Baldwin Baldwin Estate R027 Rosette for Passage Door Functions BAL-R027-PASSAGE

Baldwin Estate R027 Rosette for Passage Door Functions

(No reviews yet) Write a Review

Model: R027003IPS
From the Estate Series Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$66.00
$45.69
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BALDWIN ESTATE R027 ROSETTE FOR PASSAGE DOOR FUNCTIONS OVERVIEW

Entry/Non-Egress: Supports 1 3⁄4” doors. Includes cylinder and deadbolt latch. Must order desired knobs or levers and knob/lever passage latch along with 6503.009 or 6504.009 Adaptor separately. For a 2-1/4” thick door, you must order the 8098.000.TP03 thick door kit for the cylinder and a 5“ solid spindle 05xx.004.

Egress: Supports 1 3⁄4” doors. Includes cylinder, spindle, deadbolt latch, knob/lever latch, and egress cartridge. Must order desired knobs or levers separately. Spindle included with Egress kit will work from 1.75” to 2.25” Thick Doors. Must order 5399.xxx.C Thick Door Kit for doors 2” to 2.25” thick. Interior Egress roses do not match Interior Non-Egress or Dummy roses.

Note: All 10 inch rose interiors and exteriors have exposed screws except the Entry/Entry Egress kits, which have exposed interior screws only.

R027, R029 and R054 all cover most singular tubular cut out.

KEY FEATURES

  • A sweeping arch takes this regal design to the next level.
  • Privacy roses are sold as either a pair or individual and are used to create tubular privacy sets.
  • Passage roses are sold as either a pair or individual and can be used to create tubular passage or mortise sectional entry sets.
  • Dummy roses are sold as a pair or individual and are used to create tubular full or half dummy sets.
  • Includes either one or two roses, the appropriate backplate and the retainer(s) required to secure the rose to the door. Knobs or levers, latch and adaptors sold separately.
  • This style is featured in Quick Ship as part of a complete Passage, Privacy, Full Dummy or Half Dummy set.
  • This rustic styled piece places an emphasis on the organic and natural, leading to tastefully distressed looks that are approachable and relaxed.
  • Dependability, quality, and high design. Baldwin's Quick Ship items are ready to ship to you within 5 business days from ordering.

RESOURCES & DOWNLOADS

Manufacturer Resources

Product Specs

Product Group:
Door Trim and Accessories
Product Type:
Door Rosette
Subcategory:
Parts and Accessories
Product Subgroup:
Door Rosette
Commercial/Residential:
Residential
Collection:
Estate Series
Product Model:
R027
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Baldwin R027003IPS – Frequently Asked Questions

1) Does the Baldwin R027 passage rosette come with knobs and a latch, or do I order those separately?
The R027 rosette ships as either one or two roses with the matching backplate and the retainer(s) that hold the rose to the door. Knobs or levers, the latch, and any adaptors are separate orders. So budget for three line items minimum: the rose, the knob or lever, and the passage latch.
2) What is the difference between the Pair and Half Pair option on the Baldwin R027 rosette?
Pair gives you two roses, one for each face of the door. Half Pair is a single rose, which is what you want for a half dummy application or when you are only replacing or trimming one side. Every finish is offered both ways.
3) Will the R027 rosette fit the hole already bored in my door?
Most likely. R027, along with R029 and R054, covers most standard singular tubular cutouts, so it drops over a typical tubular bore without new prep.
4) What door thickness does the Baldwin Estate R027 work with, and what do I need for a thicker door?
The standard kits support 1-3/4 inch doors, the usual residential and commercial door thickness. For a 2-1/4 inch thick door on the entry/non-egress setup, add the 8098.000.TP03 thick door kit for the cylinder plus a 5 inch solid spindle (05xx.004). On the egress side, the included spindle covers 1.75 to 2.25 inches, but doors 2 to 2.25 inches thick need the 5399.xxx.C thick door kit.
5) Can I use the R027 passage rose to build a mortise entry set?
Yes. Passage roses in the Estate line are used to create tubular passage sets and also mortise sectional entry sets. Privacy roses build tubular privacy sets and dummy roses build full or half dummy sets, so pick the rose that matches the function you are assembling.
6) What finishes does the Baldwin Estate R027 rosette come in?
Fifteen finishes, each available as a Pair or Half Pair: 003 Polished Brass PVD, 031 Non-Lacquered Brass, 033 Vintage Brass, 044 Satin Brass PVD, 050 Satin Brass Black, 055 Polished Nickel PVD, 056 Lifetime PVD Satin Nickel, 060 Satin Brass Brown, 076 Lifetime PVD Graphite Nickel, 102 Oil Rubbed Bronze, 112 Venetian Bronze, 151 Antique Nickel, 190 Satin Black, 260 Polished Chrome, and 402 Distressed Oil Rubbed Bronze. Match the numeric code when ordering knobs and latches so the whole set reads as one finish.
7) What adaptor do I need with the R027 for an entry non-egress setup?
For entry/non-egress, the kit includes the cylinder and deadbolt latch, and you order the knobs or levers plus the knob/lever passage latch along with either the 6503.009 or 6504.009 adaptor. The egress kit is different: it already includes cylinder, spindle, deadbolt latch, knob/lever latch and the egress cartridge, so only the knobs or levers are added.
8) Are the mounting screws on the Baldwin R027 rose visible once installed?
On the 10 inch rose interiors and exteriors, screws are exposed. The exception is the entry and entry egress kits, which show exposed screws on the interior side only. Worth knowing if the client is particular about a clean face.
9) Is the Baldwin R027 rosette a residential or commercial product?
It is a residential product in Baldwin's Estate Series. For multi-family common areas or commercial openings with cycle and fire requirements, look at commercial-grade trim instead; the R027 is decorative trim for a tubular residential opening.
