Arrow SRX87 - S1150/S1250/ED910/PEC910 Series Exit Device Trim, Classroom Function, Sierra Lever with Rose

The SRX87 Sierra lever trim is built for Arrow's S1150, S1250, ED910 and PEC910 rim exit devices. It's the outside trim only, so you're mounting it to one of those device chassis already on the door, not buying a complete exit device.

No. The SRX87 is a single-thickness trim rated for 1-3/4 inch doors, which is the standard commercial door thickness. On a 1-3/8 inch door you'd need a trim with a thickness range, such as the Dormakaba E-Plex E5010 exit device lever trim (1-3/8 to 2-1/4 inches) or the Lockey 115P panic trim (1 3/16 to 2 inches).

Handing isn't a factor. The Sierra lever trim is reversible, so the same part covers left and right hand openings. Order by finish and cylinder type instead.

That depends on which version you order. The SRX87 is built in three cylinder configurations: Standard (Arrow keyway), Schlage C keyway for buildings already keyed to Schlage C, and SFIC prep less core, which is drilled for a small format interchangeable core you supply from your own system. Pick SFIC if your facility already runs interchangeable cores; pick Schlage C if you want the new door on the existing key.

Yes. Keying is specified at order: keyed different is the standard, keyed alike is available when you want one key across multiple openings, and there's a key code field if you're matching an existing system. If you selected the SFIC prep less core version, choose the no-cylinder keying option, since the core comes from your own stock.

Not for a permanently unlocked opening. Classroom function keeps the outside lever locked until it's keyed, so someone has to key it open every morning. For an always-unlocked pull, look at a passage-function trim such as the Deltana LTED80LP for exit device 80. For a lever that retracts the latch when a code is entered, the Dormakaba E-Plex E5010 push button trim with key override handles it without rekeying.

If the device chassis is sound and it's an S1150, S1250, ED910 or PEC910, the SRX87 replaces the outside lever assembly on its own. It's a single-cylinder trim, so the key side is the outside only. Confirm the door is 1-3/4 inches, since that's the thickness this trim is built for, and decide up front whether you're carrying over an existing cylinder (order SFIC prep less core) or want a new one keyed to your system.

The Corbin Russwin K157ET is a Grade 1, heavy duty, classroom-function trim for ED2200 and ED2400 series exit devices, with a rose. It differs from the Arrow SRX87 in one important way beyond the device family: the K157ET is key-only trim, so there is no lever to turn - the key retracts the latch and the door is otherwise pull-only from the outside. The SRX87 gives you a Sierra lever on a rose with a cylinder. If a facility spec calls for Grade 1 classroom trim and the openings carry Corbin Russwin ED2200 or ED2400 devices, the K157ET is the fit; if the spec also calls for outside lever operation, it is not a substitute.

The Detex 08BN is the nearest match in the group: it is a classroom-function exit device trim with an S-lever and a mortise cylinder, built for Detex Value Series devices. The Arrow SRX87 is also classroom function, uses a Sierra lever on a rose, and is keyed. The practical difference is the device family each one bolts to - the SRX87 is made for Arrow S1150, S1250, ED910 and PEC910 series devices, while the 08BN fits Detex Value Series. Trim is not interchangeable across device brands, so match the trim to the device already on the door.

Storeroom trim, such as the Deltana DDS-36 for Exit Device 80 or the Deltana LTED60LST for Exit Device 60, keeps the outside lever locked at all times; the key retracts the latch for entry and the lever relocks behind you. The Arrow SRX87 is classroom function, which lets the key set the outside lever to stay unlocked for a period and then lock it again - the reason it is specified on classrooms and any room a staff member unlocks in the morning and locks at night. If the room should never be left unsecured, storeroom is the correct function; if someone needs to leave it open through the day without propping, classroom is.

No - those are different jobs. The Sargent 802 is a Grade 1 blank plate trim in the PE80 series, the Von Duprin 379L-BE is a Grade 1 heavy duty blank escutcheon for 55 series rim devices, and the Detex 03WS is a trim plate with a cylinder hole for 10, 20, 21 and 27 series devices. Blank trim covers the outside face and gives no outside entry at all; the door becomes exit-only. The Arrow SRX87 is keyed classroom trim with a Sierra lever, so it provides controlled outside entry. If someone needs to get back in through that door, blank trim will not do it.

Two credential-free routes exist. The BEST EXZ, in the EZ Series, is electronic keypad exit device trim with key override, and the Dormakaba E-Plex E5010 is Grade 1 electronic push button exit device lever trim with key override in the E-Plex 5000 Series, rated for doors 1-3/8 inch to 2-1/4 inch thick. For a purely mechanical pushbutton, the Lockey 115P is heavy duty keyless passage lever panic trim with a 1150 lock body and the Lockey 285P is keyless mechanical panic trim with a lever, both for doors 1 3/16 inch to 2 inch thick. The Arrow SRX87 is keyed classroom trim with a single cylinder for 1-3/4 inch doors - it belongs to your existing key system, which is what you want when the facility is keyed alike or on an SFIC core program, and what you are trying to leave behind when turnover keeps forcing rekeys.

