Baldwin M514 Boulder Full Escutcheon Single Cylinder Knob Entry Mortise Trim

It's decorative mortise trim, not a working lock on its own. The Boulder full escutcheon set covers the outside plate with the 5024 knob and the cylinder cut, and a full mortise opening needs the other components specified alongside it: the mortise lock body, cylinder, and the interior trim. The door also needs custom mortise preparation. Budget for the lock body and cylinder on the same order, or the trim can't be installed.

Yes. The M514 Boulder trim covers doors from 1-3/4 inches up to 2-1/4 inches thick, so a standard 1-3/4 inch commercial or exterior door is at the bottom of its range. Thinner doors are out; if you're working a 1-3/8 inch door this is the wrong trim. Baldwin does publish thin and thick door kits to widen the range of door conditions, so ask about those if your slab falls outside 1-3/4 to 2-1/4.

C-keyway. That's the Schlage C profile, which is the most widely stocked keyway in the trades, so a locksmith can key the M514 into an existing C-keyway master system without swapping cylinders. If your building is keyed to a proprietary or restricted keyway, this trim won't join that system as supplied.

No handing call needed. The Boulder full escutcheon trim is reversible, so one part number covers both left and right hand openings. The mortise lock body behind it is where handing and function get set, so confirm that piece against the door swing.

Mortise is the harder road. It needs a pocket cut into the door edge, a separate lock body, and the trim specified to match, so it only makes sense on a heavy entry door where you want the escutcheon look and the mortise lock's durability. For a bored door or a straight replacement, a cylindrical entry lock is far less work. The Hager 2525 is a Grade 2 cylindrical entry lock for 1-3/8 to 2 inch doors, and the Cal-Royal AG00 is an entrance lever in the same Schlage C keyway on a 2-3/8 inch backset. Either drops into standard bore prep with no mortise pocket.

Projection off the door is 3.4 inches, with a 4.09 inch grip length on the 5024 knob. Worth checking if the door swings back against a wall, a sidelight return, or a storm door, since a 3.4 inch projection is what decides whether the knob clears.

Yes. Baldwin builds this trim to be customized: substitute any interior knob or lever you like, or use the interior escutcheon plate alone. That's how you turn the same Boulder escutcheon into a passage, privacy, dummy, or entry set. As configured here it is single cylinder entry function with the 5024 knob.

Yes, the Boulder full escutcheon is offered in Full Dummy and Exterior Only versions, plus individual escutcheons cut for cylinder, cut for emergency release, cut for knob, and cut for turn knob. So you can pair a working entry leaf with a dummy leaf in the same trim. If matching finish is less critical than cost on the inactive leaf, commercial dummy trims like the BEST 9K 1DT (Grade 1) or 7KC 1DT (Grade 2) are cylindrical dummy options.

The M514 Boulder trim does cover 2 inch doors, since its range runs 1-3/4 to 2-1/4 inches. If you'd rather avoid mortise prep at that thickness, the Falcon K101 is a Grade 1 cylindrical lock rated 1-3/8 to 2-1/4 inches, and Deltana's Manchester, Morant, and Linstead entry levers are all listed for 1-3/8 to 2 inch doors. The Falcon is the heavy-duty commercial route; the Deltana levers are the decorative residential-style alternative.

Yes, it's single cylinder entry function: keyed cylinder on the exterior escutcheon, no second cylinder inside. The interior side is handled by whatever knob, lever, or turn knob you pair with it, so an inside thumbturn is a trim selection rather than a second key. For units where you'd want key control on both faces, this configuration won't do it.

The M514 Boulder is an entry function trim with a single cylinder and C-keyway. For a non-locking opening, the Bravura Atlanta and Bravura Orlando are Grade 2 passage leversets with round trim, the Bravura Tampa is a Grade 2 passage leverset with square trim, and the Callan Asheville is a Grade 3 passage leverset. For a door that only needs a pull with no latch at all, the Callan Bentley is a Grade 2 dummy lever.

The Baldwin M514 Boulder is decorative mortise trim built around the 5024 knob and a C-keyway cylinder, aimed at architectural residential and light commercial openings. If the drawing calls out a graded commercial lock, the Corbin Russwin CL3110 is a Grade 1 vandal resistant cylindrical lever for 1-3/4 to 2 inch doors with a fire rating, the Falcon K101 is a Grade 1 heavy duty cylindrical lock covering 1-3/8 to 2-1/4 inch doors, and the Cal-Royal AG05 is a Grade 2 storeroom lever with a deadlocking latchbolt.

The M514 Boulder is keyed, using a single C-keyway cylinder. For a code-operated entry instead, the Lockey 2835 is a mechanical pushbutton keyless lever lock that is ADA compliant and fits doors from 1-3/16 to 2 inches, the Lockey 1150 is a heavy duty mechanical keypad lever set for 1-1/8 to 2 inch doors with an adjustable backset, and the Delaney LP250 is a Grade 2 electronic keypad leverlock.

No. The Baldwin M514 Boulder is an entry function trim only. For a classroom opening, the Dexter C1000 classroom lock is Grade 1 with a clutching lever for 1-3/8 to 1-3/4 inch doors, and the Cal-Royal AG03 is a Grade 2 classroom lever with a 6-pin Schlage C keyway and 2-3/4 inch backset. For a storeroom, the Hager 2580 is a Grade 2 storeroom cylindrical lock for 1-3/8 to 2 inch doors.

The Baldwin M514 Boulder takes a single C-keyway cylinder. Among commercial cylindrical locks, the Cal-Royal AG00 entrance lever and Cal-Royal AG03 classroom lever both use a 6-pin Schlage C keyway keyed different, and the Arrow MK33-BD-CS asylum lock uses a conventional Schlage C keyway cylinder. That shared keyway is what lets a property standardize keys across mixed hardware.

The Baldwin M514 Boulder is mortise trim with a reversible hand, a 3.4 inch projection, and a 4.09 inch grip length, and it requires custom mortise door prep. Simpler bored entry sets include the Callan Artino Grade 3 entrance leverset, the Callan Bennett Grade 3 entrance leverset with deadbolt combo, and the Master Lock RL series Grade 3 return style keyed entry lockset.
