Adams Rite 31-0944-IP Top Actuator Assembly for 8600 CVR and 4781 Series Exit Devices

Adams Rite 31-0944-IP Top Actuator Assembly for 8600 CVR and 4781 Series Exit Devices

(No reviews yet) Write a Review

Model: 31-0944-IP

In Stock (leaves warehouse same day if ordered before 3pm ET)

$25.73
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Adams Rite 31-0944-IP Top Actuator Assembly for 8600 CVR and 4781 Series Exit Devices

Professional Replacement Component for Concealed Vertical Rod Systems

The Adams Rite 31-0944-IP Top Actuator Assembly is a critical replacement component designed specifically for 8600 Concealed Vertical Rod (CVR) and 4781 2-Point Deadlatch exit device systems. This precision-engineered actuator assembly ensures reliable top latch operation in glass aluminum door applications. Compatible with both 4781 and 8600 series devices, this component maintains the operational integrity of concealed vertical rod exit systems in commercial installations.

Professional Features & Benefits

  • ANSI/BHMA Grade 1 certified
  • Narrow stile aluminum door construction
  • Rim (8300/8400) and top-of-door mounted (8800/8700/EX88) configurations
  • Stainless steel touchbar / crossbar
  • UL 10C fire door listed
  • Panic-proof single-motion egress
  • Available with electric latch retraction
  • Compatible with 7800 electric strike
  • Multiple trim options and levers
  • Field-reversible handing

Technical Specifications

  • Door Application: Narrow stile aluminum doors
  • Configuration: Rim, mortise, top-of-door mounted
  • Egress: Single-motion panic proof
  • Compatible Strike: 7800 Series electric strike
  • Fire Rating: UL 10C listed
  • ANSI/BHMA: Grade 1
  • Handing: Field reversible

Installation & Operation

This actuator assembly is designed for use with compatible Adams Rite 8600 CVR and 4781 series exit devices. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Glass Door Systems
  • Aluminum Storefront Applications
  • Office Building Entry Systems
  • Retail Facility Access Points
  • Educational Institution Glass Doors
  • Healthcare Facility Entrance Systems
  • Multi-Tenant Building Access

Why Choose Adams Rite Quality?

Adams Rite actuator assemblies deliver professional-grade reliability with precision manufacturing designed for demanding commercial door hardware applications. Individual packaging ensures component integrity during storage and installation. Engineered for seamless integration with existing Adams Rite exit device systems where dependable performance is essential.

Manufacturer Resources

Adams Rite Product Catalog

Product Specs

Product Group:
Parts and Accessories
Product Category:
Parts and Accessories
Department:
Door Hardware
Commercial/Residential:
Commercial
Product Subgroup:
Parts and Accessories
Product Type:
Parts and Accessories

Adams Rite 31-0944-IP – Frequently Asked Questions

1) Which Adams Rite exit devices does the 31-0944-IP top actuator assembly fit?
The 31-0944-IP top actuator is the replacement top actuator for Adams Rite 8600 Concealed Vertical Rod (CVR) exit devices and 4781 2-Point Deadlatch devices. Adams Rite specifies the same part across both families, so one part number covers a storefront line running a mix of 8600 CVR and 4781 openings. It is a component only, not a complete device, so the existing 8600 or 4781 chassis and rods stay in the door.
2) My storefront door's top latch stopped throwing but the bottom still works - is the top actuator the part I need?
On an 8600 CVR or 4781 device, the top actuator is what converts the pushbar motion into the top latch pull, so a top latch that no longer retracts or no longer throws while the bottom point still works points at that actuator or the top rod. The 31-0944-IP is the replacement actuator assembly for that position. Pull the top rod cover and confirm the rod itself is not bent or disconnected before you order, since a failed rod connection produces the same symptom.
3) Will the Adams Rite 31-0944-IP work on a hollow metal or wood door exit device?
No. The 31-0944-IP actuator belongs to Adams Rite narrow stile aluminum door hardware, specifically the 8600 CVR and 4781 devices used on aluminum storefront and glass entrances. A hollow metal or wood door running a wide stile exit device from another line uses entirely different top latch geometry, and this part will not adapt to it.
4) The top of a glass aluminum door is not latching - is the fix a top actuator assembly or a strike?
It depends on which locking system is on the door. On an Adams Rite 8600 concealed vertical rod or 4781 exit device, the top actuator assembly is the part that transfers touchbar motion to the top latch, and the 31-0944-IP is that assembly. On a glass door running a Codelocks CL4000 or CL4500 glass door lock, the corresponding part is the CL4000-RSB glass door strike box, which is the receiving hardware rather than an actuator. Identify the device on the door first, because the two are not interchangeable components.
5) Is the Securitron AOS armature offset strike a replacement for an Adams Rite 31-0944-IP top actuator?
No. The Securitron AOS is an armature offset strike, a mounting component for an electromagnetic lock's armature. The Adams Rite 31-0944-IP is a top actuator assembly that drives the top latch on 8600 concealed vertical rod and 4781 series exit devices. The two sit in different locking systems: the AOS pairs with a magnet holding the door shut, while the 31-0944-IP is an internal working part of a mechanical CVR exit device. Replacing a failed top actuator means sourcing the actuator assembly for the 8600 CVR or 4781 device on the door.
6) Is the Adams Rite 31-0944-IP a commercial-duty part or a residential one?
Strictly commercial. The 31-0944-IP actuator is Adams Rite commercial door hardware for aluminum storefront entrances, the kind of opening found on retail fronts, office lobbies, schools and healthcare entries. It has no residential application, and it ships individually packaged as a service part rather than in bulk.
7) Can an ABH 20020 armature head assembly be used in place of the Adams Rite 31-0944-IP actuator assembly?
No. The ABH 20020 is a standard door armature head assembly with a 1-5/8 inch projection, the door-side half of a magnetic locking arrangement. The Adams Rite 31-0944-IP is a top actuator assembly for 8600 concealed vertical rod and 4781 series exit devices, working inside the exit device to operate the top latch. Neither part performs the other's function, and specifying one where the other is needed leaves the opening without its intended latching.
