Anchors 5/8 x 7 Wdg SS (Box 10)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Pack Type:
- Box
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Anchors
Metallics TS5070SS – Frequently Asked Questions
1) What size hole do I drill for the Metallics TS5070SS 5/8 inch wedge anchor?
A 5/8 inch hole. Wedge anchors are drilled at the same nominal diameter as the anchor itself, so a 5/8 x 7 wedge anchor goes into a 5/8 inch carbide-bit hole drilled deeper than the embedment you want, with the dust cleaned out before you set it. Drive the anchor until the nut and washer seat, then torque to expand the clip.
2) Is the TS5070SS wedge anchor stainless steel, and can I use it outdoors?
Stainless steel, which is why it suits exterior and wet locations, unistrut and equipment bases on exposed slabs, pool and coastal work, and anywhere a plated carbon anchor would bleed rust. The "SS" in the 5/8 x 7 Wdg SS designation is the stainless material.
3) How many anchors come in a box of Metallics TS5070SS?
Ten anchors per box, shipped as a box pack. For a run of strut supports or multiple equipment pads, count four anchors per base and order boxes accordingly.
4) Can I use this wedge anchor in block, brick, or hollow-core deck?
Wedge anchors are for solid concrete only. They expand by wedging against the wall of a drilled hole, so they do not develop load in hollow block cells, brick, or hollow-core plank. For those, use a sleeve anchor or a screen tube and adhesive. In poured concrete of adequate thickness, the stainless 5/8 x 7 is the right tool.
5) What is the Metallics part number for the 5/8 by 7 inch stainless wedge anchor?
TS5070SS is the Metallics number for the 5/8 x 7 stainless wedge anchor, sold ten to a box. Quote that number when matching anchors already set on a job so the material and length stay consistent.
6) Do these anchors come with nuts and washers?
A wedge anchor of this style is supplied as a one-piece assembly with the expansion clip, washer, and hex nut already on the stud, so no separate hardware is needed to set it. What you do need on site is a 5/8 inch carbide bit, a hammer drill, a blow-out bulb or vacuum, and a torque wrench to tension the nut.
