AL SERVENTR COMP SPLICE A:6 B:6
Manufacturer Resources
Product Specs
- Connection Type:
- Compression
- Country Of Origin:
- Mexico (MX)
- Insulation Material:
- None
- Number Of Conductors:
- 2
- Product Group:
- Wire & Cable Management
- Product Type:
- Compression Splice Service Entrance
- Selling Unit Of Measure:
- each
- Standards:
- RUS Accepted. Complies with ANSI C119.4 when properly installed on Aluminum-to-Aluminum or Aluminum-to-Copper Conductors.
- Type2:
- Wire or cable compression splice
- Department:
- Electrical
- Product Subgroup:
- Splices
- Product Size:
- 2 Inch
- Installation Category:
- None
Blackburn CS64 – Frequently Asked Questions
1) What conductor sizes does the Blackburn CS64 service entrance splice take?
The CS64 is sized for 6 AWG on both ends, shown in the product designation as A:6 B:6. It joins two conductors, one into each barrel, so it is a straight inline splice rather than a tap or a multi-port connector.
2) Can I use the CS64 splice on aluminum to copper, or only aluminum to aluminum?
Both. The CS64 complies with ANSI C119.4 when properly installed on aluminum-to-aluminum or aluminum-to-copper conductors, which is what you need for a transition splice on a service entrance run. It is also RUS Accepted, which matters on utility and rural electrification work.
3) Is the Blackburn CS64 a crimp connector or a set screw connector?
It is a compression splice, so it is installed with a hydraulic or battery crimp tool and the correct die, not tightened with a screw. Once crimped it is permanent. If you need a connection you can open later for testing or re-termination, use a mechanical set screw splice instead.
4) Does the CS64 splice come insulated, or do I have to tape or shrink over it?
Bare metal, no insulation supplied. After crimping you insulate it yourself, typically with heat shrink tubing or an insulating tape build-up appropriate to the voltage and the environment. Budget for that material separately when you order.
5) How is the Blackburn CS64 sold, individually or in a bag?
Each. One splice per selling unit, so order one per connection you are making. On a three-conductor service entrance splice-out you would need three, plus one more if you are also splicing the neutral.
6) What is the manufacturer part number and where is the Blackburn CS64 made?
The part number is CS64, from Blackburn, and it is manufactured in Mexico. Quote it as CS64 when matching an existing service entrance splice or building out a stock order.
