Eaton B-Line series Flextray wire basket tray, 4" X 118", Attach with (FTHDWE) 1/4" and top washer, Black powder coat, Steel, Solid bottom inserts
Manufacturer Resources
Product Specs
- Application:
- Attach with (FTHDWE) 1/4 in and top washer
- Certifications:
- UL Listed
- Product Height:
- .25 in
- Product Length Depth:
- 118 in
- Product Weight:
- 1 lb
- Product Width:
- 4 in
- Department:
- Electrical
- Product Group:
- Accessories
- Product Subgroup:
- Inserts
- Product Type:
- Solid bottom inserts
- Product Finish:
- Flat black powder coat
- Product Details:
- Solid bottom inserts
- Product Material:
- Steel
B-LINE INSERT 4X118BLE – Frequently Asked Questions
1) What does a solid bottom insert do in a Flextray wire basket tray?
The Eaton B-Line solid bottom insert is a flat steel liner that drops into the bottom of a Flextray wire basket run, giving cable a continuous bearing surface instead of the open wire mesh. It is used where you want to protect small-diameter or sensitive cable from the wire grid, or keep cable from sagging through the basket. This one is 4 inches wide by 118 inches long and .25 inch high, in steel with a flat black powder coat.
2) What hardware do I need to fasten the Flextray solid bottom insert into the basket?
Mounting is by 1/4 inch hardware with a top washer, using B-Line FTHDWE hardware. The washer sits on top so the insert is clamped down against the wire mesh. That hardware is a separate item from the insert itself, so add it to the order by the number of attachment points your run needs.
3) Is this Flextray insert UL Listed for use in a commercial electrical installation?
Yes, the solid bottom insert is UL Listed. For an institutional or MRO spec that calls for listed cable tray components throughout the run, that listing covers the insert as well as the basket.
4) Will a solid bottom insert hold up in a data room or plenum ceiling run?
The insert is steel with a flat black powder coat finish, so it takes the abrasion of pulling cable across it better than a plastic liner and the black finish blends into an open or exposed ceiling. It weighs 1 lb, so adding it to a suspended Flextray run puts negligible extra load on the trapeze or threaded rod supports.
5) What is the part number for the 4 inch black Flextray solid bottom insert?
Order it as Eaton B-Line INSERT 4X118BLE. The BLE suffix carries the flat black powder coat finish, and the 4X118 is the 4 inch width by 118 inch length.
6) How much height does the insert add inside the basket tray?
Only .25 inch. The insert sits on the bottom wires and takes a quarter inch off your usable fill depth, which is worth accounting for if the run is already close to its fill limit before you line it.
