ABUS Permit Redbox™, 20-Lock Capacity, Powder Coated Steel
- Incorporates permit-to-work procedures and group lockout box in one unit
- Holds up to 20 padlocks
- Made of powder-coatedsteel to endure harsh settings
- Enclosed wall-bracket makes the box suitable for stationary and mobile use
PERMIT-TO-WORK TAKEN TO THE NEXT LEVEL
Common processes for safely shutting down systems in plants are often accompanied by documents called permits to work.
The B810 Permit Redbox™ enables not only the storage of machinery and system locks, but also the integration of these documents. It thereby combines precision system security with the necessary safeguarding of the permits in a large, lockable viewing window. For more security and transparency during maintenance.
Technology:
- Sturdy box made of powder-coated sheet steel
- Large, lockable front pane for holding permits to work (A4 format)
- With 20 receptacles for personal padlocks plus 3 additional ones for authorized persons
- Large storage area with hook rails for up to 24 machine locks
- Has a carrying handle for mobile deployment
- Accompanied by a wall mount for stationary use of the box
- Quick-release button inside for optionally attaching the box to the wall mount
- Cutouts all around to let in more light and provide a better view inside
- Has a deposit slot on the side for keys including key chain
Manufacturer Resources
ABUS 2021 Product Catalog
Product Specs
- Subcategory:
- Padlocks
- Product Group:
- Other / Miscellaneous Hardware
- Series:
- Permit Redbox
- Shackle Diameter:
- 9/32"
- Product Subgroup:
- Padlocks
- Product Type:
- Lockout/Tagout Hasps
- Commercial/Residential:
- Commercial
- Product Model:
- B810
- Product Category:
- Other / Miscellaneous Hardware
- Product Width:
- 9-29/64"
- Department:
- Door Hardware
ABUS B810 – Frequently Asked Questions
1) How many padlocks does the ABUS B810 Permit Redbox hold?
The B810 Permit Redbox takes 20 personal padlocks, plus 3 more receptacles reserved for authorized persons, so a crew of 20 can each apply their own lock and a supervisor or permit holder still has positions available. Inside there is also a large storage area with hook rails for up to 24 machine locks, which is where the isolation locks pulled off the equipment go while the work is in progress.
2) What shackle size fits the ABUS Permit Redbox lock receptacles?
The receptacles are sized for a 9/32 inch shackle diameter. Standard safety lockout padlocks in that shackle size drop straight in; a heavier shackle will not pass through the holes, so check the shackle on the padlocks your crew already carries before standardizing on this box.
3) Can the B810 Permit Redbox hold the permit-to-work paperwork as well as the locks?
That is the point of the B810. It has a large lockable front pane that holds a permit to work in A4 format, so the authorization document is secured in the same unit as the group lockout locks rather than sitting in a folder in the site office. Combining the two means the permit cannot be removed or altered while the locks are applied.
4) Does the ABUS Permit Redbox mount to a wall or can it be carried to the job?
Both. A wall mount is supplied for stationary use, and a quick-release button inside lets you take the box off the bracket and carry it away by its handle. Facilities that run lockouts at a fixed isolation panel leave it mounted; maintenance crews working across a plant carry it to the equipment.
5) Where do the isolation keys go in a group lockout box like the ABUS B810?
There is a deposit slot on the side that takes keys with their key chain attached. The isolating technician drops the machine keys in through the slot, then every worker hangs a personal padlock on the box. Nobody retrieves the keys until all 20 personal locks are off, which is what makes the group lockout hold.
6) Do I need a group lockout box or is a lockout hasp enough for my crew?
A hasp gives you roughly six lock positions on a single energy isolation point. The B810 is for the other situation: multiple isolation points and a bigger crew. It stores the machine locks and their keys inside, carries 20 personal padlocks on the outside plus 3 authorized-person positions, and secures the permit to work in a lockable pane. If you are locking one valve with a handful of people, a hasp is the simpler buy. If a shutdown involves several isolations, a documented permit and a full crew, the box is what handles it.
7) Is the ABUS Permit Redbox built for a plant floor or just an office?
It is a commercial-duty unit made from powder coated sheet steel to stand up to harsh settings, which is what a process plant, boiler room or mechanical space asks of it. Cutouts around the body let light in so the contents are visible without opening the box.
