Arrow 16CR-004 SFIC Staked-On Cam Replacement Part for Sargent Cylinders
The Arrow 16CR-004 is a Small Format Interchangeable Core (SFIC) staked-on cam designed as a precision replacement part for Sargent cylinder applications. Engineered for commercial-grade performance, this cam (004 configuration) integrates directly with compatible Sargent lock cylinders, ensuring reliable operation and accurate mechanical engagement. As a genuine Arrow replacement component, it is manufactured to meet the demanding tolerances required for professional door hardware installations.
Key Features
- SFIC Staked-On Design: Small Format Interchangeable Core staked-on cam construction provides secure, precise engagement with compatible Sargent cylinders for dependable lock operation.
- 004 Cam Configuration: Specific 004 cam profile engineered to match Sargent cylinder geometry, ensuring accurate mechanical alignment and function.
- Sargent Compatibility: Designed specifically for use with Sargent lock cylinder platforms, making it an ideal drop-in replacement for worn or damaged cam components.
- Commercial-Grade Construction: Built to the rigorous standards required for commercial door hardware applications, delivering long-lasting performance in high-use environments.
- Genuine Arrow Parts Quality: Manufactured under the Arrow Parts program to maintain original equipment specifications and performance integrity.
Technical Specifications
- Department: Door Hardware
- Product Category: Mechanical Locks
- Product Group: Parts and Accessories
- Subcategory: Parts and Accessories
- Product Subgroup: Parts and Accessories
- Product Type: Cylinders
- Parts and Accessories Type: Replacement Parts
- Commercial/Residential: Commercial
- Product Model: 16CR-004
- Features: Arrow Parts
Typical Applications
- Commercial Office Buildings
- Educational Facilities
- Healthcare Institutions
- Government and Municipal Buildings
- Retail Establishments
- Industrial and Warehouse Facilities
- Multi-Tenant Residential Properties
Why Arrow 16CR-004?
Arrow replacement parts are engineered to original equipment specifications, making the 16CR-004 SFIC staked-on cam a reliable solution for restoring proper cylinder function in Sargent-compatible lock hardware. Designed for commercial applications where precise mechanical performance and component integrity are essential, this cam delivers the consistency and durability that facility managers and security professionals depend on.
Manufacturer Resources
Arrow Express Catalog
Product Specs
- Department:
- Door Hardware
- Product Category:
- Mechanical Locks
- Product Group:
- Parts and Accessories
- Subcategory:
- Parts and Accessories
- Product Subgroup:
- Parts and Accessories
- Product Type:
- Cylinders
- Parts and Accessories Type:
- Replacement Parts
- Commercial/Residential:
- Commercial
- Product Model:
- 16CR-004
- Features:
- Arrow Parts
Arrow 16CR-004 – Frequently Asked Questions
1) What exactly is the Arrow 16CR-004 cam, and what does it do?
The 16CR-004 is a staked-on cam for small format interchangeable core (SFIC) cylinders, built as a replacement component for Sargent cylinder applications. The cam is the part that transfers key rotation from the cylinder to the lock mechanism, so a worn or damaged cam is what you replace when the key turns but the lock does not respond correctly. It is a commercial-grade part, not a complete cylinder or core.
2) Will the Arrow 16CR-004 work on a Sargent cylinder?
Yes. The 004 cam profile is made to match Sargent cylinder geometry, and the part is specified for use with Sargent lock cylinder platforms as a drop-in replacement for a worn or damaged cam. If your cylinder is another brand, this is not the cam to order.
3) Does the 16CR-004 come with a cylinder or core, or is it just the cam?
Just the cam. The 16CR-004 is a replacement part, so you supply the SFIC cylinder housing and core. If you actually need a complete interchangeable core instead, look at a core such as the BEST 1C Series 5-pin cylinder core rather than a cam.
4) I have a Sargent knob or lever cylinder that is worn out. Should I replace the cam or the whole cylinder?
If the cylinder body and core are sound and only the cam is chewed up or loose, the 16CR-004 restores the drive without touching your keying. If the cylinder itself is damaged or you want to move away from SFIC, a complete Sargent-compatible replacement cylinder such as the Kaba Ilco 1579 knob and lever cylinder for Sargent is the swap to make instead.
5) If the Sargent cylinder itself is worn out, not just the cam, what replaces the whole cylinder?
The Arrow 16CR-004 is a staked-on cam only - a 004 cam replacement part for Sargent cylinders, not a keyed cylinder. If the cylinder body or plug is the problem, Kaba Ilco makes the 1579 Series knob and lever cylinder specifically for Sargent, which replaces the complete cylinder rather than the cam alone. Choose the 16CR-004 when the cylinder is sound and only the cam needs restoring.
