Accentra 5430LN Pacific Beach Heavy Duty Grade 1 Utility/Asylum/Institutional Cylindrical Lever Lock

Accentra 5430LN Pacific Beach Heavy Duty Grade 1 Cylindrical Lever Lock

Professional Grade 1 Cylindrical Lockset for Institutional Applications

The Accentra 5430LN Pacific Beach lever lock delivers heavy-duty Grade 1 performance for asylum, institutional, and utility applications. This cylindrical lockset features a 1/2" stainless steel latchbolt throw, adjustable door thickness from 1-3/4" to 2-1/4", and 2-3/4" standard backset with extension options available. ANSI/BHMA Grade 1 certified and UL/cUL fire-rated up to 3 hours, this lockset provides reliable access control for demanding commercial environments.

Professional Features & Benefits

• ANSI/BHMA: A156.2, Series 4000 Grade 1
• UL/cUL: UL/cUL fire-rated up to 3 hours
• Windstorm: Certified (refer to local codes)
• Mechanism: Heavy-gauge steel, zinc-plated, dichromated
• Backset: 2-3/4" standard; 3-3/4" or 5" extension link available to order
• Latchbolt: 1/2" stainless steel throw standard; 3/4" throw available to order
• Guardbolt: Deadlocks latchbolt when door is closed; standard on all locking functions
• Door Thickness: Adjustable from 1-3/4" to 2-1/4"
• Fronts: 2-1/4" x 1-1/8" beveled standard; flat fronts available to order
• Lead Shielding: Available to order
• Cylinders: Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order. For other cylinder and keying options, see page 31.
• Reversibility: Non-handed
• Strikes: 1-1/4" curved lip for 1-3/4" door standard; other lip lengths available to order; all reversible
• Finishes: Available in 13 finishes, including PVD lifetime finish options for 613. PVD is standard for 605 and 606
• Warranty: 7-year mechanical

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness from 1-3/4" to 2-1/4", backset requirements, and handing as applicable to this product.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces for the cylindrical lockset installation.
3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions for the 2-3/4" standard backset or extension link configuration.
4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications, ensuring proper alignment of the guardbolt mechanism.
5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion, verifying free wheeling lever mechanism function.
6. Test device operation to verify proper function including latchbolt throw, guardbolt deadlocking, and lever return spring operation. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Healthcare and Medical Facilities
• Educational Institutions and Schools
• Government and Municipal Buildings
• Correctional and Detention Facilities
• Mental Health and Treatment Centers
• Industrial and Manufacturing Facilities
• Commercial Office Buildings

Why Choose Accentra Quality?

Accentra cylindrical lever locks deliver professional-grade reliability with heavy-gauge steel construction and Grade 1 certification for demanding institutional applications. The 7-year mechanical warranty and UL/cUL fire rating up to 3 hours demonstrate the manufacturer's commitment to quality and safety. Engineered for demanding commercial applications where dependable access control and durability are essential.
