offset Hung
Keyed:
N/A
Keyed Function:
N/A
BAA Qualified:
Yes
Duty Level:
Standard Duty
Fire Rated Time:
3 hours
Electronic:
No
Door Weight:
Up to 450 lbs
Pivot Type:
Intermediate
Mounting Method:
Offset
Application:
Standard Door
Product Attribute:
Pivots
Product Model:
180
Fire Rating:
Yes
Product Category:
Door Hinges and Pivots
Product Substrate:
Stainless Steel
Department:
Door Hardware

ABH 0195-RH-US32D – Frequently Asked Questions

1) Is the ABH 0195 pivot set approved for a 3-hour fire rated door?
It is UL listed for use on 3-hour fire rated doors, which covers stair enclosures, shaft openings, and other assemblies where the door carries a 3-hour label. That is the ceiling, so it also serves 90-minute and lesser rated openings. If your specification calls for domestic sourcing, the set is also BAA qualified for Buy American Act projects.
2) What do I need to order for an ABH 0195 offset pivot set, and what comes in it?
Four things get specified: model, offset, handing, and finish. Order the 0195 Pivot Set and you get the 0180 top pivot (frame leaf and door leaf) plus the 0195B bottom pivot. The 0180 top pivot and the 0195B bottom pivot are also sold individually, which is how you handle a replacement of just one end. Offset is 3/4 inch only. Handing is left or right, and pivots are handed hardware, so you have to know which way the door swings before you order.
3) Do I need intermediate pivots for a tall door on an ABH 0195 set?
Yes, once the door is 60 inches tall or more. The 0195 set works with the ABH 019 intermediate pivot, ordered separately, for doors from 60 to 90 inches, with an additional intermediate pivot for every 30 inches of height beyond that. The top and bottom pivots in the set carry the load; the intermediate keeps a tall leaf from racking. Budget for them on the order, since they do not ship with the set.
4) What mortising does an offset pivot set need in the door and frame?
Three preps. The 0180 frame leaf mortises into the header, the door leaf mortises into the top of the door, and the bottom leaf mortises into the side jamb with the door leaf at the bottom of the door, resting on the floor. That means the floor has to carry the bottom pivot, and both the header and the jamb need machining, which is why offset pivots are usually planned into the frame rather than retrofit onto a butt-hinged opening. Use the ABH 0195 template drawing for exact layout before you cut.
5) What is a straight equivalent to the ABH 0195 pivot set for a 3/4 inch offset hung door?
The Calibre Door Closers PV1000 is also a 3/4 inch offset flush pivot set, so it addresses the same offset hung geometry as the ABH 0195, which is built for offset hung doors with a 3/4 inch offset. The difference a specifier cares about is the ABH 0195 side: it is a stainless steel set rated for doors up to 450 lbs and UL listed for use on 3-hour fire rated doors, and it is BAA qualified for government and institutional work. The PV1000 is part of Calibre's CA/Hardware Series. If the opening is fire rated or the door is heavy, the 0195 is the set that carries those ratings; if the job is a non-rated interior opening on the same 3/4 inch offset layout, the PV1000 covers the same hanging method.
6) Which offset pivot set should I use on a fire rated opening if I am cross-shopping ABH and BEST?
Both carry a fire rating: the ABH 0195 pivot set is fire rated with a 3-hour fire rated time, and the BEST A3 System offset hung pivot set is also fire rated. Both are offset hung sets, so either hangs the door the same way. The 0195 states the load and material a heavy opening needs to be checked against - stainless steel construction, doors up to 450 lbs, and BAA qualification for federal and institutional specifications. For a facility standardizing on a documented 3-hour rating and a domestic sourcing requirement, the 0195 is the one whose rated time and BAA status are stated outright.
7) Should I use offset pivots or continuous hinges on a heavy commercial door?
Offset pivots like the ABH 0195 hang the door on a single point top and bottom, so the load goes into the floor and header rather than the jamb, which is why they suit doors up to 450 pounds and let the door swing clear of the frame with a 3/4 inch offset. They are offset hung, single acting hardware. Continuous hinges spread load down the full jamb and mount to the face of an existing frame with no header or floor prep, so they are the easier choice on a retrofit where you cannot machine the header or set a floor pivot. Pick pivots when the door is heavy, wide, or the opening is being detailed new.
8) What other 3/4 inch offset pivot sets can I use instead of the ABH 0195?
The Calibre Door Closers PV1000 is a 3/4 inch offset flush pivot set, so it matches the ABH 0195 on offset dimension. The BEST A3 System offset hung pivot set is another offset hung option and is fire rated. Where the ABH 0195 is specified by weight, hold onto it: the 450 pound and 48 inch width rating plus the UL listing for 3-hour fire doors is what the spec is usually leaning on, and neither peer is listed here with a weight capacity you can check that against.
9) Is the ABH 0195 an electrified pivot for transferring power to the door?
No. The 0195 is a mechanical offset pivot set with no electrical option, so it will not carry power through to an electric lock, exit device, or card reader on the door. For a powered opening you will need a separate electric power transfer or an electrified hinge in the jamb alongside these pivots.
10) Can I use an intermediate pivot in place of a top and bottom pivot set on a tall door?
No - an intermediate pivot is not a substitute for the top and bottom set, it is an addition to it. The ABH 0195 set carries the door on the 0180 top pivot and the 0195 bottom pivot; the 019 intermediate pivot is ordered separately and is used on doors from 60 inches to 90 inches tall, with an additional pivot for every 30 inches of further height. A door that needs intermediate support still needs the top and bottom set beneath it. The same distinction applies when cross-shopping: the Calibre PV1000 and the BEST A3 System are offset hung pivot sets, meaning they replace the set, not the intermediate.
11) Can I get ABH 0195 pivots in oil rubbed bronze to match the rest of my door hardware?
Oil Rubbed Bronze is one of fourteen finishes on the 0195 pivot set. The full range is Black Suede Powder Coat, Bright Brass, Bright Bronze, Bright Chrome, Bright Stainless Steel, Oil Rubbed Bronze, Painted Aluminum, Painted Brass, Painted Dark Bronze, Painted Satin Bronze, Satin Brass, Satin Bronze, Satin Stainless Steel, and White Suede Powder Coat. For a building standard across multiple openings, the painted and suede powder coat options are the ones that let you match a frame color rather than a plated hardware finish.
12) My floor is out of level under a pivoted door. Is there an adjustment on the ABH 0195 bottom pivot?
ABH publishes an extension bottom spindle for the 0195, which is what you use when the standard bottom spindle does not reach because of floor conditions or a thicker floor finish. Since the bottom leaf mortises into the side jamb and rests on the floor, the floor build-up under the pivot point is what drives that call, so check it before the door is hung rather than after.
