Anchors 3/4 x 7 Wdg SS (Box 20)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Pack Type:
- Box
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Anchors
Metallics TS6070SS – Frequently Asked Questions
1) Are the Metallics TS6070SS anchors stainless steel?
Yes, the TS6070SS 3/4 x 7 wedge anchor is stainless steel, which is why it gets specified for exterior pads, coastal work, wet mechanical rooms, pool decks, and wash-down areas where a zinc-plated carbon steel anchor would rust and stain the concrete.
2) Will a wedge anchor work in block or brick, or do I need something else?
Wedge anchors like the TS6070SS are for solid, poured concrete. In hollow block, brick, or grout-filled CMU the expansion clip has nothing solid to bite against near the face shell, and you should use a sleeve anchor or a screen tube with adhesive instead.
3) How many anchors come in a box of Metallics TS6070SS?
They ship 20 per box. For a crew setting a run of equipment bases or bollards, that is five four-bolt patterns per box, which is the number to work from when you size a material order.
4) What does the thick end of a 3/4 x 7 wedge anchor leave sticking out for the nut?
A wedge anchor is a one-piece stud with a threaded top, a nut, and a washer, so the TS6070SS gives you 3/4 inch threaded stud above the embedment for the fixture, washer, and nut. The length you leave exposed is set by how deep you drive it, so you size embedment first and let the rest stand proud for your base plate thickness.
5) Is the TS6070SS a reusable anchor if I need to move the equipment later?
No. Once a 3/4 x 7 wedge anchor is set, the expansion clip is permanently engaged in the hole and the anchor cannot be backed out and reused. You can remove the nut and the fixture, but the stud stays. If the layout may change, plan on a removable option such as a threaded insert or an adhesive anchor set in a coupling.
6) Why pick a stainless wedge anchor over a galvanized one for rooftop or outdoor equipment?
Two reasons drive it. Stainless, as on the TS6070SS 3/4 x 7, resists corrosion in wet and salt-air exposure without a coating that can be scraped during driving, and it avoids the rust bleed that stains concrete around a bolt pattern. It also pairs with stainless base plates and framing without the dissimilar-metal issue you get mixing stainless hardware with plain plated steel.
