B-Line Eaton series Flextray wire basket tray, 6" X 118", Attach with 1/4" and top washer, Black powder coat, Steel, Solid bottom inserts

It gives the open wire mesh a flat, continuous floor. The Eaton B-Line INSERT 6X118 BLE is a steel panel 6 inches wide and 118 inches long that drops into the bottom of the basket run so small cable, patch cords, or fiber jumpers ride on a solid surface instead of sagging through the wire grid. It is a tray accessory, not a tray, so you still need the basket section itself.

It is sized for 6 inch wide Flextray basket. The insert measures 6 in wide by 118 in long with a .25 in height, so it seats inside the basket floor of a 6 inch tray width. For wider runs you need the insert cut to that tray width instead.

They fasten with Eaton B-Line FTHDWE 1/4 inch hardware and a top washer. The washer sits on top of the insert and clamps it down to the wire mesh. That hardware is a separate item from the insert itself, so order it with the run.

UL Listed, per the product record. That matters on institutional and commercial jobs where the inspector wants listed components through the whole tray system, including the bottom inserts.

Flat black powder coat over steel. It is the standard B-Line black Flextray finish, so it reads the same as black powder coated basket sections in exposed ceiling and data center runs where the tray is visible.

No. The 6 x 118 inch steel insert weighs 1 lb, so adding it to an existing basket run does not meaningfully change your support spacing. The load that matters is the cable on top of it.
