Arrow 16CR-AM2 SFIC Staked-On Clover Cam Replacement Part for Cylinders
The Arrow 16CR-AM2 is a SFIC (Small Format Interchangeable Core) staked-on clover cam designed as a precision replacement part for compatible Arrow cylinder applications. Engineered for commercial-grade door hardware, this cam component integrates directly with SFIC cylinder configurations, providing reliable mechanical actuation in lock cylinder assemblies. Purpose-built as a genuine Arrow replacement part, the 16CR-AM2 ensures proper fit and function within Arrow cylinder systems.
Key Features
- SFIC Compatibility: Designed specifically for Small Format Interchangeable Core (SFIC) cylinder systems, ensuring seamless integration with compatible Arrow lock assemblies.
- Staked-On Design: The staked-on cam attachment method provides a secure, permanent connection to the cylinder core for dependable mechanical performance.
- Clover Cam Profile: Clover-style cam geometry delivers reliable engagement with lock mechanism components for consistent actuating performance.
- Genuine Arrow Replacement Part: Manufactured as an authentic Arrow replacement component, ensuring proper dimensional tolerances and material compatibility with original hardware.
- Commercial-Grade Construction: Built to the performance standards expected of commercial door hardware for use in demanding professional environments.
- Direct Replacement: Engineered for straightforward replacement in compatible Arrow cylinder assemblies, minimizing downtime during maintenance or repair.
Technical Specifications
- Department: Door Hardware
- Product Category: Mechanical Locks
- Product Group: Parts and Accessories
- Subcategory: Parts and Accessories
- Product Subgroup: Parts and Accessories
- Product Type: Cylinders
- Parts and Accessories Type: Replacement Parts
- Commercial/Residential: Commercial
- Product Model: 16CR-AM2
- Features: Arrow Parts
Typical Applications
- Commercial Office Building Lock Cylinder Maintenance
- Educational Facility Hardware Repair and Upkeep
- Healthcare Institution Door Hardware Servicing
- Government and Municipal Building Lock Maintenance
- Retail and Hospitality Facility Hardware Repairs
- Industrial and Warehouse Access Hardware Servicing
- Multi-Tenant Residential Property Lock Cylinder Replacement
Why Arrow 16CR-AM2?
Arrow has a longstanding reputation for producing reliable, commercial-grade door hardware components, and the 16CR-AM2 SFIC staked-on clover cam upholds that standard as a genuine replacement part. Designed to exacting tolerances for compatibility with Arrow SFIC cylinder systems, this cam delivers the precise mechanical engagement required for dependable lock operation in professional applications. When maintaining or restoring Arrow cylinder assemblies, specifying genuine Arrow replacement parts like the 16CR-AM2 ensures the integrity and performance of the original hardware installation.
Manufacturer Resources
Arrow Express Catalog
Product Specs
- Department:
- Door Hardware
- Product Category:
- Mechanical Locks
- Product Group:
- Parts and Accessories
- Subcategory:
- Parts and Accessories
- Product Subgroup:
- Parts and Accessories
- Product Type:
- Cylinders
- Parts and Accessories Type:
- Replacement Parts
- Commercial/Residential:
- Commercial
- Product Model:
- 16CR-AM2
- Features:
- Arrow Parts
Arrow 16CR-AM2 – Frequently Asked Questions
1) What exactly is the Arrow 16CR-AM2 part?
The 16CR-AM2 is a clover-style cam for Arrow small format interchangeable core (SFIC) cylinder work, attached by staking rather than screwed on. It is a cam only, not a cylinder, not a core, and not a keyed assembly. If you need a working keyed cylinder you are buying the wrong item.
2) Will the Arrow 16CR-AM2 cam fit a BEST or Falcon interchangeable core?
Arrow lists the 16CR-AM2 as a genuine Arrow component built to Arrow's own tolerances for Arrow SFIC cylinder assemblies. Treat it as an Arrow part. If you are servicing BEST cores, buy within that line, for example the BEST 1C Series 5-pin core or the 1CB 150 Series interchangeable core.
3) Is this an SFIC part or a full size interchangeable core part?
Small format. The 16CR-AM2 is built for SFIC (small format interchangeable core) cylinders, the figure-eight core format. For full size interchangeable core work, Schlage's 20-057 FSIC rim cylinder and the 20-057-C FSIC core in C keyway are the full size equivalents and the two formats do not interchange.
4) Is the Arrow 16CR-AM2 clover cam the same thing as a complete mortise cylinder with a cloverleaf cam?
No. The Arrow 16CR-AM2 is a SFIC staked-on clover cam, a replacement cam component for Arrow cylinder assemblies, not a keyed cylinder. If you need a full mortise cylinder that already carries a cloverleaf cam, the Corbin Russwin 1070 Grade 1 series 1-1/4 inch 6-pin mortise housing uses an A01 cloverleaft cam, and the Corbin Russwin 1080 Grade 1 series 1-1/2 inch LFIC mortise cylinder is a 6-pin unit with an A01 cloverleaf cam for Schlage L9000 mortise locks. Those arrive as complete cylinders; the 16CR-AM2 arrives as the cam alone.
5) My cylinder needs a straight cam instead of a clover cam - what should I order?
The Arrow 16CR-AM2 supplies a clover cam profile only. Where the lock case calls for a straight cam, the Corbin Russwin 1000 Grade 1 series mortise cylinder in 1-1/2 inch length is furnished with an A02 straight cam. Confirm the cam profile your lock case requires before ordering, since the 16CR-AM2 cam geometry is clover style.
6) The opening is a rim device, not a mortise lock - does the 16CR-AM2 cam apply?
