Baldwin 0397 SWL Flush Cup Handle & Swivel Spindle Ring Pull

The 0397 SWL cup pull is a 3-1/2 inch round face, listed at 3-1/2 x 3-1/2 inches overall, so the mortise pocket in the door has to accept that 3-1/2 inch diameter cup. On a pocket or barn door, lay out the cut from that dimension before you commit the router.

Baldwin lists the 0397 SWL as a residential part. For a high-cycle commercial opening in an office or a hotel corridor, spec commercial-duty pocket door hardware instead. For a residence, a model unit, or a light-traffic interior pocket or barn door, this is the right class of pull.

The round cup needs a full 3-1/2 inches of stile width plus edge material either side, so a narrow-stile door will not take it. On a narrow stile, a rectangular pull mortises in a much smaller footprint: the Emtek 2201 and 220304 are 1-3/4 x 4 inches, and the Emtek 2205 Brass #8 is 1-7/8 x 5 inches, all of which run the long dimension vertically down a slim stile.

Pull only. There is no latching mechanism in the 0397 SWL, no privacy function and no edge pull. If the pocket door needs to hold shut or lock, you have to order a separate pocket door latch or privacy set alongside it.

The Baldwin 0397 SWL is a round flush cup pull measuring 3-1/2 inches by 3-1/2 inches in brass, with a swivel spindle ring that folds down into the cup. If the door calls for a rectangular cutout instead, the Emtek 2201 Rectangular Brass Flush Pull is 1-3/4 inches by 4 inches, so it takes a narrow slot mortise rather than a square pocket. Both are brass. The mortise geometry is the deciding factor: a rectangular pull will not fill a cutout made for the 3-1/2 inch square footprint of the 0397 SWL, so choose the shape before the door is routed.

A narrower pull is the answer. The Baldwin 0397 SWL needs a 3-1/2 inch by 3-1/2 inch footprint. The Emtek 220304 Modern Rectangular Brass Flush Pull is 1-3/4 inches by 4 inches, which fits a stile too narrow for a square cutout while keeping the length for a full hand grip. On a thicker or wider rail, the Emtek 2205 Brass #8 Flush Pull runs 1-7/8 inches by 5 inches. Both are brass, like the 0397 SWL.

No. The Baldwin 0397 SWL is a 3-1/2 inch by 3-1/2 inch cup with a swivel spindle ring that lifts out of the recess to be grasped. The Emtek 2201 is a 1-3/4 inch by 4 inch rectangular flush pull and the Emtek 220304 Modern Rectangular is the same 1-3/4 inch by 4 inch size. Neither has a ring, and neither covers the square mortise the Baldwin sits in. Swapping in either direction means a new cutout and, on the Baldwin side, an operable ring where the Emtek pulls are a fixed recess.

One finish: 260 Polished Chrome. If you are matching a bright chrome lever and hinge package on the rest of the openings, it lands. If the rest of the unit is brass or bronze, this pull will read as an outlier and you should look at a bronze or brass flush pull instead, such as the Emtek 220404 Rustic Modern Rectangular sandcast bronze flush pull.

Brass is the substrate on the 0397 SWL, finished in 260 Polished Chrome. That is a plated brass part, not a zinc casting, which is what you want on a door someone pulls several times a day.

A ring pull like the 0397 SWL gives you something to hook a finger through and get real leverage on a heavy or stiff door, and the swivel ring lies flat when you release it. A plain rectangular flush pull, like the Emtek 2201 at 1-3/4 x 4 inches, is a recessed finger pocket only, lower profile and easier to mortise into a narrow stile, but harder to pull a sticky door with. Ring for pull force, rectangle for a slim stile.

Yes, if the door is used from both sides. The 0397 SWL is a single cup pull, so a pocket door that opens from either room takes one on each face, mortised back to back at matching height. A barn door that only gets operated from one side takes one.

The Baldwin 0397 SWL is a brass pull in a polished chrome finish, which reads bright and traditional. For a door where the rest of the hardware is dark and textured, the Emtek 220404 Rustic Modern Rectangular Sandcast Bronze Flush Pull is sandcast bronze at 2 inches by 4 inches, giving a rougher cast surface and a rectangular mortise. Cast bronze and polished brass are different metals with different surface character, so they are not typically mixed on the same opening.

The Baldwin 0397 SWL is designated for residential use. It is a brass cup pull with a swivel spindle ring, sized 3-1/2 inches by 3-1/2 inches, and its operable ring is a moving part on a door that may see constant traffic. Where a facility wants a fixed recess with no moving element, a plain rectangular flush pull such as the Emtek 2201 at 1-3/4 inches by 4 inches or the Emtek 2205 Brass #8 at 1-7/8 inches by 5 inches gives a grip with nothing to swing.

Among comparable brass flush pulls, the Emtek 2205 Brass #8 is 1-7/8 inches by 5 inches, the longest recess of the group, so a full hand fits inside the pocket. The Emtek 220404 Rustic Modern Rectangular is 2 inches by 4 inches, wider but shorter. The Baldwin 0397 SWL takes a different approach: at 3-1/2 inches by 3-1/2 inches it is a square cup, and the grip comes from a swivel spindle ring that lifts out of the recess rather than from the length of the pocket itself.

There are two mortise families to standardize on. Square cup: the Baldwin 0397 SWL is 3-1/2 inches by 3-1/2 inches in brass, with a swivel spindle ring. Rectangular slot: the Emtek 2201 Rectangular and Emtek 220304 Modern Rectangular are both 1-3/4 inches by 4 inches in brass, the Emtek 2205 Brass #8 is 1-7/8 inches by 5 inches in brass, and the Emtek 220404 Rustic Modern Rectangular is 2 inches by 4 inches in sandcast bronze. Doors already routed for one family cannot take the other without repair, so the cutout, not the style, is what fixes the standard.

Both are brass rectangular flush pulls measuring 1-3/4 inches by 4 inches, so they take the same mortise. The difference is the series styling: the 2201 belongs to Emtek's Rectangular series and the 220304 to the Modern Rectangular series. For a buyer replacing one on a door already cut for either, the opening does not change. The Baldwin 0397 SWL is a separate decision, being a 3-1/2 inch square cup with a swivel spindle ring.
