B-Line Eaton series strut channel, nuts, all threaded rod, Steel, Channel nuts, Nut without spring, Stainless steel type 316 finish, 250 lbs pull out

The N225SS6 channel nut is tapped 1/2"-13, so it takes 1/2 inch all-thread rod or 1/2"-13 hex bolts. If your rod is 3/8"-16 or 1/4"-20, this is the wrong nut in the family.

No spring. The N225SS6 is a plain channel nut, so nothing holds it in position while you set the hanger. You insert it into the strut, turn it a quarter turn to seat the teeth in the channel lips, then hold it while you start the rod. Overhead, that means two hands or a helper; if you are working alone on a long run, a spring nut version is the easier part to install.

Yes. The N225SS6 is Type 316 stainless, which is the grade specified for chloride exposure: coastal air, chemical and wastewater plants, natatoriums, food processing washdown. Pair it with 316 strut and 316 threaded rod, since mixing stainless with plain electro-galvanized hardware in a wet location gives you a corrosion point at the joint.

The nut alone is just the anchor point in the channel. A rod-hung trapeze needs the strut, 1/2 inch threaded rod to match the 1/2"-13 tapping, and the clamps or straps for the conduit or pipe. For a bolted bracket connection instead of rod, you need 1/2"-13 hex bolts of the right length. In a 316 application, order all of those in stainless so you are not mixing metals.

Both land the same load in the channel; the difference is handling. A plain nut like the N225SS6 is the cheaper, simpler part and works well when you can reach the connection and hold it, or when you are pre-assembling trapezes on the ground. A spring nut holds its position in the channel by itself, which matters on overhead runs where you are on a ladder with a rod in one hand. For long horizontal runs where you set many nuts before loading them, the spring version saves real time.

Steel body with a Type 316 stainless finish, per the manufacturer's spec data. The teeth that bite the channel lips are formed in that same body, so the gripping surfaces carry the same corrosion protection as the rest of the nut.
