Anchors 3/4 x 7 Wdg SS (Box 10)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Pack Type:
- Box
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Anchors
Metallics TS607SSD – Frequently Asked Questions
1) What hole size do I drill for a 3/4 inch wedge anchor like the TS607SSD?
Wedge anchors use a hole the same nominal diameter as the anchor, so a 3/4 inch anchor takes a 3/4 inch carbide hammer-drill bit in concrete. Drill deeper than the intended embedment to leave room for dust, blow the hole clean, then drive the TS607SSD through the fixture and tighten the nut to expand the clip.
2) Can I use the Metallics TS607SSD in block, brick, or hollow-core plank?
No. A wedge anchor needs solid concrete to expand against, so the 3/4 x 7 TS607SSD is for poured concrete only. In hollow block or hollow-core plank the clip has nothing to grip and will spin or pull. For those bases use a sleeve anchor, a toggle, or an adhesive anchor with a screen tube instead.
3) Is a stainless wedge anchor worth it over plated steel for outdoor or wet locations?
That's the reason to pick the TS607SSD. It is a stainless steel wedge anchor, so it suits exterior slabs, rooftop equipment curbs, parking structures, wash-down areas and coastal sites where a zinc-plated carbon steel anchor would rust at the collar and stain the concrete. For dry interior work, plated carbon steel does the same mechanical job.
4) Does the TS607SSD come with a nut and washer, or do I order those separately?
Wedge anchors ship as a complete assembly, nut and washer already on the threaded stud along with the expansion clip, which is how the anchor is set. Nothing else is needed to install the TS607SSD besides a 3/4 inch hammer-drill bit, a blow-out bulb or vacuum, and a wrench. If you want stainless hardware above the anchor as well, order stainless nuts and washers separately.
5) Will 10 anchors cover my equipment pad, or should I order more boxes?
The TS607SSD comes 10 to a box, which sets two four-hole bases with two spares, or a bit more than two six-hole frames. Count your holes first: on a larger run of switchgear or rooftop curbs, 3/4 inch anchors go quickly, and mixing boxes from different lots is not an issue since all are the same 3/4 x 7 stainless anchor.
6) What part number do I quote for the 3/4 x 7 stainless wedge anchor from Metallics?
Order it as Metallics TS607SSD. That manufacturer part number is the 3/4 inch by 7 inch stainless steel wedge anchor in a 10-piece box, and it is the only configuration carried under that number, so there is no diameter, length, or finish option to specify with it.
