Eaton B-Line series hanging system, KwikWire wire rope, Toggle style single termination, 1/16" wire max, 240" wire length
Manufacturer Resources
Product Specs
- Certifications:
- cULus Listed
- Product Diameter:
- .06 in
- Product Height:
- 240 in
- Product Weight:
- 2.56 lb
- Wire Diameter Max:
- .062 in
- Wire Length:
- 240 in
- Department:
- Electrical
- Product Type:
- Toggle termination
- Product Model:
- KwikWire wire rope
- Product Details:
- Toggle termination
B-LINE BKT-063-240 – Frequently Asked Questions
1) What does a toggle style termination do on a KwikWire hanging kit, and where does it anchor?
The toggle end is the top anchor. You feed the folded toggle through a hole in the deck, purlin, or panel, and it flips crosswise on the far side to bear against the structure. That makes it the right pick when you can drill through but cannot get a wrench or a hook onto the back side, which is the usual case with metal deck or above a hard-lid ceiling. If you have open bar joist or beam flange to work with, a hook or beam clamp end is easier than drilling.
2) Is the Eaton B-Line KwikWire system listed for use in commercial buildings?
The KwikWire BKT-063-240 is cULus Listed, so it carries both US and Canadian listings. That is the line inspectors and spec writers look for when wire rope is used to support lighting or other electrical equipment.
3) Does the BKT-063-240 come as a single hanger or a set?
It is a single termination, one wire rope with one toggle end. Most fixtures need two or four hang points, so order per point, not per fixture. Check your fixture's suspension detail for how many drops it calls for.