6) Does a mortise cylinder with an A01 or A02 cam do the same job as the Arrow 16CR-004?
No. The 16CR-004 is a loose 004 staked-on cam for Sargent SFIC cylinder applications. An A01 or A02 cam comes already fitted to a complete cylinder - for example the Corbin Russwin 1000 Grade 1 mortise cylinder at 1-1/2 inch with an A02 straight cam, or the Corbin Russwin 1070 Grade 1 housing at 1-1/4 inch with an A01 cloverleaf cam. Those are whole cylinders on the Corbin Russwin cam standard, so they are a different purchase than an Arrow cam for a Sargent cylinder.
7) What does "staked-on" mean for this cam, and can I reuse it if I swap cylinders?
Staked-on means the cam is mechanically staked to the cylinder plug rather than held by a screw, so it is not a part you unthread and move from housing to housing. Plan on it staying with the cylinder it is installed on, and order a new 16CR-004 for each cylinder being rebuilt.
8) Is a cam letter like A01 or A02 the same thing as this 004 cam?
No, and mixing them up is the usual ordering mistake. The 004 designation is Arrow's part identity for this SFIC staked-on cam matched to Sargent geometry. Cam letters such as the Corbin Russwin A01 cloverleaf or A02 straight cam are separate mortise-cylinder cam profiles on other brands' housings and do not cross-reference to a Sargent SFIC staked-on cam.
9) We are converting Sargent openings to interchangeable core keying - what do we order instead of a cam?
A cam like the Arrow 16CR-004 restores an existing Sargent cylinder; it does not convert an opening to interchangeable core keying. For an SFIC core itself, BEST offers the 1C Series standard 5-pin cylinder core and the 1CB 150 Series interchangeable core cylinder, and the drill-resistant 1CDF patented 7-pin brass core in the 150 Series. For full size interchangeable core instead of small format, the Schlage 20-057 is a 6-pin FSIC rim cylinder with a convertible tailpiece cam.
10) A rim exit device needs a cylinder - is the 16CR-004 cam the right part?
No. Rim devices take a rim cylinder with a tailpiece, not a staked-on SFIC cam. Schlage 20-021 is a 6-pin rim cylinder with a vertical tailpiece cam and 20-022 is the same cylinder with a horizontal tailpiece cam; the Corbin Russwin 3070 is a 6-pin rim cylinder housing with a 1-7/8 inch tailpiece. Match the tailpiece orientation to the device. The Arrow 16CR-004 applies only where a Sargent cylinder needs its 004 cam replaced.
11) What should I use on an aluminum storefront deadlock rather than an Arrow cam?
Storefront deadlocks take a mortise cylinder or cylinder pull, not a loose cam. Adams Rite makes the 4036 Grade 1 mortise cylinder for a 1/2 inch minimum door thickness, and the 4024 cylinder pull with trim plate mounting and the 4025 five-pin cylinder pull with through-screws, both for the MS1847 deadlock/deadlatch. The Arrow 16CR-004 is a commercial replacement cam for Sargent cylinders and has no role in that assembly.
12) Is this cam suitable for a school or hospital keying program, or is it residential hardware?
It is a commercial part. The 16CR-004 is specified for commercial door hardware use and is applied in office buildings, schools, healthcare facilities, government buildings, retail, industrial sites, and multi-tenant residential properties, which makes it a normal stocking item for a facility running SFIC on Sargent hardware.
13) Do I need to rekey anything after installing the 16CR-004 cam?
No. Replacing the cam changes how the plug drives the lock, not the pinning, so an SFIC core keyed to your system continues to operate on the same keys. Only the cam is being changed out.
14) Is there a key-in-knob or lever cylinder alternative if the Sargent lock cannot be rebuilt with a cam?
Yes. Kaba Ilco offers the 1539 Series key-in-knob/lever universal cylinder, the 1599 key-in-knob replacement cylinder, and the 1549 key-in-deadbolt cylinder; Falcon's A23161-05 G is a key-in-lever cylinder for RU/T series with a 6-pin G keyway, keyed different and supplied with two cut keys. Those are complete cylinders, whereas the Arrow 16CR-004 supplies only the 004 staked-on cam for a Sargent cylinder.
15) We need a non-functioning cylinder for appearance on one leaf - does the Arrow cam help?
No. A cam is an internal drive component. For a non-keyed appearance match, the BEST 12E Series dummy rim cylinder with a 1-5/32 inch diameter is the part built for that purpose. Keep the Arrow 16CR-004 for openings where a working Sargent cylinder needs its 004 cam restored.
