Aiphone Aiphone IE-8MD - Selective Call Main Handset for 2 Doors, Up To 6 Rooms IE-8MD

Aiphone IE-8MD - Selective Call Main Handset for 2 Doors, Up To 6 Rooms

(No reviews yet) Write a Review

Model: IE-8MD

In Stock (leaves warehouse same day if ordered before 3pm ET)

$510.00
$494.65
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
FEATURES
  • Selective Call or All Call between handsets
  • Simple 4 conductor wiring between handsets
  • Two doors with selective door release
  • External doorbell can be added
  • AC or DC powered (12~16V AC or 12~18V DC)
SPECIFICATIONS
  • Communication: Handset (full-duplex)
  • Door Release: N/O dry contact, 24V AC/ DC, 350mA
  • Wire Type
    • Door Station to Master Station: 2-cond., overall shield - use Aiphone #822202
    • Master Station to Sub Stations: 4-cond., overall shield - use Aiphone #822206
  • Distance
    • Door Station to Master Station: 500'(22AWG) 1,180'(18AWG)
    • Master Station to farthest Sub Master Station: 245'(22AWG) 580'(18AWG)

Product Specs

Product Type:
Master Stations
Series:
IE-8 Series
Product Group:
Electronic Access Controls
Product Subgroup:
Intercoms
Subcategory:
Audio Intercoms
Commercial/Residential:
Commercial
Electronic:
Yes
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone IE-8MD – Frequently Asked Questions

1) How many door stations and room stations can the Aiphone IE-8MD handle?
The IE-8MD master handset supports two door stations and up to six rooms, with selective call or all-call between handsets. Each of the two doors gets its own selective door release, so you can talk to one entrance and release only that door.
2) What wire do I need to run between the Aiphone IE-8MD master and the door station?
Door station to master runs 2-conductor with overall shield, Aiphone #822202. Master to sub stations is 4-conductor with overall shield, Aiphone #822206. Keep the runs separate; the 2-wire home run goes to the entrance, the 4-wire daisy feeds the room handsets.
3) How far can I run the Aiphone IE-8 intercom wiring?
From the door station to the IE-8MD master, 500 feet on 22AWG or 1,180 feet on 18AWG. From the master to the farthest sub station, 245 feet on 22AWG or 580 feet on 18AWG. On a larger building, step up to 18AWG before you start pulling.
4) Will the IE-8MD release my existing electric strike?
The door release output is a normally open dry contact rated 24V AC/DC at 350mA. That is a switch only, not a power source, so the strike or maglock needs its own transformer or power supply in the circuit. Anything drawing more than 350mA needs a relay between the handset and the lock.
5) What power supply does the Aiphone IE-8MD master station need?
It runs on either 12 to 16V AC or 12 to 18V DC, so an existing low-voltage transformer on site will often do the job. The door release contact is a separate circuit and does not take power from the handset.
6) Is the Aiphone IE-8MD hands-free or a handset intercom?
It is a handset station with full-duplex communication, so both parties can talk at once without pressing a talk button. You lift the handset rather than speak to an open speaker, which is the better choice at a leasing office or front desk where conversations should stay private.
7) Can I add a doorbell or chime to the IE-8 intercom system?
An external doorbell can be added to the system alongside the IE-8MD master. Useful where the resident or front desk wants an audible chime somewhere outside the handset locations.
8) Is the Aiphone IE-8MD suitable for a commercial building?
Yes, it is classed as commercial audio intercom equipment. The two-door, six-room capacity fits small offices, clinics, shops with a rear receiving door, and small multi-tenant buildings where one staffed handset answers both entrances.
