The SBX-AXDV30 is an 18-Gauge stainless steel surface mount 30° box designed for angle mounting the AX-DV video door station. This is applicable for wide or double door entrances where the door station needs to be mounted off to the side of the door and provides a better viewing angle for the camera.

FEATURES

  • Weather resistant
  • Vandal resistant
  • Inside space for cabling
  • Mounts to flat wall surface
  • Opening at bottom for drainage

SPECIFICATIONS

  • Included Hardware: 8x32 with T-15 Torx head
  • Dimensions: 7-11/16" H x 3-7/8" W x 2-7/8" D

Product Specs

Product Type:
Angle Boxes
Series:
AX Series
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Subcategory:
Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone SBX-AXDV30 – Frequently Asked Questions

1) What is the Aiphone SBX-AXDV30 angle box actually for?
The SBX-AXDV30 is a surface mount housing that sets an AX-DV video door station at a 30 degree angle to the wall. You use it where the station cannot sit directly beside the door, wide entrances and double door openings, so the camera looks back across the approach instead of straight out at a blank wall. It is a mounting box only, the AX-DV station itself is a separate order.
2) Will the SBX-AXDV30 box fit on my wall surface, or does it need a cut-in?
It mounts to a flat wall surface as a surface box, no back box cut into the wall. Overall size is 7-11/16 x 3-7/8 x 2-7/8 inches, so you need that much clear flat area at the mounting height. Cable is routed inside the box, and there is an opening at the bottom for drainage.
3) Can the Aiphone SBX-AXDV30 angle box be used outdoors at an exterior entrance?
Yes. The box is weather resistant and vandal resistant, built from 18-gauge stainless steel, with a drainage opening at the bottom so water that gets in runs out rather than sitting against the station. That is the exterior gate and building entry use case.
4) Does the SBX-AXDV30 work with any Aiphone door station, or only the AX-DV?
Only the AX-DV video door station. The SBX-AXDV30 is cut for that station's footprint in the AX Series, so an AX audio-only station or a station from another Aiphone family will not drop into it.
5) Do I need any extra screws or hardware to mount the AX-DV into the SBX-AXDV30?
The mounting hardware comes with the box: 8x32 screws with a T-15 Torx head. You will want a T-15 Torx driver on the truck, since a standard Phillips will not turn them. Wall anchors suited to your substrate are the installer's responsibility.
6) Should I use a 30 degree angle box or mount the AX-DV flat against the wall?
Mount flat when the station sits right at the door and the visitor stands square in front of it. Go to the 30 degree box when the station has to be offset, a wide entry, a pair of doors, or a return wall, and a flat mount would aim the camera past the visitor's shoulder. The angle turns the camera face back toward the approach and gives you a usable image instead of an ear.
7) How does the wiring get into the SBX-AXDV30 angle box?
There is space inside the box for the cabling, so the station's wiring is dressed within the housing rather than run exposed on the wall face. Plan your wall penetration to land inside the 7-11/16 x 3-7/8 x 2-7/8 inch footprint, and keep the bottom drainage opening clear when you route.
8) Is the Aiphone SBX-AXDV30 rated for commercial buildings or is it a residential part?
It is a commercial-grade part, stainless steel construction with vandal resistance, which is what you want at an apartment lobby, a school entrance, or a healthcare service door where the station is exposed to the public.
