Eaton B-Line series Flextray wire basket tray, 8" X 118", Attach with (FTHDWE) 1/4" and top washer, Black powder coat, Steel, Solid bottom inserts
Manufacturer Resources
Product Specs
- Application:
- Attach with (FTHDWE) 1/4 in and top washer
- Certifications:
- UL Listed
- Product Height:
- .25 in
- Product Length Depth:
- 118 in
- Product Weight:
- 1 lb
- Product Width:
- 8 in
- Department:
- Electrical
- Product Group:
- Accessories
- Product Subgroup:
- Inserts
- Product Type:
- Solid bottom inserts
- Product Finish:
- Flat black powder coat
- Product Details:
- Solid bottom inserts
- Product Material:
- Steel
B-LINE INSERT 8X118BLE – Frequently Asked Questions
1) How does a solid bottom insert attach inside a wire basket cable tray?
It attaches with (FTHDWE) 1/4 inch hardware and a top washer through the basket wires. The hardware is specified separately, so order the FTHDWE kit along with the insert if you do not already have it on the job.
2) Why would I put a solid bottom insert in a Flextray basket run instead of leaving it open?
An open wire basket supports cable on spaced wires, which is fine for most data and power runs but can leave small-diameter or fiber cable sagging between wires and bearing on a narrow point. A solid steel bottom insert gives a continuous flat bearing surface for that section of the run, and it also acts as a barrier under drops or transitions. Use it only where you need it; the rest of the run can stay open for airflow and cleaning.
3) What part number do I order for the 8 inch black Flextray bottom insert?
Order Eaton B-Line part INSERT 8X118BLE. The BLE suffix is the black powder coat finish, 8 is the tray width in inches and 118 the insert length.
4) Will the black powder coat insert match my existing black Flextray?
The finish is flat black powder coat on steel, the same finish family B-Line uses across the black Flextray line, so it blends into exposed black basket runs in open-ceiling offices, retail, and data rooms. If your tray is electro-zinc, pre-galvanized, or stainless, the black insert will read as a visible contrast.