Rim applications use a tailpiece rather than a mortise cam, so a clover cam is the wrong part there. For rim work, the Schlage 20-021 is a 6-pin rim cylinder with a vertical tailpiece cam and the 20-022 is the same 6-pin rim cylinder with a horizontal tailpiece cam; the Schlage 20-057 is a 6-pin FSIC rim cylinder with a convertible tailpiece cam. The Corbin Russwin 3070 is a 6-pin rim cylinder housing with a 1-7/8 inch tailpiece. The Arrow 16CR-AM2 remains a SFIC clover cam for Arrow cylinder assemblies.
7) Does a staked-on cam mean I cannot swap it out later?
Staking is a permanent mechanical attachment to the cylinder core, so the 16CR-AM2 is not a cam you rotate off and reinstall like a screw-on cam. Plan on it staying where it is put. For mortise applications where you may want to change cam style later, a screw-on cam housing such as the Corbin Russwin 1070 with its A01 cloverleaf cam is the alternative approach.
8) Is a clover cam the same as a cloverleaf cam on mortise cylinders?
Same geometry family. Clover, or cloverleaf, describes the lobed cam profile that drives the lock's actuating slide, and it is the standard mortise cam pattern (the A01 designation on mortise cylinders). Corbin Russwin's 1070 housing and 1080 LFIC mortise cylinder both carry the A01 cloverleaf cam. The Arrow 16CR-AM2 brings that same profile to Arrow SFIC cylinder assemblies.
9) I manage a building standardized on Arrow locks. Should I stock this cam?
If your openings run Arrow SFIC cylinders, the 16CR-AM2 is the cam that keeps them serviceable, and stocking it lets a locksmith rebuild a cylinder instead of replacing the whole assembly. One caution for fleet buyers: it is a component, so it does nothing on its own. Order it alongside the cores or cylinders it goes into.
10) I have an Arrow interconnected lock and need a retrofit cylinder, not a cam - what fits?
The Arrow 16CR-AM2 is a cam component, so it will not serve as a keyed retrofit. For an Arrow JL interconnected lock, the Medeco 1065140 is a 5-pin retrofit cylinder listed for Arrow JL interconnected locks as well as Emtek handleset and deadbolt outside cylinder use. Choose the 16CR-AM2 only when the existing Arrow cylinder assembly needs its clover cam replaced.
11) Instead of replacing the cam on an Arrow SFIC cylinder, can I just swap in a new interchangeable core?
That is a different repair path. The Arrow 16CR-AM2 is a staked-on cam for Small Format Interchangeable Core cylinder assemblies, so it addresses the cam side of the assembly rather than the keying. If the core itself is the problem, interchangeable cores are sold as complete units: the BEST 1C series standard 5-pin cylinder core, the BEST Peaks 1CB 150 series interchangeable core, and the BEST 1CDF drill-resistant patented 7-pin brass 150 series core are all core replacements. Cam work and core swaps are not substitutes for one another.
12) What is the difference between the Arrow 16CR-AM2 and a full size interchangeable core cylinder?
The 16CR-AM2 is built for Small Format Interchangeable Core cylinder systems and is the staked-on clover cam within that assembly. Full size interchangeable core products are complete cores sized to the FSIC standard - the Schlage 20-057-C is an FSIC core in C keyway with 643E aged bronze finish, and the Schlage 20-057 is a 6-pin FSIC rim cylinder with convertible tailpiece cam. Small format and full size cores are not interchangeable with each other, and neither is a source for an SFIC clover cam.
13) For a key-in-knob or key-in-lever cylinder replacement, should I be looking at the 16CR-AM2?
No - that repair calls for a cylinder, not a cam. Key-in-knob and lever replacements include the Kaba Ilco 1539 key-in-knob/lever universal cylinder, the 1579 knob and lever cylinder for Sargent, the 1599 key-in-knob replacement cylinder, and the Falcon A23161-05 G key in lever cylinder with RU/T series 6-pin G keyway, keyed different with two cut keys. The Arrow 16CR-AM2 is the SFIC staked-on clover cam used inside compatible Arrow cylinder assemblies.
14) Is the 16CR-AM2 suitable for commercial buildings or is it a residential part?
Commercial. Arrow classes the 16CR-AM2 as commercial door hardware, and it is a maintenance item for offices, schools, hospitals, municipal buildings, retail and hospitality, warehouses, and multi-tenant residential managed as commercial property.
15) Are there different options or finishes to choose when ordering the 16CR-AM2?
No options to specify. The Arrow 16CR-AM2 cam is ordered as a single configuration under that model number, so there is no finish, hand, or length selection to make.
16) Is there a cam replacement option for an aluminum storefront deadlock instead of the Arrow 16CR-AM2?
Storefront deadlocks are cylinder-and-pull applications rather than SFIC cam work. Adams Rite offers the 4024 cylinder pull with trim plate mounting and the 4025 five pin tumbler cylinder pull with through-screws, both for the Adams Rite MS1847 deadlock/deadlatch, plus the 4036 mortise cylinder, a Grade 1 five-pin unit with a 1/2 inch minimum door thickness. For a wood door, the 4026 five pin tumbler cylinder pull is intended for the Adams Rite 5017 wood door deadlock/deadlatch. The Arrow 16CR-AM2 applies to Arrow SFIC cylinder assemblies.
17) I need a non-keyed filler for an unused cylinder hole - is the 16CR-AM2 what I want?
No. The 16CR-AM2 is a functional clover cam for Arrow SFIC cylinder assemblies and does not fill an opening on its own. A blank position calls for a dummy unit such as the BEST 12E series dummy rim cylinder with a 1-5/32 inch diameter.