Two: 626 satin chrome and 613 oil rubbed bronze. Both are offered with all three cylinder configurations, so a satin chrome SFIC-prep trim or an oil rubbed bronze Schlage C trim are both orderable combinations. 626 is the usual match for institutional and school openings; 613 tends to go with darker commercial and multi-family entries.

The SRX87 mounts on a rose, a compact round trim plate around the lever rather than a full-length escutcheon plate. A rose shows less of the door face, so it works where you don't want to cover existing paint or prep marks. An escutcheon covers more area and hides old holes. If you need the escutcheon look on an Arrow-adjacent opening, comparable escutcheon-style trims include the Von Duprin 379L-BE blank escutcheon for 55 Series rim devices and the Detex A/AN Series straight pull with blank escutcheon.

Commercial. The SRX87 is a keyed lever trim for rim exit devices, the hardware you put on institutional, school, healthcare and multi-family egress doors. It isn't a residential lockset and it doesn't work as a standalone lock; there has to be an Arrow S1150, S1250, ED910 or PEC910 device on the door for it to operate.

Look at the Deltana LTED80LP, a passage-function lever trim for Exit Device 80. Passage trim means the outside lever always retracts the latch and there is no cylinder to key or rekey - suited to corridor and stairwell-side openings that stay unlocked. The Arrow SRX87 is keyed classroom-function trim with a single cylinder, which is what you want when staff need to lock and unlock the outside lever by key. Choosing between them is a security decision at that specific opening, not a matter of which trim is better built.

They are not the same. The Sargent 814 PSB is heavy duty nightlatch pull trim in the 80 series: the key retracts the latch and you pull the door open by the handle, with no lever to operate. The Sargent 862 offset pull handle for exit devices, in the P800 series, is pull hardware only. The Arrow SRX87 is a keyed classroom lever trim with a Sierra lever on a rose. Nightlatch and pull trim suit service and delivery doors where a hand may be full and only key entry is wanted; lever trim suits openings that need to be operable without the key once unlocked, and is what ADA-conscious specs typically call for on the outside of an occupied room.

The Corbin Russwin x650ET is Grade 1 heavy duty dummy lever trim with a rose for ED7000 series exit devices. Dummy trim gives a fixed lever with no latch operation at all - it is there so the leaf matches its neighbor visually and gives a hand something to hold. The Arrow SRX87 is keyed classroom trim that actually operates the device. On a pair of doors where only one leaf is active, the active leaf takes operating trim and the inactive leaf can take dummy trim, so these two often ship together rather than as alternatives.

That depends on the opening, not on the trim. The Detex 90KR is a keyed removable mullion in the 90 Series for rim exit devices - it gives each leaf of a pair a rim device something to latch into, and lifts out by key when a wide opening is needed. The Arrow SRX87 is outside lever trim for Arrow S1150, S1250, ED910 and PEC910 series devices; it addresses how the door is entered, not how the pair is secured at the center. A pair with rim devices generally needs a mullion or a device pair designed to latch to each other, so plan the mullion separately from the trim.

The Deltana LTED80LS is entry-function lever trim for Exit Device 80. Entry function is the pattern most people know from a residential-style lockset - the outside lever locks and unlocks, typically with a button or turn, and the key gets you in. The Arrow SRX87 is classroom function, where control sits with the key on the outside face and there is nothing on the inside to inadvertently secure the room. In schools and other institutional buildings that distinction is deliberate: classroom function stops an occupant from locking the outside lever without a key, which is why it is the function commonly written into facility standards for occupied rooms.

Electric latch retraction is a property of the device, not the trim. The ACSI ED4200-W036 is a Grade 1 wide stile Corbin Russwin ED4000 series rim exit device with 24 volt AC/DC electric latch retraction - a complete device, where the latch pulls back on a signal for access control or scheduled unlocking. The Arrow SRX87 is trim only, for Arrow S1150, S1250, ED910 and PEC910 series devices, and gives mechanical key control of a Sierra lever. If the opening is going on an access control system, the device is the item that has to support it; specify the device first and let the trim follow the device family.

The Detex 0A is A/AN series straight pull trim with a blank escutcheon for Detex Value Series exit devices - a fixed pull with no cylinder and no latch retraction, so the door stays exit-only from inside and is pull-only outside once unlatched. The Arrow SRX87 is keyed lever trim with a single cylinder, offered with a standard cylinder, a Schlage C keyway, or an SFIC prep less core. If the outside face is meant to be dead and the door is entered from elsewhere, straight pull trim is the simpler part; if that door has to be an entry point for staff, it is not.
