ABH L0147 Pivot Set - 3/4" Offset
- Handed - Specify LH or RH
- Maximum door load 800 pounds
- Maxium door width - 48"
- UL listed for use on 3-hour fire rated doors - Standard
- Heavy Duty bearings
- Stainless steel base material
- Average weight per unit = 5 lbs
- Doors ranging from 60" to 90” tall should use one intermediate pivot. An additional intermediate pivot should be used for each additional 30" in door height
- Includes:
- L0180 Top Pivot
- Frame leaf mortises into header
- Door leaf mortises into top of door
- L0147 Bottom Pivot
- Bottom leaf mounts on top of finished floor
- Door leaf mortises into botton of door
- L0180 Top Pivot
TEMPLATES
TECH MEMOS
CROSS REFERENCE CHARTS
- Brand:
- ABH
- Category:
- Door Hinges and Pivots
- Series:
- L0147 Series
- Product Group:
- Door Hinges and Pivots
- Product Subgroup:
- Pivots and Pivot Sets
- Product Type:
- Pivots - Offset
- Subcategory:
- Door Pivots
- Commercial/Residential:
- Commercial
- Hang Type:
- Offset Hung
- Keyed:
- N/A
- Keyed Function:
- N/A
- Model:
- L0147
- BAA Qualified:
- Yes
